Water Pump of Lamborghini Lamborghini Diablo GT (1999-2000)

View All

Lamborghini Diablo GT (1999-2000) - Water Pump

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	7L919501A	Water Temperature Sensor IN STOCK	7L919501A Water Temperature Sensor SENSORE TEMP. ACOUA IN STOCK	$359.56	2
002	8832604	STRAP	8832604 STRAP FASCETTA	$3.37	2
003	1732811	PIPE	1732811 PIPE TUBO	$25.20 MSRP: ~~25.50~~ (1.2% off)	1
004	8700617	SCREW IN STOCK	8700617 SCREW VITE IN STOCK	$0.25 MSRP: ~~7.35~~ (96.6% off)	2
005	8410602	WASHER IN STOCK	8410602 WASHER RONDELLA IN STOCK	$44.87	2
006	WHT003062	SEAL RING IN STOCK	WHT003062 SEAL RING ANELLO TENUTA IN STOCK	$6.61	1
007	8700650	SCREW IN STOCK	8700650 SCREW VITE IN STOCK	$2.42 MSRP: ~~2.50~~ (3.2% off)	1
008	8301034	STUD	8301034 STUD PRIGIONIERO	$5.82 MSRP: ~~6.00~~ (3% off)	1
009	WHT003028	THREADED PIN	WHT003028 THREADED PIN PRIGIONIERO	$22.30	2
010	8201008	NUT IN STOCK	8201008 NUT DADO IN STOCK	$0.80 MSRP: ~~7.24~~ (89% off)	1
011	N0122094	WASHER IN STOCK	N0122094 WASHER RONDELLA IN STOCK	$1.47 MSRP: ~~7.15~~ (79.4% off)	1
012	7M109565	PULLEY	7M109565 PULLEY PULEGGIA	$3,938.16	1
013	1237082	BUSHING	1237082 BUSHING BUSSOLA	$262.00	1
014	8301034	STUD	8301034 STUD PRIGIONIERO	$5.82 MSRP: ~~6.00~~ (3% off)	1
015	8300833	STUD BOLT	8300833 STUD BOLT PRIGIONIERO	$6.09 MSRP: ~~6.30~~ (3.3% off)	1
016	8200809	NUT	8200809 NUT DADO	$1.96	3
017	N0122094	WASHER IN STOCK	N0122094 WASHER RONDELLA IN STOCK	$1.47 MSRP: ~~7.15~~ (79.4% off)	3
018	1736516	TRANS BELT	1736516 TRANS BELT WATER PUMP, ALTERNATOR & POWER STEERING	$428.46	1
019	17001862	WATER PUMP	17001862 WATER PUMP POMPA ACOUA	$4,096.35	1
020	8840601	HELI-COIL	8840601 HELI-COIL	$2.56	2
021	1732803	CONNECTION	1732803 CONNECTION RACCORDO	$330.04	1
022	8401408	WASHER IN STOCK	8401408 WASHER RONDELLA IN STOCK	$0.88 MSRP: ~~7.22~~ (87.8% off)	1
023	1724221	THERMOCOUPLE	1724221 THERMOCOUPLE TERMOCOPPIA	$142.01	1
024	WHT003018	SEAL RING IN STOCK	WHT003018 SEAL RING (Also Included In The Engine Gaskets Kit) ANELLO Dl TENUTA IN STOCK	$87.36	1
025	1732806	COVER	1732806 COVER COPERCHIO	$1,074.44 MSRP: ~~1,125.00~~ (4.5% off)	1
026	17004515	THERMOSTAT	17004515 THERMOSTAT TERMOSTATO	-	1	Enquire
027	1732808	GASKET IN STOCK	1732808 GASKET GUARNIZIONE IN STOCK	$23.44 MSRP: ~~23.70~~ (1.1% off)	1
028	17006572	THERMOSTAT CASING	17006572 THERMOSTAT CASING CORPO TERMOSTATO	$774.19	1
029	8300803	STUD BOLT	8300803 STUD BOLT PRIGIONIERO	$13.40	4
030	WHT000771	WASHER IN STOCK	WHT000771 WASHER RONDELLA IN STOCK	$1.19	4
031	8200816	NUT	8200816 NUT DADO	$5.14	4
032	8410602	WASHER IN STOCK	8410602 WASHER RONDELLA IN STOCK	$44.87	2
033	N01118312	HEXAGON NUT, SELF-LOCKING IN STOCK	N01118312 HEXAGON NUT, SELF-LOCKING DADO IN STOCK	$2.04	2
