Name: OUTER COMPONENTS FOR GEARBOX
Rating: 4.4 (1 reviews)

OUTER COMPONENTS FOR GEARBOX of Lamborghini Lamborghini Aventador LP770 SVJ Coupe

View All

Lamborghini Aventador LP770 SVJ Coupe - OUTER COMPONENTS FOR GEARBOX

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	470398008L	SHAFT	$4,724.46	To Order

Photo	Part No	Description	Price (each)	Stock
	470398008K	BAFFLE PLATE	$18.71	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311230B	BEARING SHELL	$260.09	To Order

Photo	Part No	Description	Price (each)	Stock
		BALL BEARING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311467	OUTPUT GEAR	$217.07	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311250A	OUTPUT GEAR	$2,177.41	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311439	NEEDLE CAGE	$103.78	To Order

Photo	Part No	Description	Price (each)	Stock
	CE301155	GROMMET	$329.30	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311759	SYNCHRONIZING HUB	$3,870.96	To Order

Photo	Part No	Description	Price (each)	Stock
	CE315167	BEARING SLEEVE	$364.26	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311532	OUTPUT GEAR	$1,989.24	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311440	NEEDLE CAGE	$379.04	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311626	LENGTH-MEASURING DEVICE	$135.08	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311145	OUTPUT GEAR	$2,002.69	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311423	BUSH	$321.93	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311241	SYNCHRONIZER RING	$4,173.38	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311228	NEEDLE CAGE	$90.47	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311270	OUTPUT GEAR	$2,231.18	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311530B	SHIFT ROD WITH SHIFTING JOINT	$455.66	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311820B	SELECTOR SHAFT	$3,608.88	To Order

Photo	Part No	Description	Price (each)	Stock
		SQUARE WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		REDUCTION GEARBOX	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		CYLINDER ROLLER BEARING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311615B	OUTPUT GEAR	$952.95	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311380A	LENGTH-MEASURING DEVICE	$345.43	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311165	OUTPUT GEAR	$893.84	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311153B	OUTPUT GEAR	$1,040.31	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311470B	LENGTH-MEASURING DEVICE	$369.64	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311285A	OUTPUT GEAR	$1,411.29	To Order

Photo	Part No	Description	Price (each)	Stock
	CE311235A	SHOULDERED WASHER	$206.32	To Order

Photo	Part No	Description	Price (each)	Stock
		BEARING SHELL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		BEARING RING FOR DIFFERENTIAL	Enquire	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	470398008L	SHAFT	470398008L SHAFT	$4,724.46	1
2	470398008K	BAFFLE PLATE	470398008K BAFFLE PLATE	$18.71	-
3	CE311230B	BEARING SHELL	CE311230B BEARING SHELL	$260.09	-
4	-	BALL BEARING	BALL BEARING 301-020,02	-	-	Enquire
5	CE311467	OUTPUT GEAR	CE311467 OUTPUT GEAR	$217.07	1
6	CE311250A	OUTPUT GEAR	CE311250A OUTPUT GEAR	$2,177.41	-
7	CE311439	NEEDLE CAGE	CE311439 NEEDLE CAGE	$103.78	-
8	CE301155	GROMMET	CE301155 GROMMET	$329.30	1
9	CE311759	SYNCHRONIZING HUB	CE311759 SYNCHRONIZING HUB	$3,870.96	-
10	CE315167	BEARING SLEEVE	CE315167 BEARING SLEEVE	$364.26	1
11	CE311532	OUTPUT GEAR	CE311532 OUTPUT GEAR	$1,989.24	-
12	CE311440	NEEDLE CAGE	CE311440 NEEDLE CAGE	$379.04	-
13	CE311626	LENGTH-MEASURING DEVICE	CE311626 LENGTH-MEASURING DEVICE	$135.08	-
14	CE311145	OUTPUT GEAR	CE311145 OUTPUT GEAR	$2,002.69	-
15	CE311423	BUSH	CE311423 BUSH	$321.93	1
16	CE311241	SYNCHRONIZER RING	CE311241 SYNCHRONIZER RING	$4,173.38	-
17	CE311228	NEEDLE CAGE	CE311228 NEEDLE CAGE	$90.47	-
18	CE311270	OUTPUT GEAR	CE311270 OUTPUT GEAR	$2,231.18	-
19	CE311530B	SHIFT ROD WITH SHIFTING JOINT	CE311530B SHIFT ROD WITH SHIFTING JOINT	$455.66	1
20	CE311820B	SELECTOR SHAFT	CE311820B SELECTOR SHAFT	$3,608.88	1
21	-	SQUARE WASHER	SQUARE WASHER 301-030,02	-	-	Enquire
22	-	SCREW	SCREW 301-030,02	-	-	Enquire
23	-	REDUCTION GEARBOX	REDUCTION GEARBOX 301-030,01	-	-	Enquire
24	-	CYLINDER ROLLER BEARING	CYLINDER ROLLER BEARING 301-020,02	-	-	Enquire
25	CE311615B	OUTPUT GEAR	CE311615B OUTPUT GEAR	$952.95	1
26	CE311380A	LENGTH-MEASURING DEVICE	CE311380A LENGTH-MEASURING DEVICE	$345.43	-
27	CE311165	OUTPUT GEAR	CE311165 OUTPUT GEAR	$893.84	1
28	CE311153B	OUTPUT GEAR	CE311153B OUTPUT GEAR	$1,040.31	1
29	CE311470B	LENGTH-MEASURING DEVICE	CE311470B LENGTH-MEASURING DEVICE	$369.64	-
30	CE311285A	OUTPUT GEAR	CE311285A OUTPUT GEAR	$1,411.29	1
31	CE311235A	SHOULDERED WASHER	CE311235A SHOULDERED WASHER	$206.32	-
32	-	BEARING SHELL	BEARING SHELL 301-020,02	-	-	Enquire
33	-	BEARING RING FOR DIFFERENTIAL	BEARING RING FOR DIFFERENTIAL 301-030,01	-	-	Enquire
