CRANKCASE of Ferrari Ferrari F8 Spider Europe

View All

Ferrari F8 Spider Europe - CRANKCASE

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	820170	CRANKCASE-LOWER CRANKCASE SHELL ASSEMBLY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	312059	CENTERING DOWEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	270465	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	270466	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	133988	HEX NUT M10 X 1.25 X 8	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	178348	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	134705	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	312836	COMPL. VALVE HOLDER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13026924	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	103994	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	339289	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231620	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	317217	CHAIN COOLING NOZZLE ASSEMBLY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	282393	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11066876	SEEGER RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	247049	BEARING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11060276	SEEGER RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	304697	DRIVE JOINT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231619	SOCKET HEAD SCREW M6 X 22 WITH WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	164400	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	306145	Thread Cap M18 x 1.5	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10259960	Copper Washer 18 - 24 x 1.5	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	315493	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	307477	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10263460	COPPER GASKET D.28-22.3 X 1.5	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	282755	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	935026	COMPL. CHAIN COOLING NOZZLE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	291078	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	311001	CENTERING DOWEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	935031	COMPL. CHAIN COOLING NOZZLE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	334895	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	334890	CYLINDER SLEEVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	278120	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	298858	PISTON COOLING NOZZLE ASSEMBLY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	298859	PISTON COOLING NOZZLE ASSEMBLY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	271598	GASKET	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	339287	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	270464	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	185360	CENTERING DOWEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	271564	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	282753	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231620	SCREW	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
0001	820170	CRANKCASE-LOWER CRANKCASE SHELL ASSEMBLY	820170 CRANKCASE-LOWER CRANKCASE SHELL ASSEMBLY	-	1	Enquire
0002	312059	CENTERING DOWEL	312059 CENTERING DOWEL	-	10	Enquire
0003	270465	STUD BOLT	270465 STUD BOLT	-	10	Enquire
0004	270466	STUD BOLT	270466 STUD BOLT	-	10	Enquire
0005	133988	HEX NUT M10 X 1.25 X 8	133988 HEX NUT M10 X 1.25 X 8	-	20	Enquire
0006	178348	WASHER	178348 WASHER	-	20	Enquire
0007	134705	GASKET	134705 GASKET	-	20	Enquire
0008	312836	COMPL. VALVE HOLDER	312836 COMPL. VALVE HOLDER	-	4	Enquire
0009	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2	-	8	Enquire
0010	13026924	SCREW	13026924 SCREW M6 X 14	-	8	Enquire
0011	103994	GASKET	103994 GASKET	-	4	Enquire
0012	339289	GASKET	339289 GASKET Also included in engine gasket set	-	1	Enquire
0013	231620	SCREW	231620 SCREW M6 X 25	-	12	Enquire
0014	317217	CHAIN COOLING NOZZLE ASSEMBLY	317217 CHAIN COOLING NOZZLE ASSEMBLY	-	1	Enquire
0015	282393	SCREW	282393 SCREW M6 X 14	-	3	Enquire
0016	11066876	SEEGER RING	11066876 SEEGER RING	-	1	Enquire
0017	247049	BEARING	247049 BEARING	-	1	Enquire
0018	11060276	SEEGER RING	11060276 SEEGER RING	-	1	Enquire
0019	304697	DRIVE JOINT	304697 DRIVE JOINT	-	1	Enquire
0020	231619	SOCKET HEAD SCREW M6 X 22 WITH WASHER	231619 SOCKET HEAD SCREW M6 X 22 WITH WASHER M6 X 20	-	1	Enquire
0021	164400	THREADED PLUG	164400 THREADED PLUG	-	1	Enquire
0022	306145	Thread Cap M18 x 1.5	306145 Thread Cap M18 x 1.5	-	3	Enquire
0023	10259960	Copper Washer 18 - 24 x 1.5	10259960 Copper Washer 18 - 24 x 1.5 Also included in engine gasket set	-	3	Enquire
0024	315493	SCREW	315493 SCREW M4 X 10	-	12	Enquire
0025	307477	THREADED PLUG	307477 THREADED PLUG	-	2	Enquire
0026	10263460	COPPER GASKET D.28-22.3 X 1.5	10263460 COPPER GASKET D.28-22.3 X 1.5 Also included in engine gasket set	-	2	Enquire
0027	282755	THREADED PLUG	282755 THREADED PLUG D. 10 X 1.25	-	4	Enquire
0028	935026	COMPL. CHAIN COOLING NOZZLE	935026 COMPL. CHAIN COOLING NOZZLE	-	1	Enquire
0029	291078	THREADED PLUG	291078 THREADED PLUG M12 X 11	-	2	Enquire
0030	311001	CENTERING DOWEL	311001 CENTERING DOWEL	-	2	Enquire
0031	935031	COMPL. CHAIN COOLING NOZZLE	935031 COMPL. CHAIN COOLING NOZZLE	-	1	Enquire
0032	334895	GASKET	334895 GASKET	-	24	Enquire
0033	334890	CYLINDER SLEEVE	334890 CYLINDER SLEEVE	-	8	Enquire
0034	278120	STUD BOLT	278120 STUD BOLT	-	8	Enquire
0035	298858	PISTON COOLING NOZZLE ASSEMBLY	298858 PISTON COOLING NOZZLE ASSEMBLY	-	4	Enquire
0036	298859	PISTON COOLING NOZZLE ASSEMBLY	298859 PISTON COOLING NOZZLE ASSEMBLY	-	8	Enquire
0037	271598	GASKET ARRIVING SOON	271598 GASKET ARRIVING SOON	-	1	Enquire
0038	339287	GASKET	339287 GASKET Also included in engine gasket set	-	1	Enquire
0039	270464	STUD BOLT	270464 STUD BOLT	-	18	Enquire
0040	185360	CENTERING DOWEL	185360 CENTERING DOWEL	-	4	Enquire
0041	271564	STUD BOLT	271564 STUD BOLT	-	2	Enquire
0042	282753	THREADED PLUG	282753 THREADED PLUG	-	2	Enquire
0043	231620	SCREW	231620 SCREW M6 X 30	-	1	Enquire
