Gearbox of Lamborghini Lamborghini Diablo GT (1999-2000)

View All

Lamborghini Diablo GT (1999-2000) - Gearbox

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	8100807	SCREW	8100807 SCREW VITE	-	1	Enquire
002	8700644	SCREW	8700644 SCREW VITE	-	4	Enquire
003	8410602	WASHER	8410602 WASHER RONDELLA	-	4	Enquire
004	2428645	COVER	2428645 COVER COPERCHIO SFIATO	-	1	Enquire
005	8830128	CLAMP	8830128 CLAMP FASCETTA	-	1	Enquire
006	2428643	PAN	2428643 PAN VASCHETTA	-	1	Enquire
007	2428649	VENT PIPE	2428649 VENT PIPE TUBO Dl SFIATO	-	1	Enquire
008	8100821	SCREW	8100821 SCREW VITE	-	9	Enquire
009	WHT000771	WASHER	WHT000771 WASHER RONDELLA	-	22	Enquire
010	2424900	COVER	2424900 COVER COPERCHIO	-	1	Enquire
011	8850806	DOWEL	8850806 DOWEL GRAND	-	4	Enquire
012	N01029315	SCREW (FROM VIN 5LA01545)	N01029315 SCREW (FROM VIN 5LA01545) VITE	-	1	Enquire
013	8400802	WASHER	8400802 WASHER RONDELLA	-	1	Enquire
014	2425223	ROD	2425223 ROD PUNTALINO	-	2	Enquire
015	2425224	ROD	2425224 ROD PUNTALINO	-	1	Enquire
016	8300895	STUD	8300895 STUD PRIGIONIERO	-	2	Enquire
017	8300897	STUD	8300897 STUD PRIGIONIERO	-	1	Enquire
018	8300916	STUD	8300916 STUD PRIGIONIERO	-	9	Enquire
019	2430746	GEAR BOX CASE	2430746 GEAR BOX CASE SCATOLA CAMBIO	-	1	Enquire
020	86301141A	MAGNETIC PLUG	86301141A MAGNETIC PLUG TAPPO MAGNETICO	-	1	Enquire
021	N01100845	HEXAGON NUT	N01100845 HEXAGON NUT DADO	-	12	Enquire
022	2435931	COVER	2435931 COVER COPERCHIO	-	1	Enquire
023	8410602	WASHER	8410602 WASHER RONDELLA	-	4	Enquire
024	86301141A	MAGNETIC PLUG	86301141A MAGNETIC PLUG TAPPO MAGNETICO	-	1	Enquire
025	8100861	SCREW M8X90	8100861 SCREW M8X90 VITE	-	4	Enquire
026	2425638	COVER	2425638 COVER COPERCHIO	-	1	Enquire
027	8410602	WASHER	8410602 WASHER RONDELLA	-	6	Enquire
028	8100601	SCREW	8100601 SCREW VITE	-	6	Enquire
029	8801612	BUSHING	8801612 BUSHING BOCCOLA	-	1	Enquire
030	8611605	SEAL	8611605 SEAL ANELLO TENUTA	-	1	Enquire
