DASHBOARD AND TUNNEL INSTRUMENTS of Ferrari Ferrari LaFerrari

View All

Ferrari LaFerrari - DASHBOARD AND TUNNEL INSTRUMENTS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	303134	COMPLETE INSTRUMENT PANEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	305351	INDICATOR LAMP MODULE ASSEMBLY	Enquire	To Order
	304950	INDICATOR LAMP MODULE ASSEMBLY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	168133	Screw M5 x 20	Enquire	To Order
	168133	Screw M5 x 20	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	179087	INERTIAL SWITCH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	293193	COMPLETE POWER WINDOW CONTROLS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	300402	RH POWER WINDOW BUTTON	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	300403	LH POWER WINDOW BUTTON	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11568124	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	298790	POWER WINDOW CONTROLS MOUNTING BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14418074	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	72587700	EPB Switch With AutoPark Disable -No longer supplied- -Replaced by 820259..-	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	88822200	SCREW TORX HEAD M4 X 10MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	236871	SUNLIGHT SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	246568	VEHICLE LIFT CONTROL	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	15957077	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	246860	HAZARD WARNING LIGHT BUTTON	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14418074	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10519224	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	86786900	CAP	Enquire	To Order
	300409	NAVIGATOR CONTROLS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14418074	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	300408	DISPLAY MODE SELECTOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14418125	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10519224	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	300410	EXTERNAL REAR VIEW MIRROR CONTROL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	15902570	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85560700	MIRROR CONTROLS BRACKET ON DOOR PANEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	15902570	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	313837	F1 GEARBOX CONTROLS	Enquire	To Order
	313836	F1 GEARBOX CONTROLS	Enquire	To Order
	308435	F1 GEARBOX CONTROLS	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	83996600	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	311368	LIGHTS AND REAR FOG LIGHT SWITCH SATELLITE	Enquire	To Order
	300411	LIGHTS AND REAR FOG LIGHT SWITCH SATELLITE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85930500	FELT PAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	298816	LUGGAGE COMPARTMENT LID AND FUEL FILLER FLAP RELEASE CONTROL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14418074	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	298837	BATTERY CHARGER SOCKET COVER RELEASE CONTROL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	298918	DOOR SWITCH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	299616	MIRROR SURROUND CONTROLS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	82893300	LH VENT CONTROL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	88822200	SCREW TORX HEAD M4 X 10MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85747300	BUTTON CARRIER BRACKET ON DOOR PANEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14303123	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12639901	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12642821	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	293193	COMPLETE POWER WINDOW CONTROLS	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	303134	COMPLETE INSTRUMENT PANEL	303134 COMPLETE INSTRUMENT PANEL	-	1	Enquire
2	305351	INDICATOR LAMP MODULE ASSEMBLY	305351 INDICATOR LAMP MODULE ASSEMBLY Applicable for USA, CDN	-	1	Enquire
2	304950	INDICATOR LAMP MODULE ASSEMBLY	304950 INDICATOR LAMP MODULE ASSEMBLY Not for USA, CDN	-	1	Enquire
3	168133	Screw M5 x 20	168133 Screw M5 x 20 Applicable for USA, CDN	-	2	Enquire
3	168133	Screw M5 x 20	168133 Screw M5 x 20 Not for USA, CDN	-	2	Enquire
4	179087	INERTIAL SWITCH	179087 INERTIAL SWITCH	-	1	Enquire
5	293193	COMPLETE POWER WINDOW CONTROLS	293193 COMPLETE POWER WINDOW CONTROLS Replaced by compl. 293193 ref. 43; No longer supplied	-	1	Enquire
6	300402	RH POWER WINDOW BUTTON	300402 RH POWER WINDOW BUTTON	-	1	Enquire
7	300403	LH POWER WINDOW BUTTON	300403 LH POWER WINDOW BUTTON	-	1	Enquire
8	11568124	SCREW	11568124 SCREW M5 X 16	-	2	Enquire
9	298790	POWER WINDOW CONTROLS MOUNTING BRACKET	298790 POWER WINDOW CONTROLS MOUNTING BRACKET	-	1	Enquire
10	14418074	SCREW	14418074 SCREW	-	4	Enquire
11	72587700	EPB Switch With AutoPark Disable -No longer supplied- -Replaced by 820259..-	72587700 EPB Switch With AutoPark Disable -No longer supplied- -Replaced by 820259..- Plastic in interior leather trim colour	-	1	Enquire
12	88822200	SCREW TORX HEAD M4 X 10MM	88822200 SCREW TORX HEAD M4 X 10MM	-	3	Enquire
13	236871	SUNLIGHT SENSOR	236871 SUNLIGHT SENSOR	-	1	Enquire
14	246568	VEHICLE LIFT CONTROL ARRIVING SOON	246568 VEHICLE LIFT CONTROL Version with lifter ARRIVING SOON	-	1	Enquire
15	15957077	SCREW	15957077 SCREW	-	2	Enquire
16	246860	HAZARD WARNING LIGHT BUTTON	246860 HAZARD WARNING LIGHT BUTTON	-	1	Enquire
17	14418074	SCREW	14418074 SCREW	-	4	Enquire
18	10519224	WASHER	10519224 WASHER	-	4	Enquire
19	86786900	CAP	86786900 CAP Not for audio system with integrated satellite navigation	-	1	Enquire
19	300409	NAVIGATOR CONTROLS	300409 NAVIGATOR CONTROLS	-	1	Enquire
20	14418074	SCREW	14418074 SCREW	-	2	Enquire
21	300408	DISPLAY MODE SELECTOR	300408 DISPLAY MODE SELECTOR	-	1	Enquire
22	14418125	SCREW	14418125 SCREW No longer supplied	-	2	Enquire
23	10519224	WASHER	10519224 WASHER	-	2	Enquire
24	300410	EXTERNAL REAR VIEW MIRROR CONTROL	300410 EXTERNAL REAR VIEW MIRROR CONTROL	-	1	Enquire
25	15902570	SCREW	15902570 SCREW	-	2	Enquire
26	85560700	MIRROR CONTROLS BRACKET ON DOOR PANEL	85560700 MIRROR CONTROLS BRACKET ON DOOR PANEL	-	1	Enquire
27	15902570	SCREW	15902570 SCREW	-	2	Enquire
28	313837	F1 GEARBOX CONTROLS	313837 F1 GEARBOX CONTROLS With yellow ring; Applicable for USA, CDN, USA LIGHT	-	1	Enquire
28	313836	F1 GEARBOX CONTROLS	313836 F1 GEARBOX CONTROLS Applicable for USA, CDN, USA LIGHT	-	1	Enquire
28	308435	F1 GEARBOX CONTROLS	308435 F1 GEARBOX CONTROLS With yellow ring; Not for USA, CDN, USA LIGHT	-	1	Enquire
28	299308	F1 GEARBOX CONTROLS	299308 F1 GEARBOX CONTROLS Not for USA, CDN, USA LIGHT	-	1	Enquire
29	83996600	SCREW	83996600 SCREW	-	6	Enquire
30	311368	LIGHTS AND REAR FOG LIGHT SWITCH SATELLITE	311368 LIGHTS AND REAR FOG LIGHT SWITCH SATELLITE Applicable for J	-	1	Enquire
30	300411	LIGHTS AND REAR FOG LIGHT SWITCH SATELLITE	300411 LIGHTS AND REAR FOG LIGHT SWITCH SATELLITE Not for J	-	1	Enquire
31	85930500	FELT PAD	85930500 FELT PAD No longer supplied	-	1	Enquire
32	298816	LUGGAGE COMPARTMENT LID AND FUEL FILLER FLAP RELEASE CONTROL	298816 LUGGAGE COMPARTMENT LID AND FUEL FILLER FLAP RELEASE CONTROL	-	1	Enquire
33	14418074	SCREW	14418074 SCREW	-	6	Enquire
34	298837	BATTERY CHARGER SOCKET COVER RELEASE CONTROL	298837 BATTERY CHARGER SOCKET COVER RELEASE CONTROL	-	1	Enquire
35	298918	DOOR SWITCH	298918 DOOR SWITCH	-	1	Enquire
36	299616	MIRROR SURROUND CONTROLS	299616 MIRROR SURROUND CONTROLS	-	1	Enquire
37	82893300	LH VENT CONTROL	82893300 LH VENT CONTROL	-	4	Enquire
38	88822200	SCREW TORX HEAD M4 X 10MM	88822200 SCREW TORX HEAD M4 X 10MM M4 X 10	-	8	Enquire
39	85747300	BUTTON CARRIER BRACKET ON DOOR PANEL	85747300 BUTTON CARRIER BRACKET ON DOOR PANEL	-	1	Enquire
40	14303123	SCREW	14303123 SCREW	-	3	Enquire
41	12639901	WASHER	12639901 WASHER	-	3	Enquire
42	12642821	WASHER	12642821 WASHER Not for USA, CDN	-	2	Enquire
43	293193	COMPLETE POWER WINDOW CONTROLS	293193 COMPLETE POWER WINDOW CONTROLS	-	1	Enquire
