Door - Power window of Ferrari Ferrari 512 M

View All

Ferrari 512 M - Door - Power window

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	63096200	L.H. window regulator	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	61533600	L.H. glass	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63057200	L.H. frame work complete	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	61548600	Gasket for L.H. door	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	61574000	Support for LH external rear view mirror	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	147985	NUT	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	61568600	BUTTON	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	62771300	Column	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	61509800	Run channel	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	61509900	Rear run channel	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62106600	OUTER BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62106700	INNER BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63108500	L.H. glass base	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63111300	Cover to fix LH mirror	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10902424	SCREW	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	12643724	WASHER	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	62766200	Bushing	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10902221	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14084411	Nut	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	62766300	CLIP	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	84653800	WASHER	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	812273	CABLE GROMMET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12648925	WASHER	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	10902221	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	12648925	WASHER	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	81591700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	12648925	WASHER	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	63951200	Bracket	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13836371	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10977521	SCREW	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	12638124	WASHER	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	319201	FUEL FILLER PIPE ASSEMBLY	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	64536300	Spacer	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64536200	Spacer	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
-	63108400	R.H. glass base	63108400 R.H. glass base	-	1	Enquire
-	63111200	Cover to fix RH mirror	63111200 Cover to fix RH mirror R.H. mirror	-	1	Enquire
-	61573900	Support for RH external rear view mirror	61573900 Support for RH external rear view mirror view mirror	-	1	Enquire
-	61533700	R.H. glass	61533700 R.H. glass	-	1	Enquire
-	63057100	R.H. frame work complete	63057100 R.H. frame work complete	-	1	Enquire
-	61548500	Gasket for R.H. door	61548500 Gasket for R.H. door	-	1	Enquire
-	63096100	R.H. window regulator	63096100 R.H. window regulator	-	1	Enquire
1	63096200	L.H. window regulator	63096200 L.H. window regulator	-	1	Enquire
2	61533600	L.H. glass	61533600 L.H. glass	-	1	Enquire
3	63057200	L.H. frame work complete	63057200 L.H. frame work complete	-	1	Enquire
4	61548600	Gasket for L.H. door	61548600 Gasket for L.H. door	-	1	Enquire
5	61574000	Support for LH external rear view mirror	61574000 Support for LH external rear view mirror view mirror	-	1	Enquire
6	147985	NUT IN STOCK	147985 NUT IN STOCK	-	2	Enquire
7	61568600	BUTTON IN STOCK	61568600 BUTTON IN STOCK	-	6	Enquire
8	62771300	Column	62771300 Column	-	4	Enquire
9	61509800	Run channel	61509800 Run channel	-	2	Enquire
10	61509900	Rear run channel	61509900 Rear run channel	-	2	Enquire
11	62106600	OUTER BUSHING	62106600 OUTER BUSHING	-	4	Enquire
12	62106700	INNER BUSHING	62106700 INNER BUSHING	-	4	Enquire
13	63108500	L.H. glass base	63108500 L.H. glass base	-	1	Enquire
14	63111300	Cover to fix LH mirror	63111300 Cover to fix LH mirror L.H. mirror	-	1	Enquire
15	10902424	SCREW IN STOCK	10902424 SCREW IN STOCK	-	4	Enquire
16	14059290	FLANGED NUT M6 IN STOCK	14059290 FLANGED NUT M6 IN STOCK	-	4	Enquire
17	12643724	WASHER IN STOCK	12643724 WASHER IN STOCK	-	14	Enquire
18	62766200	Bushing	62766200 Bushing	-	4	Enquire
19	10902221	SCREW	10902221 SCREW	-	6	Enquire
20	14084411	Nut	14084411 Nut	-	2	Enquire
21	127494	WASHER IN STOCK	127494 WASHER IN STOCK	-	2	Enquire
22	62766300	CLIP IN STOCK	62766300 CLIP IN STOCK	-	4	Enquire
23	84653800	WASHER IN STOCK	84653800 WASHER IN STOCK	-	2	Enquire
24	812273	CABLE GROMMET	812273 CABLE GROMMET	-	2	Enquire
25	12648925	WASHER IN STOCK	12648925 WASHER IN STOCK	-	4	Enquire
26	14059290	FLANGED NUT M6 IN STOCK	14059290 FLANGED NUT M6 IN STOCK	-	4	Enquire
27	10902221	SCREW	10902221 SCREW	-	6	Enquire
28	127494	WASHER IN STOCK	127494 WASHER IN STOCK	-	6	Enquire
29	12648925	WASHER IN STOCK	12648925 WASHER IN STOCK	-	6	Enquire
30	81591700	SCREW	81591700 SCREW	-	2	Enquire
31	127494	WASHER IN STOCK	127494 WASHER IN STOCK	-	2	Enquire
32	12648925	WASHER IN STOCK	12648925 WASHER IN STOCK	-	2	Enquire
33	63951200	Bracket	63951200 Bracket	-	2	Enquire
34	13836371	SCREW	13836371 SCREW	-	2	Enquire
35	10977521	SCREW IN STOCK	10977521 SCREW IN STOCK	-	2	Enquire
36	12638124	WASHER IN STOCK	12638124 WASHER IN STOCK	-	4	Enquire
37	319201	FUEL FILLER PIPE ASSEMBLY IN STOCK	319201 FUEL FILLER PIPE ASSEMBLY IN STOCK	-	2	Enquire
38	64536300	Spacer	64536300 Spacer	-	2	Enquire
39	64536200	Spacer	64536200 Spacer	-	2	Enquire
