Lamborghini Diablo VT 6.0 (2000-2001) - Climate Control (Valid for GB & Australia - March 2001) 1

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	8831524	STRAP	8831524 STRAP (Valid for GB & AUSTRALIA - March 2001)	-	8	Enquire
002	45007992	PIPE	45007992 PIPE (Valid for GB & AUSTRALIA - March 2001)	-	1	Enquire
003	410819377	CONNECTOR	410819377 CONNECTOR (Valid for GB & AUSTRALIA - March 2001)	-	1	Enquire
004	N01118312	HEXAGON NUT, SELF-LOCKING	N01118312 HEXAGON NUT, SELF-LOCKING (Valid for GB & AUSTRALIA - March 2001)	-	3	Enquire
005	8834401	CLAMP	8834401 CLAMP (Valid for GB & AUSTRALIA - March 2001)	-	2	Enquire
006	45006942	PIPE	45006942 PIPE (Valid for GB & AUSTRALIA - March 2001)	-	1	Enquire
007	45007993	PIPE	45007993 PIPE (Valid for GB & AUSTRALIA - March 2001)	-	1	Enquire
008	45006135	PUMP	45006135 PUMP (Valid for GB & AUSTRALIA - March 2001)	-	1	Enquire
009	410260155	SOLENOID VALVE	410260155 SOLENOID VALVE (Valid for GB & AUSTRALIA - March 2001)	-	1	Enquire
010	45006941	PIPE	45006941 PIPE (Valid for GB & AUSTRALIA - March 2001)	-	1	Enquire
011	45006945	PIPE	45006945 PIPE (Valid for GB & AUSTRALIA - March 2001)	-	1	Enquire
012	6231411	PIPE	6231411 PIPE (Valid for GB & AUSTRALIA - March 2001) (Not valid for USA or CANADA)	-	1	Enquire
013	8830128	CLAMP	8830128 CLAMP (Valid for GB & AUSTRALIA - March 2001) (Not valid for USA or CANADA)	-	2	Enquire
014	1323406	VACUUM TANK	1323406 VACUUM TANK (Valid for GB & AUSTRALIA - March 2001) (Not valid for USA or CANADA)	-	1	Enquire
015	N90319404	SCREW	N90319404 SCREW (Valid for GB & AUSTRALIA - March 2001) (Not valid for USA or CANADA)	-	2	Enquire
016	8700614	SCREW	8700614 SCREW (Valid for GB & AUSTRALIA - March 2001)	-	2	Enquire
017	8410611	WASHER	8410611 WASHER (Valid for GB & AUSTRALIA - March 2001)	-	2	Enquire
018	WHT002961	WASHER	WHT002961 WASHER (Valid for GB & AUSTRALIA - March 2001)	-	2	Enquire
019	N90327506	SPEED NUT	N90327506 SPEED NUT (Valid for GB & AUSTRALIA - March 2001)	-	2	Enquire
020	63700313	GASKET	63700313 GASKET (Valid for GB & AUSTRALIA - March 2001)	-	2	Enquire
021	45001234	A/C CONDENSER	45001234 A/C CONDENSER (Valid for GB & AUSTRALIA - March 2001)	-	1	Enquire
022	45006131	PIPE	45006131 PIPE (Valid for GB & AUSTRALIA - March 2001)	-	1	Enquire
023	WHT002961	WASHER	WHT002961 WASHER (Valid for GB & AUSTRALIA - March 2001)	-	4	Enquire
024	8410611	WASHER	8410611 WASHER (Valid for GB & AUSTRALIA - March 2001)	-	4	Enquire
025	8700614	SCREW	8700614 SCREW (Valid for GB & AUSTRALIA - March 2001)	-	4	Enquire
026	45006130	PIPE	45006130 PIPE (Valid for GB & AUSTRALIA - March 2001)	-	1	Enquire
027	8700542	SCREW	8700542 SCREW (Valid for GB & AUSTRALIA - March 2001)	-	1	Enquire
028	45003629	FILTER	45003629 FILTER (Valid for GB & AUSTRALIA - March 2001)	-	1	Enquire
029	4531395	STRAP	4531395 STRAP (Valid for GB & AUSTRALIA - March 2001)	-	1	Enquire
030	N0211963	NUT	N0211963 NUT (Valid for GB & AUSTRALIA - March 2001)	-	1	Enquire
031	N90179103	WASHER 18X8,4X2,5	N90179103 WASHER 18X8,4X2,5 (Valid for GB & AUSTRALIA - March 2001)	-	2	Enquire
032	N0111849	NUT	N0111849 NUT (Valid for GB & AUSTRALIA - March 2001)	-	2	Enquire
033	8834401	CLAMP	8834401 CLAMP (Valid for GB & AUSTRALIA - March 2001)	-	6	Enquire
034	45007990	PIPE	45007990 PIPE (Valid for GB & AUSTRALIA - March 2001)	-	1	Enquire
035	N01118312	HEXAGON NUT, SELF-LOCKING	N01118312 HEXAGON NUT, SELF-LOCKING (Valid for GB & AUSTRALIA - March 2001)	-	8	Enquire
036	45007991	PIPE	45007991 PIPE (Valid for GB & AUSTRALIA - March 2001)	-	1	Enquire
