Rear Drive Shaft

Lamborghini Gallardo (2008)

Find Your Part

Lamborghini Gallardo (2008) - Rear Drive Shaft

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Rear Drive Shaft of Lamborghini Lamborghini Gallardo (2008) Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
000 R1400150
REAR DRIVE SHAFTS SCREWS KIT 		- 1 Enquire
001 WHT006779
12 POINT SOCKET SHOULDERED NUT SELF-LOCKING 		- 2 Enquire
002 400501652
HUB 		- 2 Enquire
003 4E0407625F
DOUBLE (ANGLED) BALL BEARING WITH FLANGE 		- 2 Enquire
004 WHT000237
BALL SCREW 		- 8 Enquire
006 400615381
LH BRACKET 		- 1 Enquire
006 400615382
RH BRACKET 		- 1 Enquire
007 WHT001331A
SCREW 		- 12 Enquire
008 7L0407357B
SPACER 		- 6 Enquire
009 420501204A
RH Rear Omokinetic Drive Shaft 		- 1 Enquire
009 420501203A
LH REAR OMOKINETIC DRIVE SHAFT 		- 1 Enquire
010 4E0927803F
SPEED SENSOR 		- 1 Enquire
010 4E0927804F
SPEED SENSOR 		- 1 Enquire
011 N01474011
SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD 		- 2 Enquire
012 400505434
REAR RIGHT HUB CARRIER 		- 1 Enquire
012 400505433
REAR LEFT HUB CARRIER 		- 1 Enquire
012 400505433B
REAR LEFT HUB CARRIER (CARBOCERAMIC BRAKE) 		- 1 Enquire
012 400505434B
REAR RIGHT HUB CARRIER (CARBOCERAMIC BRAKE) 		- 1 Enquire
013 400501226
SPACER RING 		- 2 Enquire
015 400498099C
KIT AXELSHAFT REAR INNER 		- 2 Enquire
016 400498099B
KIT AXELSHAFT REAR OUTER 		- 2 Enquire
