Water Pump of Lamborghini Lamborghini Diablo SV (1995-1997)

View All

Lamborghini Diablo SV (1995-1997) - Water Pump

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	7L919501A	Water Temperature Sensor	7L919501A Water Temperature Sensor SENSORE TEMP. ACQUA	$359.56	2
002	8832604	STRAP	8832604 STRAP FASCETTA	$3.37	2
003	1732811	PIPE	1732811 PIPE TUBO	$25.20 MSRP: ~~25.50~~ (1.2% off)	1
004	8700617	SCREW	8700617 SCREW VITE	$0.25 MSRP: ~~7.35~~ (96.6% off)	2
005	8410602	WASHER	8410602 WASHER RONDELLA	$44.87	2
006	WHT003062	SEAL RING	WHT003062 SEAL RING ANELLO TENUTA	$6.61	1
007	8700650	SCREW	8700650 SCREW VITE	$2.42 MSRP: ~~2.50~~ (3.2% off)	1
008	8301034	STUD	8301034 STUD PRIGIONIERO	$5.82 MSRP: ~~6.00~~ (3% off)	1
009	WHT003028	THREADED PIN	WHT003028 THREADED PIN PRIGIONIERO	$22.30	2
010	1734252	IMPELLER	1734252 IMPELLER GIRANTE	$592.77	1
011	1734243	SHIM	1734243 SHIM SPESSORE Dl REGISTRO 1.8 MM	$36.68	1
011	1734242	SHIM	1734242 SHIM SPESSORE Dl REGISTRO 1.6 MM	$36.68	1
011	1734241	SHIM	1734241 SHIM SPESSORE Dl REGISTRO 1.4 MM	$53.92	1
011	1734240	SHIM	1734240 SHIM SPESSORE Dl REGISTRO 1.2 MM	$36.68	1
011	1734239	SHIM	1734239 SHIM SPESSORE Dl REGISTRO 1 .0 MM	$36.68	1
011	1734247	SHIM	1734247 SHIM SPESSORE Dl REGISTRO 2.6 MM	$36.68	1
011	1734244	SHIM	1734244 SHIM SPESSORE Dl REGISTRO 2.0 MM	$36.68	1
011	1734248	SHIM	1734248 SHIM SPESSORE Dl REGISTRO 2.8 MM	$36.68	1
011	1734246	SHIM	1734246 SHIM SPESSORE Dl REGISTRO 2.4 MM	$36.68	1
011	1734245	SHIM	1734245 SHIM SPESSORE Dl REGISTRO 2.2 MM	$36.68	1
012	1734675	SEAL	1734675 SEAL TENUTA FRONTALE	$46.59	1
013	1727739	SMALL SHAFT	1727739 SMALL SHAFT CUSCINETTO	$470.44	1
014	WHT003018	SEAL RING	WHT003018 SEAL RING ANELLO TENUTA	$87.36	1
015	1734676	WATER PUMP CASE	1734676 WATER PUMP CASE CORPO POMPA ACQUA	-	1	Enquire
016	8300833	STUD BOLT	8300833 STUD BOLT PRIGIONIERO	$6.09 MSRP: ~~6.30~~ (3.3% off)	1
017	1736516	TRANS BELT	1736516 TRANS BELT WATER PUMP, ALTERNATOR & POWER STEERING	$428.46	1
018	N0122094	WASHER	N0122094 WASHER RONDELLA	$1.47 MSRP: ~~7.15~~ (79.4% off)	3
019	8200809	NUT	8200809 NUT DADO	$1.96	3
020	8301034	STUD	8301034 STUD PRIGIONIERO	$5.82 MSRP: ~~6.00~~ (3% off)	1
021	1237082	BUSHING	1237082 BUSHING BUSSOLA	$262.00	1
022	7M109565	PULLEY	7M109565 PULLEY PULEGGIA	$3,938.16	1
023	8401006	WASHER	8401006 WASHER RONDELLA	$0.61 MSRP: ~~7.29~~ (91.6% off)	1
024	8201008	NUT	8201008 NUT DADO	$0.80 MSRP: ~~7.24~~ (89% off)	1
025	1736801	PULLEY	1736801 PULLEY PULEGGIA	$1,189.84	1
026	1724221	THERMOCOUPLE	1724221 THERMOCOUPLE TERMOCOPPIA	$142.01	1
027	8401408	WASHER	8401408 WASHER RONDELLA	$0.88 MSRP: ~~7.22~~ (87.8% off)	1
028	1732803	CONNECTION	1732803 CONNECTION RACCORDO	$330.04	1
029	8840601	HELI-COIL	8840601 HELI-COIL	$2.56	2
