Name: HIGH POWER BOSE HI FI SYSTEM
Rating: 5.0 (1 reviews)

HIGH POWER BOSE HI FI SYSTEM of Ferrari Ferrari 430 Coupe

View All

Ferrari 430 Coupe - HIGH POWER BOSE HI FI SYSTEM

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	233478	BOSE BASS-BOX AMPLIFIER	$2,223.96	To Order

Photo	Part No	Description	Price (each)	Stock
	14358624	SCREW	$0.16	To Order

Photo	Part No	Description	Price (each)	Stock
	12638107	WASHER	$1.07	To Order

Photo	Part No	Description	Price (each)	Stock
	80409000	BRACKET	$433.23	To Order
	80946800	BRACKET	$288.81	To Order

Photo	Part No	Description	Price (each)	Stock
	80199100	BOSE BASS-BOX SUBSTRUCTURE	$5,035.21	To Order

Photo	Part No	Description	Price (each)	Stock
	80199300	GRILLE	$211.92	To Order

Photo	Part No	Description	Price (each)	Stock
	16085177	SCREW	$2.84	To Order

Photo	Part No	Description	Price (each)	Stock
	68927900	SCREW	$0.24	To Order

Photo	Part No	Description	Price (each)	Stock
	12611107	WASHER	$0.78	To Order

Photo	Part No	Description	Price (each)	Stock
	80569100	RH RECESS	$573.36	To Order
	80569300	LH RECESS	$573.36	To Order

Photo	Part No	Description	Price (each)	Stock
	81591700	SCREW	$2.22	To Order

Photo	Part No	Description	Price (each)	Stock
	10519424	WASHER	$0.02	To Order

Photo	Part No	Description	Price (each)	Stock
	80481600	MOUNTING BRACKET	$641.82	To Order

Photo	Part No	Description	Price (each)	Stock
	80482700	COMPLETE RH TWIDDLER CONTAINER	$893.89	To Order
	80483800	COMPLETE RH TWIDDLER CONTAINER	$1,175.96	To Order
	81129900	COMPLETE RH TWIDDLER CONTAINER	Enquire	To Order

...and 2 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	227270	TWIDDLER	$278.68	To Order

Photo	Part No	Description	Price (each)	Stock
	16082777	SCREW	$1.15	To Order

Photo	Part No	Description	Price (each)	Stock
	80584300	SURROUND FOR TWIDDLER	$372.69	To Order

Photo	Part No	Description	Price (each)	Stock
	68927400	SCREW	$0.66	To Order

Photo	Part No	Description	Price (each)	Stock
	12611107	WASHER	$0.78	To Order

Photo	Part No	Description	Price (each)	Stock
	233479	BOSE 8800 AMPLIFIER	$3,071.19	To Order

Photo	Part No	Description	Price (each)	Stock
	14305321	SCREW	$0.10	To Order

Photo	Part No	Description	Price (each)	Stock
	12643724	WASHER	$0.06	To Order

Photo	Part No	Description	Price (each)	Stock
	192522	BOSE AUDIOPILOT MICROPHONE	$78.61	To Order

Photo	Part No	Description	Price (each)	Stock
	61756800	RIVET	$0.15	To Order

Photo	Part No	Description	Price (each)	Stock
	80552200	CABLE RETAINER BRACKET	$7.59	To Order

Photo	Part No	Description	Price (each)	Stock
	16082977	SCREW	$7.54	To Order

Photo	Part No	Description	Price (each)	Stock
	80554000	GRILLE	$176.49	To Order

Photo	Part No	Description	Price (each)	Stock
	14418924	SCREW	$0.52	To Order

Photo	Part No	Description	Price (each)	Stock
	13550077	WASHER	$3.52	To Order

Photo	Part No	Description	Price (each)	Stock
	80858000	STUD BOLT	$11.73	To Order

Photo	Part No	Description	Price (each)	Stock
	80858100	STUD BOLT	$8.33	To Order

Photo	Part No	Description	Price (each)	Stock
	80858400	MOUNTING	$8.17	To Order

Photo	Part No	Description	Price (each)	Stock
	12577821	NUT	$0.42	To Order

Photo	Part No	Description	Price (each)	Stock
	81017800	GASKET	$11.39	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	233478	BOSE BASS-BOX AMPLIFIER	233478 BOSE BASS-BOX AMPLIFIER	$2,223.96	1
2	14358624	SCREW	14358624 SCREW Applicable up to Ass. No. 74795	$0.16	6
3	12638107	WASHER	12638107 WASHER Applicable up to Ass. No. 74795	$1.07	6
4	80409000	BRACKET	80409000 BRACKET Applicable up to Ass. No. 74795	$433.23	1
4	80946800	BRACKET	80946800 BRACKET Applicable from Ass. No. 74796	$288.81	1
5	80199100	BOSE BASS-BOX SUBSTRUCTURE	80199100 BOSE BASS-BOX SUBSTRUCTURE	$5,035.21	1
6	80199300	GRILLE	80199300 GRILLE	$211.92	1
7	16085177	SCREW	16085177 SCREW	$2.84	6
8	68927900	SCREW	68927900 SCREW M6 X 25	$0.24 MSRP: ~~0.75~~ (68% off)	4
9	12611107	WASHER	12611107 WASHER	$0.78	4
10	80569100	RH RECESS	80569100 RH RECESS	$573.36	1
10	80569300	LH RECESS	80569300 LH RECESS	$573.36	1
11	81591700	SCREW	81591700 SCREW L. 14 mm	$2.22	6
12	10519424	WASHER	10519424 WASHER	$0.02 MSRP: ~~0.25~~ (92% off)	6
13	80481600	MOUNTING BRACKET	80481600 MOUNTING BRACKET	$641.82	2
14	80482700	COMPLETE RH TWIDDLER CONTAINER	80482700 COMPLETE RH TWIDDLER CONTAINER Not for USA, CDN	$893.89	1
14	80483800	COMPLETE RH TWIDDLER CONTAINER	80483800 COMPLETE RH TWIDDLER CONTAINER Applicable for USA, CDN	$1,175.96	1
14	81129900	COMPLETE RH TWIDDLER CONTAINER	81129900 COMPLETE RH TWIDDLER CONTAINER Applicable for vehicles with rollbar	-	1	Enquire
14	80602100	COMPLETE LH TWIDDLER CONTAINER	80602100 COMPLETE LH TWIDDLER CONTAINER	$1,093.30	1
14	81130000	COMPLETE LH TWIDDLER CONTAINER	81130000 COMPLETE LH TWIDDLER CONTAINER Applicable for vehicles with rollbar	-	1	Enquire
15	227270	TWIDDLER	227270 TWIDDLER	$278.68	4
16	16082777	SCREW	16082777 SCREW	$1.15	16
17	80584300	SURROUND FOR TWIDDLER	80584300 SURROUND FOR TWIDDLER	$372.69	4
18	68927400	SCREW	68927400 SCREW	$0.66	16
19	12611107	WASHER	12611107 WASHER	$0.78	16
20	233479	BOSE 8800 AMPLIFIER	233479 BOSE 8800 AMPLIFIER	$3,071.19	1
21	14305321	SCREW	14305321 SCREW	$0.10 MSRP: ~~0.75~~ (86.7% off)	3
22	12643724	WASHER	12643724 WASHER	$0.06 MSRP: ~~0.50~~ (88% off)	3
23	192522	BOSE AUDIOPILOT MICROPHONE	192522 BOSE AUDIOPILOT MICROPHONE	$78.61	1
24	61756800	RIVET	61756800 RIVET	$0.15	2
25	80552200	CABLE RETAINER BRACKET	80552200 CABLE RETAINER BRACKET	$7.59	1
26	16082977	SCREW	16082977 SCREW	$7.54	2
27	80554000	GRILLE	80554000 GRILLE	$176.49	1
28	14418924	SCREW	14418924 SCREW	$0.52	4
29	13550077	WASHER	13550077 WASHER	$3.52	4
30	80858000	STUD BOLT	80858000 STUD BOLT Applicable from Ass. No. 74796	$11.73	2
31	80858100	STUD BOLT	80858100 STUD BOLT Applicable from Ass. No. 74796	$8.33	4
32	80858400	MOUNTING	80858400 MOUNTING Applicable from Ass. No. 74796	$8.17	6
33	12577821	NUT	12577821 NUT Applicable from Ass. No. 74796	$0.42	6
34	81017800	GASKET	81017800 GASKET	$11.39	1
