Outer Components For Gearbox

Lamborghini Aventador LP770 SVJ Coupe

Find Your Part

Lamborghini Aventador LP770 SVJ Coupe - OUTER COMPONENTS FOR GEARBOX

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
OUTER COMPONENTS FOR GEARBOX of Lamborghini Lamborghini Aventador LP770 SVJ Coupe Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 470398008J
SHAFT 		- 1 Enquire
2 470398008G
1 SET: SEALING BEARINGS 		- 1 Enquire
3 CE311357C
LENGTH-MEASURING DEVICE 		- 1 Enquire
4 BALL BEARING
301-020,02 		- - Enquire
5 RING
301-020,01 		- - Enquire
6 MAIN SHAFT
301-020,01 		- - Enquire
7 BEARING RING FOR DIFFERENTIAL
301-020,01 		- - Enquire
8 CYLINDER ROLLER BEARING
40X80X18 301-020,02 		- - Enquire
9 CE311256B
GUIDE WHEEL 		- 1 Enquire
10 CE311931
NEEDLE CAGE 		- - Enquire
11 CE311693B
GROMMET 		- 1 Enquire
12 CE311576B
SHIFT ROD WITH SHIFTING JOINT 		- 1 Enquire
13 CE311536B
SHIFT ROD WITH SHIFTING JOINT 		- 1 Enquire
14 CE311301
SYNCHRONIZER RING 		- - Enquire
15 CE311150
NEEDLE CAGE 		- - Enquire
16 CE311389B
GUIDE WHEEL 		- 1 Enquire
17 CE311689C
BUSH 		- 1 Enquire
18 CE311361B
GUIDE WHEEL 		- 1 Enquire
19 CE311279C
GROMMET 		- 1 Enquire
20 CE311310
SYNCHRONIZER RING 		- - Enquire
21 CE311353B
GUIDE WHEEL 		- 1 Enquire
22 CE311427A
NEEDLE CAGE 		- - Enquire
23 CE311533D
GROMMET 		- 1 Enquire
24 CYLINDER ROLLER BEARING
30X62X16 301-020,02 		- - Enquire
25 BEARING SHELL
301-020,02 		- - Enquire
26 CYLINDER ROLLER BEARING
301-020,02 		- - Enquire
