ELECTRIC SEAT - GUIDES AND ADJUSTMENT MECHANISMS -Optional- of Ferrari Ferrari 430 Coupe

View All

Ferrari 430 Coupe - ELECTRIC SEAT - GUIDES AND ADJUSTMENT MECHANISMS -Optional-

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	66327300	LH GUIDE ASSEMBLY	Enquire	To Order
	66327200	RH GUIDE ASSEMBLY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66323500	UPPER THREADED PLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66327100	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66327900	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66327500	COMPLETE SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66327700	REAR FASTENER BUSHING	Enquire	To Order
	66327600	FRONT FASTENER BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66090400	RH GUIDE COVER	Enquire	To Order
	66090500	LH GUIDE COVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	166168	REAR PLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66328000	CONNECTOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66326100	BOWDEN CABLE SHEATH	Enquire	To Order
	66326000	BACKREST BOLSTER ADJUSTMENT BOWDEN CABLE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66374500	ELECTRIC LUMBAR SUPPORT ADJUSTMENT MECHANISM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66328400	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	69198200	COMPLETE SEAT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66324700	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66324600	RH CLIP	Enquire	To Order
	66370200	LH CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66324100	BACKREST BACKING SHELL TRIM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66324500	SEAT HOOK LEVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66324400	FIXING PLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66324300	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66324200	SEAT RELEASE CABLE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66328800	COMPLETE CONNECTOR BAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66328700	CROWN FASTENER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66327800	BACKREST ADJUSTMENT MOTOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66328500	FASTENER KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66329200	RH SEAT BUTTON PANEL	Enquire	To Order
	66329300	LH SEAT BUTTON PANEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66329400	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66329500	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	80179100	BACKREST WIRING HARNESS	Enquire	To Order
	66329100	BACKREST WIRING HARNESS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	80179500	Cushion Wiring Harness, Passenger Side	Enquire	To Order
	69589700	CUSHION WIRING HARNESS, PASSENGER SIDE	Enquire	To Order
	80179300	CUSHION WIRING HARNESS, PASSENGER SIDE	Enquire	To Order

...and 5 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	65917500	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12601474	WAVY WASHER 10MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64025400	BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64025500	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	69198500	BACKREST STRUCTURE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	69198900	LH CUSHION STRUCTURE	Enquire	To Order
	69198800	RH CUSHION STRUCTURE	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	66327300	LH GUIDE ASSEMBLY	66327300 LH GUIDE ASSEMBLY	-	1	Enquire
1	66327200	RH GUIDE ASSEMBLY	66327200 RH GUIDE ASSEMBLY	-	1	Enquire
2	66323500	UPPER THREADED PLATE	66323500 UPPER THREADED PLATE	-	4	Enquire
3	66327100	SCREW	66327100 SCREW	-	4	Enquire
4	66327900	SCREW	66327900 SCREW	-	8	Enquire
5	66327500	COMPLETE SCREW	66327500 COMPLETE SCREW	-	8	Enquire
6	66327700	REAR FASTENER BUSHING	66327700 REAR FASTENER BUSHING	-	4	Enquire
6	66327600	FRONT FASTENER BUSHING	66327600 FRONT FASTENER BUSHING	-	4	Enquire
7	66090400	RH GUIDE COVER	66090400 RH GUIDE COVER	-	2	Enquire
7	66090500	LH GUIDE COVER	66090500 LH GUIDE COVER	-	2	Enquire
8	166168	REAR PLATE	166168 REAR PLATE	-	4	Enquire
9	66328000	CONNECTOR	66328000 CONNECTOR	-	2	Enquire
10	66326100	BOWDEN CABLE SHEATH	66326100 BOWDEN CABLE SHEATH	-	2	Enquire
10	66326000	BACKREST BOLSTER ADJUSTMENT BOWDEN CABLE	66326000 BACKREST BOLSTER ADJUSTMENT BOWDEN CABLE	-	2	Enquire
11	66374500	ELECTRIC LUMBAR SUPPORT ADJUSTMENT MECHANISM	66374500 ELECTRIC LUMBAR SUPPORT ADJUSTMENT MECHANISM	-	2	Enquire
12	66328400	SCREW	66328400 SCREW	-	4	Enquire
13	69198200	COMPLETE SEAT	69198200 COMPLETE SEAT	-	2	Enquire
14	66324700	CLIP	66324700 CLIP	-	4	Enquire
15	66324600	RH CLIP	66324600 RH CLIP	-	2	Enquire
15	66370200	LH CLIP	66370200 LH CLIP	-	2	Enquire
16	66324100	BACKREST BACKING SHELL TRIM	66324100 BACKREST BACKING SHELL TRIM	-	2	Enquire
17	66324500	SEAT HOOK LEVER	66324500 SEAT HOOK LEVER	-	4	Enquire
18	66324400	FIXING PLATE	66324400 FIXING PLATE	-	4	Enquire
19	66324300	CLIP	66324300 CLIP	-	4	Enquire
20	66324200	SEAT RELEASE CABLE	66324200 SEAT RELEASE CABLE	-	4	Enquire
21	66328800	COMPLETE CONNECTOR BAR	66328800 COMPLETE CONNECTOR BAR	-	2	Enquire
22	66328700	CROWN FASTENER	66328700 CROWN FASTENER	-	4	Enquire
23	66327800	BACKREST ADJUSTMENT MOTOR	66327800 BACKREST ADJUSTMENT MOTOR	-	2	Enquire
24	66328500	FASTENER KIT	66328500 FASTENER KIT	-	2	Enquire
25	66329200	RH SEAT BUTTON PANEL	66329200 RH SEAT BUTTON PANEL	-	1	Enquire
25	66329300	LH SEAT BUTTON PANEL	66329300 LH SEAT BUTTON PANEL	-	1	Enquire
26	66329400	SCREW	66329400 SCREW	-	4	Enquire
27	66329500	NUT	66329500 NUT	-	4	Enquire
28	80179100	BACKREST WIRING HARNESS	80179100 BACKREST WIRING HARNESS Heated seat	-	2	Enquire
28	66329100	BACKREST WIRING HARNESS	66329100 BACKREST WIRING HARNESS	-	2	Enquire
29	80179500	Cushion Wiring Harness, Passenger Side	80179500 Cushion Wiring Harness, Passenger Side Heated seat; Applicable for GD	-	1	Enquire
29	69589700	CUSHION WIRING HARNESS, PASSENGER SIDE	69589700 CUSHION WIRING HARNESS, PASSENGER SIDE Applicable for GD	-	1	Enquire
29	80179300	CUSHION WIRING HARNESS, PASSENGER SIDE	80179300 CUSHION WIRING HARNESS, PASSENGER SIDE Heated seat; Not for GD	-	1	Enquire
29	66329000	CUSHION WIRING HARNESS, PASSENGER SIDE	66329000 CUSHION WIRING HARNESS, PASSENGER SIDE Not for GD	-	1	Enquire
29	80179400	CUSHION WIRING HARNESS, DRIVER SIDE	80179400 CUSHION WIRING HARNESS, DRIVER SIDE Heated seat; Applicable for GD	-	1	Enquire
29	69589600	CUSHION WIRING HARNESS, DRIVER SIDE	69589600 CUSHION WIRING HARNESS, DRIVER SIDE Applicable for GD	-	1	Enquire
29	80179200	CUSHION WIRING HARNESS, DRIVER SIDE	80179200 CUSHION WIRING HARNESS, DRIVER SIDE Heated seat; Not for GD	-	1	Enquire
29	66328900	CUSHION WIRING HARNESS, DRIVER SIDE	66328900 CUSHION WIRING HARNESS, DRIVER SIDE Not for GD	-	1	Enquire
30	65917500	SCREW	65917500 SCREW	-	4	Enquire
31	12601474	WAVY WASHER 10MM	12601474 WAVY WASHER 10MM	-	4	Enquire
32	64025400	BUSHING	64025400 BUSHING	-	4	Enquire
33	64025500	WASHER	64025500 WASHER	-	4	Enquire
34	69198500	BACKREST STRUCTURE	69198500 BACKREST STRUCTURE	-	2	Enquire
35	69198900	LH CUSHION STRUCTURE	69198900 LH CUSHION STRUCTURE	-	1	Enquire
35	69198800	RH CUSHION STRUCTURE	69198800 RH CUSHION STRUCTURE	-	1	Enquire
