Name: OUTER GEARBOX CONTROLS
Rating: 4.6 (1 reviews)

OUTER GEARBOX CONTROLS of Ferrari Ferrari F50

View All

Ferrari F50 - OUTER GEARBOX CONTROLS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	150856	GEARBOX CONTROL TURRET	$1,755.41	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	$1.51	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WASHER	$0.06	To Order

Photo	Part No	Description	Price (each)	Stock
	13541124	STUD BOLT	$23.50	To Order

Photo	Part No	Description	Price (each)	Stock
	150860	GEAR SELECTOR	$946.70	To Order

Photo	Part No	Description	Price (each)	Stock
	84653800	WASHER	$5.75	To Order

Photo	Part No	Description	Price (each)	Stock
	115980A	SWITCH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	235980	BUSHING	$239.70	To Order

Photo	Part No	Description	Price (each)	Stock
	14303123	SCREW	$0.06	To Order

Photo	Part No	Description	Price (each)	Stock
	146992	BALL	$288.81	To Order

Photo	Part No	Description	Price (each)	Stock
	147561	SPRING	$110.47	To Order

Photo	Part No	Description	Price (each)	Stock
	150857	GEARBOX CONTROL LEVER	$946.70	To Order

Photo	Part No	Description	Price (each)	Stock
	146994	PIN	$34.57	To Order

Photo	Part No	Description	Price (each)	Stock
	108010	CHECKNUT	$27.31	To Order

Photo	Part No	Description	Price (each)	Stock
	165483	KNOB	$1,021.68	To Order

Photo	Part No	Description	Price (each)	Stock
	127446	BALL SEAT FOR JOINT	$30.42	To Order

Photo	Part No	Description	Price (each)	Stock
	155480	ROCKER IN TOWER	$372.17	To Order

Photo	Part No	Description	Price (each)	Stock
	150859	FRAME	$15.54	To Order

Photo	Part No	Description	Price (each)	Stock
	80365900	SCREW	$0.16	To Order

Photo	Part No	Description	Price (each)	Stock
	150858	RUBBER BOOT	$49.73	To Order

Photo	Part No	Description	Price (each)	Stock
	149907	BUSHING	$35.25	To Order

Photo	Part No	Description	Price (each)	Stock
	145773	GASKET	$6.89	To Order

Photo	Part No	Description	Price (each)	Stock
	161956	FRONT CONTROL BAR FOR GEAR BOX	$609.73	To Order

Photo	Part No	Description	Price (each)	Stock
	15212724	SCREW	$1.56	To Order

Photo	Part No	Description	Price (each)	Stock
	10519424	WASHER	$0.02	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	$1.51	To Order

Photo	Part No	Description	Price (each)	Stock
	150865	ROD ON OIL SUMP	$61.57	To Order

Photo	Part No	Description	Price (each)	Stock
	145773	GASKET	$6.89	To Order

Photo	Part No	Description	Price (each)	Stock
	149907	BUSHING	$35.25	To Order

Photo	Part No	Description	Price (each)	Stock
	154004	SPACER	$13.21	To Order

Photo	Part No	Description	Price (each)	Stock
	151521	REAR CONTROL BAR FOR GEAR BOX	$577.64	To Order

Photo	Part No	Description	Price (each)	Stock
	145773	GASKET	$6.89	To Order

Photo	Part No	Description	Price (each)	Stock
	149907	BUSHING	$35.25	To Order

Photo	Part No	Description	Price (each)	Stock
	155481	ROD ON GEARBOX	$123.17	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
-	147561	SPRING	147561 SPRING Valid after stock exhaustion of 147561	$110.47	1
1	150856	GEARBOX CONTROL TURRET	150856 GEARBOX CONTROL TURRET	$1,755.41	1
2	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	$1.51	4
3	11197774	WASHER	11197774 WASHER	$0.06 MSRP: ~~0.30~~ (80% off)	4
4	13541124	STUD BOLT	13541124 STUD BOLT	$23.50	4
5	150860	GEAR SELECTOR	150860 GEAR SELECTOR	$946.70	1
6	84653800	WASHER	84653800 WASHER	$5.75	1
7	115980A	SWITCH	115980A SWITCH	-	1	Enquire
8	235980	BUSHING	235980 BUSHING	$239.70	1
9	14303123	SCREW	14303123 SCREW	$0.06	4
10	146992	BALL	146992 BALL	$288.81	1
11	147561	SPRING	147561 SPRING	$110.47	1
12	150857	GEARBOX CONTROL LEVER	150857 GEARBOX CONTROL LEVER	$946.70	1
13	146994	PIN	146994 PIN	$34.57	1
14	108010	CHECKNUT	108010 CHECKNUT	$27.31 MSRP: ~~29.30~~ (6.8% off)	1
15	165483	KNOB	165483 KNOB	$1,021.68	1
16	127446	BALL SEAT FOR JOINT	127446 BALL SEAT FOR JOINT	$30.42 MSRP: ~~37.64~~ (19.2% off)	1
17	155480	ROCKER IN TOWER	155480 ROCKER IN TOWER	$372.17	1
18	150859	FRAME	150859 FRAME	$15.54	1
19	80365900	SCREW	80365900 SCREW	$0.16 MSRP: ~~0.50~~ (68% off)	6
20	150858	RUBBER BOOT	150858 RUBBER BOOT	$49.73	1
21	149907	BUSHING	149907 BUSHING	$35.25	2
22	145773	GASKET	145773 GASKET	$6.89 MSRP: ~~8.74~~ (21.2% off)	2
23	161956	FRONT CONTROL BAR FOR GEAR BOX	161956 FRONT CONTROL BAR FOR GEAR BOX	$609.73	1
24	15212724	SCREW	15212724 SCREW	$1.56	3
25	10519424	WASHER	10519424 WASHER	$0.02 MSRP: ~~0.25~~ (92% off)	3
26	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	$1.51	3
27	150865	ROD ON OIL SUMP	150865 ROD ON OIL SUMP	$61.57	1
28	145773	GASKET	145773 GASKET	$6.89 MSRP: ~~8.74~~ (21.2% off)	2
29	149907	BUSHING	149907 BUSHING	$35.25	2
30	154004	SPACER	154004 SPACER	$13.21	1
31	151521	REAR CONTROL BAR FOR GEAR BOX	151521 REAR CONTROL BAR FOR GEAR BOX	$577.64	1
32	145773	GASKET	145773 GASKET	$6.89 MSRP: ~~8.74~~ (21.2% off)	2
33	149907	BUSHING	149907 BUSHING	$35.25	1
34	155481	ROD ON GEARBOX	155481 ROD ON GEARBOX	$123.17	1
