Name: Valve timing gear camshaft valves
Rating: 4.3 (1 reviews)

View All

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	11311705512	Rectangring	$11.12	To Order

Photo	Part No	Description	Price (each)	Stock
	11348638405	Intake valve	$52.15	To Order

Photo	Part No	Description	Price (each)	Stock
	11348638404	Exhaust valve	$71.75	To Order

Photo	Part No	Description	Price (each)	Stock
	11340053504	Repair kit valve seal ring	$134.34	To Order

Photo	Part No	Description	Price (each)	Stock
	11347572451	Valve spring	$20.93	To Order

Photo	Part No	Description	Price (each)	Stock
	11347614134	Upper spring plate	$12.36	To Order

Photo	Part No	Description	Price (each)	Stock
	11341461405	Valve collet	$2.68	To Order

Photo	Part No	Description	Price (each)	Stock
	11338679835	Compensating element	$41.44	To Order

Photo	Part No	Description	Price (each)	Stock
	11337557284	Roller drag lever	$49.72	To Order

View All

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
1	11317583230	Inlet camshaft	11317583230 Inlet camshaft ZYL. 1-6	$1,599.65	1
1	11317583234	Inlet camshaft	11317583234 Inlet camshaft ZYL. 7-12	$1,599.65	1
2	11311705512	Rectangring	11311705512 Rectangring	$11.12	8
3	11317583232	Outlet camshaft	11317583232 Outlet camshaft ZYL. 1-6	$1,563.68	1
3	11317583236	Outlet camshaft	11317583236 Outlet camshaft ZYL. 7-12	$1,563.68	1
4	11348638405	Intake valve	11348638405 Intake valve D=33,2/5,92MM	$52.15	24
5	11348638404	Exhaust valve	11348638404 Exhaust valve D=29,0/5,92MM	$71.75	24
6	11340053504	Repair kit valve seal ring	11340053504 Repair kit valve seal ring	$134.34	2
7	11347572451	Valve spring	11347572451 Valve spring	$20.93	48
8	11347614134	Upper spring plate	11347614134 Upper spring plate	$12.36	48
9	11341461405	Valve collet	11341461405 Valve collet D=6	$2.68	96
10	11338679835	Compensating element	11338679835 Compensating element	$41.44	48
11	11337557284	Roller drag lever	11337557284 Roller drag lever	$49.72	48
