Name: ENGINE COMPARTMENT LID AND RELEASE MECHANISM
Rating: 4.4 (1 reviews)

ENGINE COMPARTMENT LID AND RELEASE MECHANISM of Ferrari Ferrari 488 Spider

View All

Ferrari 488 Spider - ENGINE COMPARTMENT LID AND RELEASE MECHANISM

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	87413911	COMPL. REAR LID	$6,373.90	To Order
	87381811	COMPL. REAR LID	$4,258.52	To Order

Photo	Part No	Description	Price (each)	Stock
	87624800	ENGINE COMPARTMENT LID HINGE	$286.67	To Order

Photo	Part No	Description	Price (each)	Stock
	16286124	SCREW	$0.37	To Order
	16286121	SCREW	$0.70	To Order

Photo	Part No	Description	Price (each)	Stock
	12647021	WASHER	$0.32	To Order

Photo	Part No	Description	Price (each)	Stock
	87667600	RH ENGINE COMPARTMENT LID AIR VENT GRILLE TRIM	$224.63	To Order

Photo	Part No	Description	Price (each)	Stock
	87667500	LH ENGINE COMPARTMENT LID AIR VENT GRILLE TRIM	$224.63	To Order

Photo	Part No	Description	Price (each)	Stock
	87780900	GAS STRUT REAR LID	$43.18	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	69106400	PIN	$2.54	To Order

Photo	Part No	Description	Price (each)	Stock
	87667000	COMPL. RH ENGINE COMPARTMENT LID AIR VENT GRILLE	$702.02	To Order

Photo	Part No	Description	Price (each)	Stock
	87666900	COMPL. LH ENGINE COMPARTMENT LID AIR VENT GRILLE	$702.02	To Order

Photo	Part No	Description	Price (each)	Stock
	87934400	SPACER	$2.79	To Order
	87934500	SPACER	$2.90	To Order

Photo	Part No	Description	Price (each)	Stock
	85833900	SCREW	$0.36	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	83467200	LOCK STRIKER	$51.59	To Order

Photo	Part No	Description	Price (each)	Stock
	87513800	REAR LID HANDLE, COMPL. WITH CABLE	$240.67	To Order
	87258800	REAR LID HANDLE, COMPL. WITH CABLE	$224.63	To Order

Photo	Part No	Description	Price (each)	Stock
	82926600	BRACKET FOR ENGINE COMPARTMENT LID HANDLE	$240.67	To Order
	83028900	BRACKET FOR ENGINE COMPARTMENT LID HANDLE	$53.02	To Order

Photo	Part No	Description	Price (each)	Stock
	11612826	SCREW	$3.40	To Order

Photo	Part No	Description	Price (each)	Stock
	303385	CLIP	$0.31	To Order

Photo	Part No	Description	Price (each)	Stock
	248061	CLIP	$2.22	To Order

Photo	Part No	Description	Price (each)	Stock
	303385	CLIP	$0.31	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	$1.51	To Order

Photo	Part No	Description	Price (each)	Stock
	113113	WASHER	$1.07	To Order

Photo	Part No	Description	Price (each)	Stock
	67161800	VIBRATION DAMPER	$43.31	To Order

Photo	Part No	Description	Price (each)	Stock
	84076100	ENGINE COMPARTMENT LID LOCK	$141.90	To Order

Photo	Part No	Description	Price (each)	Stock
	87231800	ENGINE COMPARTMENT LID LOCK SHIM	$8.72	To Order

Photo	Part No	Description	Price (each)	Stock
	87231900	ENGINE COMPARTMENT LID LOCK SHIM	$14.26	To Order

Photo	Part No	Description	Price (each)	Stock
	87232000	LOCK SPACER	$3.32	To Order

Photo	Part No	Description	Price (each)	Stock
	88158700	SPACER	$4.00	To Order

Photo	Part No	Description	Price (each)	Stock
	85833900	SCREW	$0.36	ARRIVING SOON
	85833900	SCREW	$0.36	ARRIVING SOON

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
1	87413911	COMPL. REAR LID	87413911 COMPL. REAR LID Applicable for USA, CDN	$6,373.90	1
1	87381811	COMPL. REAR LID	87381811 COMPL. REAR LID Not for USA, CDN	$4,258.52	1
2	87624800	ENGINE COMPARTMENT LID HINGE	87624800 ENGINE COMPARTMENT LID HINGE	$286.67	2
3	16286124	SCREW	16286124 SCREW M6 X 20; No longer supplied; Replaced by 16286121	$0.37	8
3	16286121	SCREW	16286121 SCREW M6 X 20	$0.70 MSRP: ~~1.35~~ (48.1% off)	8
4	12647021	WASHER	12647021 WASHER	$0.32	8
5	87667600	RH ENGINE COMPARTMENT LID AIR VENT GRILLE TRIM	87667600 RH ENGINE COMPARTMENT LID AIR VENT GRILLE TRIM	$224.63	1
6	87667500	LH ENGINE COMPARTMENT LID AIR VENT GRILLE TRIM	87667500 LH ENGINE COMPARTMENT LID AIR VENT GRILLE TRIM	$224.63	1
7	87780900	GAS STRUT REAR LID ARRIVING SOON	87780900 GAS STRUT REAR LID ARRIVING SOON	$43.18	2
8	69106400	PIN	69106400 PIN	$2.54	4
9	87667000	COMPL. RH ENGINE COMPARTMENT LID AIR VENT GRILLE	87667000 COMPL. RH ENGINE COMPARTMENT LID AIR VENT GRILLE	$702.02	1
10	87666900	COMPL. LH ENGINE COMPARTMENT LID AIR VENT GRILLE	87666900 COMPL. LH ENGINE COMPARTMENT LID AIR VENT GRILLE	$702.02	1
11	87934400	SPACER	87934400 SPACER Th. 1 mm; No longer supplied	$2.79	2
11	87934500	SPACER	87934500 SPACER Th. 2 mm; No longer supplied	$2.90	2
12	85833900	SCREW ARRIVING SOON	85833900 SCREW M5 X 16 ARRIVING SOON	$0.36	4
13	83467200	LOCK STRIKER	83467200 LOCK STRIKER	$51.59	1
14	87513800	REAR LID HANDLE, COMPL. WITH CABLE	87513800 REAR LID HANDLE, COMPL. WITH CABLE Not for GD	$240.67	1
14	87258800	REAR LID HANDLE, COMPL. WITH CABLE	87258800 REAR LID HANDLE, COMPL. WITH CABLE Applicable for GD	$224.63	1
15	82926600	BRACKET FOR ENGINE COMPARTMENT LID HANDLE	82926600 BRACKET FOR ENGINE COMPARTMENT LID HANDLE Not for GD	$240.67	1
15	83028900	BRACKET FOR ENGINE COMPARTMENT LID HANDLE	83028900 BRACKET FOR ENGINE COMPARTMENT LID HANDLE Applicable for GD	$53.02	1
16	11612826	SCREW	11612826 SCREW M6 X 25	$3.40	1
17	303385	CLIP	303385 CLIP	$0.31	4
18	248061	CLIP	248061 CLIP	$2.22	6
19	303385	CLIP	303385 CLIP	$0.31	1
20	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	$1.51	3
21	113113	WASHER	113113 WASHER	$1.07 MSRP: ~~2.56~~ (58.2% off)	3
22	67161800	VIBRATION DAMPER	67161800 VIBRATION DAMPER	$43.31 MSRP: ~~52.89~~ (18.1% off)	2
23	84076100	ENGINE COMPARTMENT LID LOCK	84076100 ENGINE COMPARTMENT LID LOCK	$141.90	1
24	87231800	ENGINE COMPARTMENT LID LOCK SHIM	87231800 ENGINE COMPARTMENT LID LOCK SHIM Th. 1 mm	$8.72	2
25	87231900	ENGINE COMPARTMENT LID LOCK SHIM	87231900 ENGINE COMPARTMENT LID LOCK SHIM Th. 3 mm	$14.26	1
26	87232000	LOCK SPACER	87232000 LOCK SPACER	$3.32	1
27	88158700	SPACER	88158700 SPACER Applicable until depletion	$4.00	4
28	85833900	SCREW ARRIVING SOON	85833900 SCREW M5 X 16; No longer supplied; Replaced by 85833700 ARRIVING SOON	$0.36	10
28	85833900	SCREW ARRIVING SOON	85833900 SCREW M5 X 14 ARRIVING SOON	$0.36	10
