SECONDARY AIR PUMP of Lamborghini Lamborghini Aventador LP770 SVJ Coupe

View All

Lamborghini Aventador LP770 SVJ Coupe - SECONDARY AIR PUMP

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	400998075	PUMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10451408	OVAL HEXAGON SOCKET HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10210501	CLAMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N02214812	HEXAGON NUT, SELF-LOCKING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT002961	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91054001	SEMI ROUND BOLT (COMBI) WITH HEXAGON SOCKET HEAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10451408	OVAL HEXAGON SOCKET HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470131611B	AIR HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470131611C	AIR HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N0206253	CLAMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	6A131120D	SEAL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470906613D	BRACKET FOR SECONDARY AIR PUMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470906617C	BRACKET FOR SECONDARY AIR PUMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	7L131119	Secondary Air Injection Pump Hose	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	7L131101N	COMBINATION VALVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470133898A	PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470133897B	PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	7L133579	T-PIECE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470131845	PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470131846	PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470131853	PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	6L906052A	PRESSURE SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	7M133106B	HEAT SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		HEAT SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470906325A	HEAT SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470906294A	HEAT SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	1J0906029A	BRACKET FOR CONNECTOR HOUSING	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	400998075	PUMP	400998075 PUMP	-	2	Enquire
2	N10451408	OVAL HEXAGON SOCKET HEAD BOLT	N10451408 OVAL HEXAGON SOCKET HEAD BOLT M6X16-M6X16	-	8	Enquire
3	N10210501	CLAMP	N10210501 CLAMP 9,5X5X0,5	-	6	Enquire
4	N02214812	HEXAGON NUT, SELF-LOCKING	N02214812 HEXAGON NUT, SELF-LOCKING M6-M6	-	6	Enquire
5	WHT002961	WASHER	WHT002961 WASHER 6,5X18X1,5	-	10	Enquire
6	N91054001	SEMI ROUND BOLT (COMBI) WITH HEXAGON SOCKET HEAD	N91054001 SEMI ROUND BOLT (COMBI) WITH HEXAGON SOCKET HEAD M6X22-M6X22	-	9	Enquire
7	N10451408	OVAL HEXAGON SOCKET HEAD BOLT	N10451408 OVAL HEXAGON SOCKET HEAD BOLT M6X16-M6X16	-	4	Enquire
8	470131611B	AIR HOSE	470131611B AIR HOSE RIGHT	-	1	Enquire
9	470131611C	AIR HOSE	470131611C AIR HOSE LEFT	-	1	Enquire
10	N0206253	CLAMP	N0206253 CLAMP	-	5	Enquire
11	6A131120D	SEAL	6A131120D SEAL	-	4	Enquire
12	470906613D	BRACKET FOR SECONDARY AIR PUMP	470906613D BRACKET FOR SECONDARY AIR PUMP LEFT	-	1	Enquire
13	470906617C	BRACKET FOR SECONDARY AIR PUMP	470906617C BRACKET FOR SECONDARY AIR PUMP RIGHT	-	1	Enquire
14	7L131119	Secondary Air Injection Pump Hose	7L131119 Secondary Air Injection Pump Hose	-	2	Enquire
15	7L131101N	COMBINATION VALVE	7L131101N COMBINATION VALVE	-	2	Enquire
16	470133898A	PIPE	470133898A PIPE RIGHT	-	1	Enquire
17	470133897B	PIPE	470133897B PIPE LEFT	-	1	Enquire
18	7L133579	T-PIECE	7L133579 T-PIECE	-	1	Enquire
19	470131845	PIPE	470131845 PIPE LEFT	-	1	Enquire
20	470131846	PIPE	470131846 PIPE RIGHT	-	1	Enquire
21	470131853	PIPE	470131853 PIPE CENTER	-	1	Enquire
22	6L906052A	PRESSURE SENSOR	6L906052A PRESSURE SENSOR	-	2	Enquire
23	7M133106B	HEAT SHIELD	7M133106B HEAT SHIELD	-	2	Enquire
24	-	HEAT SHIELD	HEAT SHIELD CANNOT BE SOLD SEPARATELY - INCLUDED IN REF.:- 1	-	-	Enquire
25	470906325A	HEAT SHIELD	470906325A HEAT SHIELD LEFT	-	1	Enquire
26	470906294A	HEAT SHIELD	470906294A HEAT SHIELD RIGHT	-	1	Enquire
27	1J0906029A	BRACKET FOR CONNECTOR HOUSING	1J0906029A BRACKET FOR CONNECTOR HOUSING 6R0 973 735 1J0 973 835	-	1	Enquire
