Name: ROOF
Rating: 4.6 (1 reviews)

View All

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	985830112	ROOF TRIM PANEL	$14,500.84	To Order

Photo	Part No	Description	Price (each)	Stock
	985838305	UPPER WINDSCREEN CROSS MEMBER	$1,089.41	To Order

Photo	Part No	Description	Price (each)	Stock
	985838303	UPPER REAR SCREEN CROSS MEMBER	$817.05	To Order

Photo	Part No	Description	Price (each)	Stock
	852496	RH PARTITION	$54.46	To Order

Photo	Part No	Description	Price (each)	Stock
	852495	LH PARTITION	$54.46	To Order

Photo	Part No	Description	Price (each)	Stock
	985573	SCREW	$7.54	To Order

Photo	Part No	Description	Price (each)	Stock
	964589	SCREW	$2.14	To Order

Photo	Part No	Description	Price (each)	Stock
	964589	SCREW	$2.14	To Order

Photo	Part No	Description	Price (each)	Stock
	964587	SCREW	$19.58	To Order

Photo	Part No	Description	Price (each)	Stock
	917020	TOP TETHER FASTENER BRACKET	$65.92	To Order

Photo	Part No	Description	Price (each)	Stock
	878133	SCREW	$16.65	To Order

Photo	Part No	Description	Price (each)	Stock
	14496527	WASHER	$1.26	To Order

View All

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
0001	985830112	ROOF TRIM PANEL	985830112 ROOF TRIM PANEL Request ASM authorisation	$14,500.84	1
0002	985838305	UPPER WINDSCREEN CROSS MEMBER	985838305 UPPER WINDSCREEN CROSS MEMBER	$1,089.41	1
0003	985838303	UPPER REAR SCREEN CROSS MEMBER	985838303 UPPER REAR SCREEN CROSS MEMBER	$817.05	1
0004	741154	REAR SCREEN ASSEMBLY	741154 REAR SCREEN ASSEMBLY Version for 3-point seat belts - Request ASM authorisation	$7,455.39	1
0004	741153	REAR SCREEN ASSEMBLY	741153 REAR SCREEN ASSEMBLY Version for 4-point seat harnesses - Request ASM authorisation	$11,344.36	1
0004	743143	REAR SCREEN ASSEMBLY	743143 REAR SCREEN ASSEMBLY Version for 3-point seat belts - Request ASM authorisation	$8,453.07	1
0005	852496	RH PARTITION	852496 RH PARTITION	$54.46	1
0006	852495	LH PARTITION	852495 LH PARTITION	$54.46	1
0007	985573	SCREW	985573 SCREW M8 X 28	$7.54	4
0008	964589	SCREW	964589 SCREW M6 X 16	$2.14	7
0009	964589	SCREW	964589 SCREW M6 X 16	$2.14	7
0010	964587	SCREW	964587 SCREW M6 X 18	$19.58	4
0011	917020	TOP TETHER FASTENER BRACKET	917020 TOP TETHER FASTENER BRACKET	$65.92	1
0012	878133	SCREW	878133 SCREW M8 X 35	$16.65	2
0013	14496527	WASHER	14496527 WASHER	$1.26	2
