STEERING COLUMN WITH ATTACHMENT PARTS of Lamborghini Lamborghini Urus (2018-2019)

View All

Lamborghini Urus (2018-2019) - STEERING COLUMN WITH ATTACHMENT PARTS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
		STEERING COLUMN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M1419065A	STEERING COLUMN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	3Q0905861C	STEERING COLUMN LOCK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0419378C4PK	RETAINING LEVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		STEERING COLUMN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M1419506AB	STEERING COLUMN OBERT.EVLS LL RDW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	3Q0905861C	STEERING COLUMN LOCK	Enquire	To Order
	80A907705	CONTROL UNIT FOR ELECTRICALLY ADJUSTABLE STEERING COLUMN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		CONTROL UNIT FOR ELECTRICALLY ADJUSTABLE STEERING COLUMN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4F0937733B	FLAT CONTACT HOUSING WITH CONTACT LOCKING MECHANISM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M1419753C	INTERMEDIATE STEERING SHAFT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0419119A	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10430103	HEXAGON SOCKET FLAT HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10739301	FILLISTER HD. BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		TORX SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91173301	HEX. NUT WITH WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		HEX COLLARED BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10518405	SOCKET HEAD BOLT WITH MULTI- POINT INNER DRIVE, SELF-LOCK.	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10665001	FLAT HEAD MULTI-POINT SOCKET BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M1805673A	GROMMET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		SCREW	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	-	STEERING COLUMN	STEERING COLUMN NOT AVAILABLE - SEE REFERENCE 2- LHD	-	-	Enquire
2	4M1419065A	STEERING COLUMN	4M1419065A STEERING COLUMN MANUAL AXIAL AND TILTING ADJUSTMENT- LHD	-	1	Enquire
3	3Q0905861C	STEERING COLUMN LOCK	3Q0905861C STEERING COLUMN LOCK	-	1	Enquire
4	4M0419378C4PK	RETAINING LEVER	4M0419378C4PK RETAINING LEVER SOUL (BLACK)	-	1	Enquire
5	-	STEERING COLUMN	STEERING COLUMN NOT AVAILABLE- LHD	-	-	Enquire
6	4M1419506AB	STEERING COLUMN OBERT.EVLS LL RDW	4M1419506AB STEERING COLUMN OBERT.EVLS LL RDW ELECTRICAL AXIAL AND TILTING ADJUSTMENT- LHD	-	1	Enquire
7	3Q0905861C	STEERING COLUMN LOCK	3Q0905861C STEERING COLUMN LOCK	-	1	Enquire
7	80A907705	CONTROL UNIT FOR ELECTRICALLY ADJUSTABLE STEERING COLUMN	80A907705 CONTROL UNIT FOR ELECTRICALLY ADJUSTABLE STEERING COLUMN	-	-	Enquire
8	-	CONTROL UNIT FOR ELECTRICALLY ADJUSTABLE STEERING COLUMN	CONTROL UNIT FOR ELECTRICALLY ADJUSTABLE STEERING COLUMN SEE ILLUSTRATION : 959.01	-	-	Enquire
9	4F0937733B	FLAT CONTACT HOUSING WITH CONTACT LOCKING MECHANISM	4F0937733B FLAT CONTACT HOUSING WITH CONTACT LOCKING MECHANISM 10 PIN RED	-	1	Enquire
10	4M1419753C	INTERMEDIATE STEERING SHAFT	4M1419753C INTERMEDIATE STEERING SHAFT LHD- LHD	-	1	Enquire
11	-	CLIP	CLIP NOT AVAILABLE	-	-	Enquire
12	4M0419119A	CLIP	4M0419119A CLIP	-	1	Enquire
13	N10430103	HEXAGON SOCKET FLAT HEAD BOLT	N10430103 HEXAGON SOCKET FLAT HEAD BOLT M5X16	-	1	Enquire
14	N10739301	FILLISTER HD. BOLT	N10739301 FILLISTER HD. BOLT M6X10	-	1	Enquire
15	-	TORX SCREW	TORX SCREW SEE REF 13	-	-	Enquire
16	N91173301	HEX. NUT WITH WASHER	N91173301 HEX. NUT WITH WASHER	-	2	Enquire
17	-	HEX COLLARED BOLT	HEX COLLARED BOLT NOT AVAILABLE	-	-	Enquire
18	N10518405	SOCKET HEAD BOLT WITH MULTI- POINT INNER DRIVE, SELF-LOCK.	N10518405 SOCKET HEAD BOLT WITH MULTI- POINT INNER DRIVE, SELF-LOCK. M8X30	-	1	Enquire
19	N10665001	FLAT HEAD MULTI-POINT SOCKET BOLT	N10665001 FLAT HEAD MULTI-POINT SOCKET BOLT M8X30	-	4	Enquire
20	4M1805673A	GROMMET	4M1805673A GROMMET	-	1	Enquire
21	-	SCREW	SCREW NOT AVAILABLE	-	-	Enquire
