View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
001	86301047B	BREATHER PIPE	86301047B BREATHER PIPE	$94.89	1
002	86301051D	MANUAL TRANSMISSION CASE	86301051D MANUAL TRANSMISSION CASE	$4,509.41	1
003	86301141	MAGNETIC PLUG	86301141 MAGNETIC PLUG	$26.89	1
004	86301153B	DOWEL SLEEVE	86301153B DOWEL SLEEVE	$5.72	6
005	86301201F	COVER	86301201F COVER	$2,103.51	1
006	86301293B	PLATE	86301293B PLATE	$1,010.76	1
007	86323209F	CLUTCH HOUSING	86323209F CLUTCH HOUSING	$5,376.36	1
008	86927321	TIMING SENSOR	86927321 TIMING SENSOR	$121.40	2
012	N01100845	HEXAGON NUT IN STOCK	N01100845 HEXAGON NUT IN STOCK	$1.89	3
013	N0115581	ROSETTE	N0115581 ROSETTE	$0.40	3
014	N0115581	ROSETTE	N0115581 ROSETTE	$0.40	3
015	N0138271	SEAL RING IN STOCK	N0138271 SEAL RING IN STOCK	$3.40 MSRP: ~~7.16~~ (52.5% off)	2
016	N0147151	SCREW	N0147151 SCREW	$1.96	3
017	N91071801	HEX COLLARED BOLT	N91071801 HEX COLLARED BOLT	$3.51	12
018	N10338903	SCREW M6X16	N10338903 SCREW M6X16	$52.74	2
019	N90173302	SCREW	N90173302 SCREW	$4.78	10
020	WHT001492	O-RING	WHT001492 O-RING	$4.58	5
021	86301114A	PLUG	86301114A PLUG	$21.57	1
023	7L301155	DOWEL	7L301155 DOWEL	$57.68	2
024	N91028801	O-RING	N91028801 O-RING	$2.96	1
