Name: FUEL FILLER SEAT
Rating: 4.5 (1 reviews)

FUEL FILLER SEAT of Ferrari Ferrari 296 GTB USA

View All

Ferrari 296 GTB USA - FUEL FILLER SEAT

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	985743913	COMPL. FUEL FILLER FLAP	$286.67	To Order

Photo	Part No	Description	Price (each)	Stock
	985743973	COMPL. CHARGING SOCKET COVER	$286.67	To Order

Photo	Part No	Description	Price (each)	Stock
	749482	COMPL. FUEL FILLER FLAP HINGE	$173.73	To Order
	921685	COMPL. FUEL FILLER FLAP HINGE	$229.33	To Order

Photo	Part No	Description	Price (each)	Stock
	62769800	WASHER	$0.23	To Order

Photo	Part No	Description	Price (each)	Stock
	294780	SCREW	$0.47	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	$1.51	To Order

Photo	Part No	Description	Price (each)	Stock
	833814	RUBBER PAD	$2.07	To Order

Photo	Part No	Description	Price (each)	Stock
	82249400	STRIKER	$8.49	To Order

Photo	Part No	Description	Price (each)	Stock
	84046900	SHIM PLATE	$9.61	To Order

Photo	Part No	Description	Price (each)	Stock
	921324	CHARGE SOCKET CAP ORIENTATION BRACKET	$24.34	To Order
	921324	CHARGE SOCKET CAP ORIENTATION BRACKET	$24.34	To Order

Photo	Part No	Description	Price (each)	Stock
	769131	COMPL. FUEL FILLER FLAP ACTUATOR	$93.80	To Order

Photo	Part No	Description	Price (each)	Stock
	769713	RH EMERGENCY RELEASE CABLE GUIDE TUBE	$130.43	To Order

Photo	Part No	Description	Price (each)	Stock
	769709	LH EMERGENCY RELEASE CABLE GUIDE TUBE	$130.43	To Order

Photo	Part No	Description	Price (each)	Stock
	748925	RUBBER CABLE GROMMET	$2.56	To Order

Photo	Part No	Description	Price (each)	Stock
	85833900	SCREW	$0.36	ARRIVING SOON
	16281827	SCREW	$0.23	To Order

Photo	Part No	Description	Price (each)	Stock
	743978	COMPL. RIGID FUEL DRAIN PIPE	$315.34	To Order

Photo	Part No	Description	Price (each)	Stock
	13000390	Screw Collar	$0.79	To Order

Photo	Part No	Description	Price (each)	Stock
	11625824	SCREW	$0.39	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	$1.51	To Order
	14059290	FLANGED NUT M6	$1.51	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
0001	985743913	COMPL. FUEL FILLER FLAP	985743913 COMPL. FUEL FILLER FLAP	$286.67	1
0002	985743973	COMPL. CHARGING SOCKET COVER	985743973 COMPL. CHARGING SOCKET COVER	$286.67	1
0003	749482	COMPL. FUEL FILLER FLAP HINGE	749482 COMPL. FUEL FILLER FLAP HINGE No longer supplied - Replaced by 921685	$173.73	2
0003	921685	COMPL. FUEL FILLER FLAP HINGE	921685 COMPL. FUEL FILLER FLAP HINGE	$229.33	2
0004	62769800	WASHER	62769800 WASHER	$0.23 MSRP: ~~0.30~~ (23.3% off)	8
0005	294780	SCREW	294780 SCREW M5 X 14	$0.47	8
0006	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	$1.51	2
0007	833814	RUBBER PAD	833814 RUBBER PAD	$2.07	4
0008	82249400	STRIKER	82249400 STRIKER	$8.49	2
0009	84046900	SHIM PLATE	84046900 SHIM PLATE	$9.61	4
0010	921324	CHARGE SOCKET CAP ORIENTATION BRACKET	921324 CHARGE SOCKET CAP ORIENTATION BRACKET	$24.34	1
0010	921324	CHARGE SOCKET CAP ORIENTATION BRACKET	921324 CHARGE SOCKET CAP ORIENTATION BRACKET	$24.34	1
0011	769131	COMPL. FUEL FILLER FLAP ACTUATOR	769131 COMPL. FUEL FILLER FLAP ACTUATOR	$93.80	2
0012	769713	RH EMERGENCY RELEASE CABLE GUIDE TUBE	769713 RH EMERGENCY RELEASE CABLE GUIDE TUBE	$130.43	1
0013	769709	LH EMERGENCY RELEASE CABLE GUIDE TUBE	769709 LH EMERGENCY RELEASE CABLE GUIDE TUBE	$130.43	1
0014	748925	RUBBER CABLE GROMMET	748925 RUBBER CABLE GROMMET	$2.56	2
0015	85833900	SCREW ARRIVING SOON	85833900 SCREW M5 X 16 ARRIVING SOON	$0.36	4
0015	16281827	SCREW	16281827 SCREW M5 X 14	$0.23	4
0016	743978	COMPL. RIGID FUEL DRAIN PIPE	743978 COMPL. RIGID FUEL DRAIN PIPE	$315.34	1
0017	13000390	Screw Collar	13000390 Screw Collar	$0.79 MSRP: ~~2.00~~ (60.5% off)	1
0018	11625824	SCREW	11625824 SCREW M6 X 18	$0.39 MSRP: ~~1.00~~ (61% off)	4
0019	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	$1.51	6
0019	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	$1.51	6
