ROOF of Rolls Royce Rolls Royce Phantom Extended Wheelbase

View All

Rolls Royce Phantom Extended Wheelbase - ROOF

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	41217175768	Roof panel	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41227116230	UPPER APRON	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41327116240	LOWER APRON	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41227116239	REAR WINDOW FRAME UPPER PART	Enquire	To Order
	41327197206	REAR WINDOW FRAME UPPER PART	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41217197225	REAR WINDOW FRAME BOTTOM PART	Enquire	To Order
	41227116275	REAR WINDOW FRAME BOTTOM PART	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41317175755	Roof bow, rear	Enquire	To Order
	41317175756	Roof bow, rear	Enquire	To Order
	41317197275	Roof bow, rear	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	41357116281	Weld pool support, left	Enquire	To Order
	41357116282	Weld pool support, right	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	7146950151	Blind rivet, flat headed	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41317131188	UPPER APRON	Enquire	To Order
	41317197226	UPPER APRON	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41317175767	Bracket, overhead console, centre	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41317175765	Bracket, overhead console, left	Enquire	To Order
	41317175766	Bracket, overhead console, right	Enquire	To Order
	41317197277	Bracket, overhead console, left	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	7149112449	Torx-bolt with washer	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	7129902752	Punch rivet	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	7146950151	Blind rivet, flat headed	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	41217175768	Roof panel	41217175768 Roof panel	-	-	Enquire
2	41227116230	UPPER APRON	41227116230 UPPER APRON	-	-	Enquire
3	41327116240	LOWER APRON	41327116240 LOWER APRON	-	-	Enquire
4	41227116239	REAR WINDOW FRAME UPPER PART	41227116239 REAR WINDOW FRAME UPPER PART	-	-	Enquire
4	41327197206	REAR WINDOW FRAME UPPER PART	41327197206 REAR WINDOW FRAME UPPER PART	-	-	Enquire
5	41217197225	REAR WINDOW FRAME BOTTOM PART	41217197225 REAR WINDOW FRAME BOTTOM PART	-	-	Enquire
5	41227116275	REAR WINDOW FRAME BOTTOM PART	41227116275 REAR WINDOW FRAME BOTTOM PART	-	-	Enquire
6	41227116243	Roof bow, front	41227116243 Roof bow, front	-	-	Enquire
6	41317197215	Roof bow, front	41317197215 Roof bow, front	-	-	Enquire
7	41317175755	Roof bow, rear	41317175755 Roof bow, rear REAR BOW2	-	-	Enquire
7	41317175756	Roof bow, rear	41317175756 Roof bow, rear REAR BOW 3	-	-	Enquire
7	41317197275	Roof bow, rear	41317197275 Roof bow, rear REAR BOW2	-	-	Enquire
7	41317197276	Roof bow, rear	41317197276 Roof bow, rear REAR BOW 3	-	-	Enquire
8	41357116281	Weld pool support, left	41357116281 Weld pool support, left	-	-	Enquire
8	41357116282	Weld pool support, right	41357116282 Weld pool support, right	-	-	Enquire
9	7146950151	Blind rivet, flat headed	7146950151 Blind rivet, flat headed 3,2X8	-	-	Enquire
10	41317131188	UPPER APRON	41317131188 UPPER APRON	-	-	Enquire
10	41317197226	UPPER APRON	41317197226 UPPER APRON	-	-	Enquire
11	41317175767	Bracket, overhead console, centre	41317175767 Bracket, overhead console, centre	-	-	Enquire
12	41317175765	Bracket, overhead console, left	41317175765 Bracket, overhead console, left	-	-	Enquire
12	41317175766	Bracket, overhead console, right	41317175766 Bracket, overhead console, right	-	-	Enquire
12	41317197277	Bracket, overhead console, left	41317197277 Bracket, overhead console, left	-	-	Enquire
12	41317197278	Bracket, overhead console, right	41317197278 Bracket, overhead console, right	-	-	Enquire
13	7149112449	Torx-bolt with washer	7149112449 Torx-bolt with washer	-	-	Enquire
14	7129902752	Punch rivet	7129902752 Punch rivet 5MM	-	-	Enquire
15	7146950151	Blind rivet, flat headed	7146950151 Blind rivet, flat headed 3,2X8	-	-	Enquire
