Name: CLUTCH CONTROLS
Rating: 4.1 (1 reviews)

View All

Ferrari F50 - CLUTCH CONTROLS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	154939	ENGINE FLYWHEEL WITH TOOTHED WHEEL	$3,706.98	To Order

Photo	Part No	Description	Price (each)	Stock
	10337530	PIN	$0.84	To Order

Photo	Part No	Description	Price (each)	Stock
	201755	Bolt Hex Head M10 x 1.25	$1.18	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	163854	CLUTCH TWIN DISC	$7,802.85	To Order

Photo	Part No	Description	Price (each)	Stock
	155318	RING GEAR	$449.27	To Order

Photo	Part No	Description	Price (each)	Stock
	238108	WASHER	$0.45	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	85757300	SCREW	$3.24	To Order

Photo	Part No	Description	Price (each)	Stock
	166434	COMPLETE THRUST BEARING	$802.28	To Order

Photo	Part No	Description	Price (each)	Stock
	154550	SCRAPER RING	$24.62	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	154504	SEAL RING 32MM	$7.05	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	154505	SEAL RING 32MM	$13.21	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	154508	Sealing Ring 44mm	$40.10	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	154507	Ring	$3.97	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	154551	Scrapper Ring	$27.26	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	121717	Pre load spring	$14.91	To Order

Photo	Part No	Description	Price (each)	Stock
	155322	PIN	$50.16	To Order

Photo	Part No	Description	Price (each)	Stock
	11065474	CIRCLIP	$0.13	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	238108	WASHER	$0.45	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	155867	FLANGE FOR BEARING	$2,529.48	To Order

Photo	Part No	Description	Price (each)	Stock
	14040711	NUT	$0.42	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	127496	WASHER	$0.06	To Order

Photo	Part No	Description	Price (each)	Stock
	155935	CLUTCH CONTROL PIPE	$63.75	To Order

Photo	Part No	Description	Price (each)	Stock
	155929	DRAIN PIPE	$63.03	To Order

Photo	Part No	Description	Price (each)	Stock
	235706	Union Block	$256.72	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	152954	BLEED NIPPLE SCREW	$6.40	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	13579224	WASHER	$0.36	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	$1.43	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	155966	SPACER	$63.26	To Order

Photo	Part No	Description	Price (each)	Stock
	11067876	Seeger Ring	$0.28	To Order

Photo	Part No	Description	Price (each)	Stock
	146767	BEARING	$614.89	To Order

Photo	Part No	Description	Price (each)	Stock
	155883	CLUTCH SHAFT	$802.28	To Order

Photo	Part No	Description	Price (each)	Stock
	163854	CLUTCH TWIN DISC	$7,802.85	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
1	154939	ENGINE FLYWHEEL WITH TOOTHED WHEEL	154939 ENGINE FLYWHEEL WITH TOOTHED WHEEL TOOTHED WHEEL	$3,706.98	1
2	10337530	PIN	10337530 PIN	$0.84	2
3	201755	Bolt Hex Head M10 x 1.25 IN STOCK	201755 Bolt Hex Head M10 x 1.25 IN STOCK	$1.18 MSRP: ~~1.95~~ (39.5% off)	9
4	163854	CLUTCH TWIN DISC	163854 CLUTCH TWIN DISC	$7,802.85	1
5	155318	RING GEAR	155318 RING GEAR	$449.27	1
6	238108	WASHER IN STOCK	238108 WASHER IN STOCK	$0.45 MSRP: ~~0.65~~ (30.8% off)	9
7	85757300	SCREW	85757300 SCREW	$3.24	9
8	166434	COMPLETE THRUST BEARING	166434 COMPLETE THRUST BEARING	$802.28	1
9	154550	SCRAPER RING IN STOCK	154550 SCRAPER RING IN STOCK	$24.62	1
10	154504	SEAL RING 32MM IN STOCK	154504 SEAL RING 32MM IN STOCK	$7.05	1
11	154505	SEAL RING 32MM IN STOCK	154505 SEAL RING 32MM IN STOCK	$13.21 MSRP: ~~16.86~~ (21.6% off)	1
12	154508	Sealing Ring 44mm IN STOCK	154508 Sealing Ring 44mm IN STOCK	$40.10 MSRP: ~~54.22~~ (26% off)	1
13	154507	Ring IN STOCK	154507 Ring IN STOCK	$3.97 MSRP: ~~5.05~~ (21.4% off)	1
14	154551	Scrapper Ring IN STOCK	154551 Scrapper Ring IN STOCK	$27.26 MSRP: ~~29.85~~ (8.7% off)	1
15	121717	Pre load spring	121717 Pre load spring	$14.91 MSRP: ~~18.85~~ (20.9% off)	2
16	155322	PIN	155322 PIN	$50.16	1
17	11065474	CIRCLIP IN STOCK	11065474 CIRCLIP IN STOCK	$0.13 MSRP: ~~0.95~~ (86.3% off)	1
18	238108	WASHER IN STOCK	238108 WASHER IN STOCK	$0.45 MSRP: ~~0.65~~ (30.8% off)	1
19	155867	FLANGE FOR BEARING	155867 FLANGE FOR BEARING	$2,529.48	1
20	14040711	NUT IN STOCK	14040711 NUT IN STOCK	$0.42	4
21	127496	WASHER	127496 WASHER	$0.06 MSRP: ~~0.30~~ (80% off)	4
22	155935	CLUTCH CONTROL PIPE	155935 CLUTCH CONTROL PIPE	$63.75	1
23	155929	DRAIN PIPE	155929 DRAIN PIPE	$63.03	1
24	235706	Union Block IN STOCK	235706 Union Block IN STOCK	$256.72	1
25	152954	BLEED NIPPLE SCREW IN STOCK	152954 BLEED NIPPLE SCREW IN STOCK	$6.40	1
26	13579224	WASHER	13579224 WASHER	$0.36	1
27	14059290	FLANGED NUT M6 IN STOCK	14059290 FLANGED NUT M6 IN STOCK	$1.43	1
28	155966	SPACER	155966 SPACER	$63.26	5
29	11067876	Seeger Ring	11067876 Seeger Ring	$0.28	1
30	146767	BEARING	146767 BEARING	$614.89	1
31	155883	CLUTCH SHAFT	155883 CLUTCH SHAFT	$802.28	1
32	163854	CLUTCH TWIN DISC	163854 CLUTCH TWIN DISC Not as spare part / With the assembly 163854	$7,802.85	1

Clutch Controls

Ferrari F50

Ferrari F50 - CLUTCH CONTROLS
