Front Arms of Lamborghini Lamborghini Gallardo (2006-2007)

View All

Lamborghini Gallardo (2006-2007) - Front Arms

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	400407379	0.5 MM SHIM	Enquire	To Order
	400407379B	1.5 MM SHIM	Enquire	To Order
	400407379C	2 MM SHIM	Enquire	To Order

...and 4 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	400407313	JOURNAL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10314503	SCREW (UNTIL THE VIN 6LA63288)	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	400411317A	CONNECTING ROD (TO BE USED WITH 400407750A REF. 25 UNTIL THE VIN 1109)	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10286102	NUT (UNTIL THE VIN 6LA03288)	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91062001	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N90323704	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	400407152B	RH Lower Arm	Enquire	To Order
	400407151B	LH Lower Arm	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	400407171B	BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	400505179B	SPACER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	400419121A	BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	400419811A	Ball Joint Coupling	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	400407750A	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT000915	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT000919	WASHER	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
01	N90323704	NUT	N90323704 NUT	-	2	Enquire
02	400407506B	RH UPPER ARM	400407506B RH UPPER ARM	-	1	Enquire
02	400407505B	LH UPPER ARM	400407505B LH UPPER ARM	-	1	Enquire
03	N90226404	HEXAGON COLLAR NUT SELF-LOCKING	N90226404 HEXAGON COLLAR NUT SELF-LOCKING	-	16	Enquire
04	N91062101	STUD BOLT	N91062101 STUD BOLT	-	8	Enquire
05	WHT001197A	WASHER	WHT001197A WASHER	-	4	Enquire
06	400411031G	STAB. BAR BRACKET (UP TO VIN 4LA01398 - ALSO USE 400411324C)	400411031G STAB. BAR BRACKET (UP TO VIN 4LA01398 - ALSO USE 400411324C)	-	2	Enquire
06	400411031C	STAB. BAR BRACKET (FROM VIN 4LA01399)	400411031C STAB. BAR BRACKET (FROM VIN 4LA01399)	-	2	Enquire
07	400411324C	BUSHING (UNTIL THE VIN 6LA03288)	400411324C BUSHING (UNTIL THE VIN 6LA03288)	-	2	Enquire
08	400411309A	FRONT STABILIZER BAR (FROM VIN 4LA01399)	400411309A FRONT STABILIZER BAR (FROM VIN 4LA01399)	-	1	Enquire
08	400411309	FRONT STABILIZER BAR (UNTIL THE VIN 4LA01398)	400411309 FRONT STABILIZER BAR (UNTIL THE VIN 4LA01398)	-	1	Enquire
09	N10470703	ROUND HD. SCREW	N10470703 ROUND HD. SCREW	-	4	Enquire
10	400407379	0.5 MM SHIM	400407379 0.5 MM SHIM	-	16	Enquire
10	400407379B	1.5 MM SHIM	400407379B 1.5 MM SHIM	-	16	Enquire
10	400407379C	2 MM SHIM	400407379C 2 MM SHIM	-	16	Enquire
10	400407379E	3 MM SHIM	400407379E 3 MM SHIM	-	16	Enquire
10	400407379D	2.5 MM SHIM	400407379D 2.5 MM SHIM	-	16	Enquire
10	400407379A	1 MM SHIM	400407379A 1 MM SHIM	-	16	Enquire
10	400407379F	0.3 MM SHIM	400407379F 0.3 MM SHIM	-	16	Enquire
11	400407313	JOURNAL	400407313 JOURNAL	-	2	Enquire
12	N10314503	SCREW (UNTIL THE VIN 6LA63288)	N10314503 SCREW (UNTIL THE VIN 6LA63288)	-	2	Enquire
14	400411317A	CONNECTING ROD (TO BE USED WITH 400407750A REF. 25 UNTIL THE VIN 1109)	400411317A CONNECTING ROD (TO BE USED WITH 400407750A REF. 25 UNTIL THE VIN 1109)	-	2	Enquire
15	N10286102	NUT (UNTIL THE VIN 6LA03288)	N10286102 NUT (UNTIL THE VIN 6LA03288)	-	4	Enquire
18	N91062001	STUD BOLT	N91062001 STUD BOLT	-	8	Enquire
19	N90323704	NUT	N90323704 NUT	-	4	Enquire
20	400407152B	RH Lower Arm	400407152B RH Lower Arm	-	1	Enquire
20	400407151B	LH Lower Arm	400407151B LH Lower Arm	-	1	Enquire
21	400407171B	BUSHING	400407171B BUSHING	-	2	Enquire
22	400505179B	SPACER	400505179B SPACER	-	2	Enquire
23	400419121A	BUSHING	400419121A BUSHING	-	1	Enquire
24	400419811A	Ball Joint Coupling	400419811A Ball Joint Coupling	-	2	Enquire
25	400407750A	SCREW	400407750A SCREW	-	2	Enquire
35	WHT000915	NUT	WHT000915 NUT	-	2	Enquire
36	WHT000919	WASHER	WHT000919 WASHER	-	2	Enquire
