FUEL TANK

Find Your Part

Maserati 3200 GT / Assetto Corsa - FUEL TANK

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
389201103 FUEL TANK $1,576.21 To Order
389200103 FUEL TANK $3,115.45 To Order
Photo Part No Description Price (each) Stock
383700003 IN-TANK FUEL PUMP $617.63 To Order
Photo Part No Description Price (each) Stock
393750312 FILTER $7.04 To Order
Photo Part No Description Price (each) Stock
383700309 Gasket $15.77 To Order
Photo Part No Description Price (each) Stock
389200446 RING NUT $82.54 To Order
Photo Part No Description Price (each) Stock
389200141 FUEL FILTER $60.11 To Order
Photo Part No Description Price (each) Stock
389200433 UNION $73.66 To Order
Photo Part No Description Price (each) Stock
389200432 UNION $15.24 To Order
Photo Part No Description Price (each) Stock
10280060 WASHER COPPER D14. 20 X 1.5 $1.32 To Order
Photo Part No Description Price (each) Stock
389201009 FUEL INTAKE TUBE $761.85 To Order
389240009 FUEL INTAKE TUBE $197.00 To Order
389220009 FUEL INTAKE TUBE $135.82 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
374091380 CLAMP $2.83 To Order
Photo Part No Description Price (each) Stock
13000790 Screw Collar $2.05 To Order
Photo Part No Description Price (each) Stock
373630111 FUEL LEVEL INDICATOR CONTROL $119.28 To Order
Photo Part No Description Price (each) Stock
33331300 GASKET $3.53 To Order
Photo Part No Description Price (each) Stock
62790300 NUT $0.50 To Order
Photo Part No Description Price (each) Stock
12642878 WASHER $1.55 To Order
Photo Part No Description Price (each) Stock
389200106 STRIP $24.79 To Order
Photo Part No Description Price (each) Stock
319220337 BLOCK $3.53 To Order
Photo Part No Description Price (each) Stock
670000414 SCREW $2.39 To Order
Photo Part No Description Price (each) Stock
670000413 ROD $4.22 To Order
Photo Part No Description Price (each) Stock
670000412 ROD $4.22 To Order
Photo Part No Description Price (each) Stock
389200384 STRIP $18.31 To Order
Photo Part No Description Price (each) Stock
389200520 PIN $10.98 To Order
Photo Part No Description Price (each) Stock
58841309 SAFETY CLIP $5.90 To Order
Photo Part No Description Price (each) Stock
379200398 FELT PAD $4.22 To Order
Photo Part No Description Price (each) Stock
14305324 Allen Screw 6 x 20 $2.05 To Order
Photo Part No Description Price (each) Stock
389201007 FUEL TANK CAP $50.00 To Order
389220007 FUEL TANK CAP $12.40 To Order
389240007 FUEL TANK CAP $45.91 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
383000160 HARNESS $15.47 To Order
Photo Part No Description Price (each) Stock
383300195 FUEL FILLER DOOR ACTUATOR $125.82 To Order
Photo Part No Description Price (each) Stock
135600050 WASHER $1.41 To Order
Photo Part No Description Price (each) Stock
10977624 SCREW $1.97 To Order
Photo Part No Description Price (each) Stock
388100355 RUBBER $12.40 To Order
Photo Part No Description Price (each) Stock
389200348 WASHER $7.61 To Order
View All
FUEL TANK of Maserati Maserati 3200 GT / Assetto Corsa Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 389201103
FUEL TANK
Valid for GS from Ass. Nr.4446 not for Ass. Nr.4491,4499 and 4500 / Valid for GD froml Ass. Nr.4469 not for Ass. Nr.4451 and 4454 		$1,576.21 1
1 389200103
FUEL TANK
Valid for GS till Ass. Nr.4445 and for Ass. Nr.4491,4499 and 4500 / Valid for GD till Ass. Nr.4468 and for Ass. Nr.4451 and 4454 / Valid for BRA and GOL 		$3,115.45 1
2 383700003
IN-TANK FUEL PUMP 		$617.63 2
3 393750312
FILTER 		$7.04 2
4 383700309
Gasket 		$15.77 2
5 389200446
RING NUT 		$82.54 2
6 389200141
FUEL FILTER 		$60.11 1
7 389200433
UNION 		$73.66 1
8 389200432
UNION 		$15.24 1
9 10280060
WASHER COPPER D14. 20 X 1.5 		$1.32 1
10 389201009
FUEL INTAKE TUBE
Not for BRA / Not for GOL / Valid for GS till Ass. Nr.4445 and for Ass. Nr.4491,4499 and 4500 / Valid for GD till Ass. Nr.4468 and for Ass. Nr.4451 and 4454 		$761.85 1
10 389240009
FUEL INTAKE TUBE
Only for BRA 		$197.00 1
10 389220009
FUEL INTAKE TUBE
Only for GOL 		$135.82 1
10 183430
FUEL FILLER NECK ASSEMBLY
Not for BRA / Not for GOL / Valid for GS from Ass. Nr.4446 not for Ass. Nr.4491,4499 and 4500 / Valid for GD froml Ass. Nr.4469 not for Ass. Nr.4451 and 4454 		$487.81 1
11 374091380
CLAMP 		$2.83 1
12 13000790
Screw Collar 		$2.05 1
13 373630111
FUEL LEVEL INDICATOR CONTROL 		$119.28 1
14 33331300
GASKET 		$3.53 1
15 62790300
NUT 		$0.50 6
16 12642878
WASHER 		$1.55 6
17 389200106
STRIP 		$24.79 2
18 319220337
BLOCK 		$3.53 2
19 670000414
SCREW 		$2.39 2
20 670000413
ROD 		$4.22 2
21 670000412
ROD 		$4.22 2
22 389200384
STRIP 		$18.31 2
23 389200520
PIN 		$10.98 (24.2% off) 4
24 58841309
SAFETY CLIP 		$5.90 8
25 379200398
FELT PAD 		$4.22 2
26 14305324
Allen Screw 6 x 20 		$2.05 1
27 389201007
FUEL TANK CAP
Not for BRA / Not for GOL / Valid for GS till Ass. Nr.4445 and for Ass. Nr.4491,4499 and 4500 / Valid for GD till Ass. Nr.4468 and for Ass. Nr.4451 and 4454 		$50.00 1
27 389220007
FUEL TANK CAP
Only for GOL 		$12.40 1
27 389240007
FUEL TANK CAP
Only for BRA 		$45.91 1
27 183432
TANK PLUG
Not for BRA / Not for GOL / Valid for GS from Ass. Nr.4446 not for Ass. Nr.4491,4499 and 4500 / Valid for GD froml Ass. Nr.4469 not for Ass. Nr.4451 and 4454 		$54.94 1
28 383000160
HARNESS 		$15.47 1
29 383300195
FUEL FILLER DOOR ACTUATOR 		$125.82 1
30 135600050
WASHER 		$1.41 2
31 10977624
SCREW 		$1.97 2
32 388100355
RUBBER 		$12.40 1
33 389200348
WASHER 		$7.61 1
