Engine Oil System of Lamborghini Lamborghini Diablo VT (1993-1998)

View All

Lamborghini Diablo VT (1993-1998) - Engine Oil System

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	1533285	FLEX. HOSE	1533285 FLEX. HOSE TUBO FLESSIBILE	$1,181.15	1
002	1531828	FLEX. HOSE	1531828 FLEX. HOSE TUBO FLESSIBILE	$764.28	1
003	1531858	FLEX. HOSE	1531858 FLEX. HOSE TUBO FLESSIBILE	$849.68	1
004	4133013	ROD	4133013 ROD ASIA SUPPORTO RAD. OLIO	$102.22	1
005	1533286	FLEX. HOSE	1533286 FLEX. HOSE TUBO FLESSIBILE	$333.64	1
006	1533889	PIPE	1533889 PIPE TUBO	$98.53	1
007	1533703	PIPE	1533703 PIPE TUBO	$436.73	1
008	WHT003062	SEAL RING IN STOCK	WHT003062 SEAL RING ANELLO TENUTA IN STOCK	$6.61	1
009	8300828	STUD	8300828 STUD PRIGIONIERO	-	2	Enquire
010	8410820	WASHER	8410820 WASHER RONDELLA	$0.19 MSRP: ~~7.37~~ (97.4% off)	2
011	N01100845	HEXAGON NUT IN STOCK	N01100845 HEXAGON NUT DADO IN STOCK	$1.89	2
012	8200816	NUT	8200816 NUT DADO	$5.14	1
013	8300905	STUD	8300905 STUD PRIGIONIERO	$18.60 MSRP: ~~19.45~~ (4.4% off)	1
014	8403006	WASHER	8403006 WASHER RONDELLA	$10.18	1
015	400115707	CONNECTOR	400115707 CONNECTOR RACCORDO	$34.14	1
016	4133295	SUPPORT - SUPPORTO	4133295 SUPPORT - SUPPORTO O	$134.19	1
017	N90327506	SPEED NUT IN STOCK	N90327506 SPEED NUT PIASTRINA CON FILETTATURA IN STOCK	$0.94	1
018	1533284	BRACKET	1533284 BRACKET STAFFA	$45.95	1
019	N10718801	HEX COLLARED BOLT	N10718801 HEX COLLARED BOLT VITE	$0.95	1
020	7M117021	OIL RADIATOR	7M117021 OIL RADIATOR RADIATORE OLIO	$4,334.67	1
021	410813585	RUBBER WEATHER-	410813585 RUBBER WEATHER- PROFILATO COMMA	$13.97	1
022	4133292	SUPPORT - SUPPORTO RADIATORE	4133292 SUPPORT - SUPPORTO RADIATORE O RADIATORE	$413.15	1
023	N90319404	SCREW IN STOCK	N90319404 SCREW VITE IN STOCK	$1.89	2
024	N01118312	HEXAGON NUT, SELF-LOCKING IN STOCK	N01118312 HEXAGON NUT, SELF-LOCKING DADO IN STOCK	$2.04	2
025	8920604	SILENTBLOC - SILENTBLOC	8920604 SILENTBLOC - SILENTBLOC	$19.30	1
