REAR SUSPENSION - ARMS of Ferrari Ferrari Purosangue USA

View All

Ferrari Purosangue USA - REAR SUSPENSION - ARMS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	800828	COMPL. LH REAR HUB CARRIER	Enquire	To Order
	800829	COMPL. RH REAR HUB CARRIER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	971876	COMPL. LOWER LH REAR ARM	Enquire	To Order
	971905	COMPL. LOWER RH REAR ARM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	950508	LH ACTUATOR	Enquire	To Order
	950509	RH ACTUATOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	15541434	SCREW	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	14496721	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	203666	NUT M12	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	302406	THREADED ROD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13578321	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14496524	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	104030	NYLOC NUT M8 X 1.25 X 9.5	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	859105	LH REAR SENSOR BRACKET	Enquire	To Order
	859109	RH REAR SENSOR BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12642701	Washer	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	741924	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	833066	ACTUATOR CABLE FASTENER BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	81911600	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	883878	COMPL. REAR UPPER ARM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	264528	THREADED ROD 10 X 1.25	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	312826	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14496624	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	104114	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	250657	SCREW M6 X 14	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	338394	LH REAR JOINT BRACKET	Enquire	To Order
	338395	RH REAR JOINT BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13046011	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	336026	ABS SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	942843	LH ABS CABLE BRACKET	Enquire	To Order
	942906	RH ABS CABLE BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	259688	ANTI-ROTATION LINKAGE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	238258	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	222956	COMPENSATOR RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	238656	SPECIAL SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	238063	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	896438	THREADED ROD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	888754	ADJUSTER SHIM	Enquire	To Order
	888755	ADJUSTER SHIM	Enquire	To Order
	888756	ADJUSTER SHIM	Enquire	To Order

...and 5 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	969297	ADJUSTMENT SHIM	Enquire	To Order
	969298	ADJUSTMENT SHIM	Enquire	To Order
	969299	ADJUSTMENT SHIM	Enquire	To Order

...and 5 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	13507434	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148020	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	984045	COMPL. TRAVEL SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	216973	BALL JOINT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16284934	FLANGED SCREW	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
0001	800828	COMPL. LH REAR HUB CARRIER	800828 COMPL. LH REAR HUB CARRIER	-	1	Enquire
0001	800829	COMPL. RH REAR HUB CARRIER	800829 COMPL. RH REAR HUB CARRIER	-	1	Enquire
0002	971876	COMPL. LOWER LH REAR ARM	971876 COMPL. LOWER LH REAR ARM	-	1	Enquire
0002	971905	COMPL. LOWER RH REAR ARM	971905 COMPL. LOWER RH REAR ARM	-	1	Enquire
0003	950508	LH ACTUATOR	950508 LH ACTUATOR	-	1	Enquire
0003	950509	RH ACTUATOR	950509 RH ACTUATOR	-	1	Enquire
0004	15541434	SCREW ARRIVING SOON	15541434 SCREW M12 X 1.25 X 80 ARRIVING SOON	-	4	Enquire
0005	14496721	WASHER	14496721 WASHER	-	6	Enquire
0006	203666	NUT M12 ARRIVING SOON	203666 NUT M12 ARRIVING SOON	-	4	Enquire
0007	302406	THREADED ROD	302406 THREADED ROD	-	4	Enquire
0008	13578321	WASHER	13578321 WASHER	-	4	Enquire
0009	14496524	WASHER	14496524 WASHER	-	4	Enquire
0010	104030	NYLOC NUT M8 X 1.25 X 9.5	104030 NYLOC NUT M8 X 1.25 X 9.5	-	4	Enquire
0011	859105	LH REAR SENSOR BRACKET	859105 LH REAR SENSOR BRACKET	-	1	Enquire
0011	859109	RH REAR SENSOR BRACKET	859109 RH REAR SENSOR BRACKET	-	1	Enquire
0012	12642701	Washer	12642701 Washer	-	2	Enquire
0013	741924	NUT	741924 NUT	-	2	Enquire
0014	833066	ACTUATOR CABLE FASTENER BRACKET	833066 ACTUATOR CABLE FASTENER BRACKET	-	2	Enquire
0015	81911600	SCREW	81911600 SCREW M6 X 1 X 18	-	2	Enquire
0016	883878	COMPL. REAR UPPER ARM	883878 COMPL. REAR UPPER ARM	-	2	Enquire
0017	264528	THREADED ROD 10 X 1.25	264528 THREADED ROD 10 X 1.25	-	4	Enquire
0018	312826	WASHER	312826 WASHER	-	4	Enquire
0019	14496624	WASHER	14496624 WASHER D. 10.5-21 X 2	-	4	Enquire
0020	104114	NUT	104114 NUT	-	4	Enquire
0021	250657	SCREW M6 X 14	250657 SCREW M6 X 14 M6 X 14	-	6	Enquire
0022	338394	LH REAR JOINT BRACKET	338394 LH REAR JOINT BRACKET	-	1	Enquire
0022	338395	RH REAR JOINT BRACKET	338395 RH REAR JOINT BRACKET	-	1	Enquire
0023	13046011	NUT	13046011 NUT	-	2	Enquire
0024	336026	ABS SENSOR	336026 ABS SENSOR	-	2	Enquire
0026	942843	LH ABS CABLE BRACKET	942843 LH ABS CABLE BRACKET	-	1	Enquire
0026	942906	RH ABS CABLE BRACKET	942906 RH ABS CABLE BRACKET	-	1	Enquire
0027	259688	ANTI-ROTATION LINKAGE	259688 ANTI-ROTATION LINKAGE	-	2	Enquire
0028	238258	SCREW	238258 SCREW M12 X 1.25 X 75	-	2	Enquire
0029	222956	COMPENSATOR RING	222956 COMPENSATOR RING	-	2	Enquire
0030	238656	SPECIAL SCREW	238656 SPECIAL SCREW M14 X 1.5 X 210	-	2	Enquire
0031	238063	NUT	238063 NUT	-	2	Enquire
0032	896438	THREADED ROD	896438 THREADED ROD	-	8	Enquire
0033	888754	ADJUSTER SHIM	888754 ADJUSTER SHIM Th. 0.5 mm	-	4	Enquire
0033	888755	ADJUSTER SHIM	888755 ADJUSTER SHIM Th. 1 mm	-	4	Enquire
0033	888756	ADJUSTER SHIM	888756 ADJUSTER SHIM Th. 1.5 mm	-	4	Enquire
0033	888757	ADJUSTER SHIM	888757 ADJUSTER SHIM Th. 2 mm	-	4	Enquire
0033	888758	ADJUSTER SHIM	888758 ADJUSTER SHIM Th. 2.5 mm	-	4	Enquire
0033	888759	ADJUSTER SHIM	888759 ADJUSTER SHIM Th. 3 mm	-	4	Enquire
0033	888760	ADJUSTER SHIM	888760 ADJUSTER SHIM Th. 3.5 mm	-	4	Enquire
0033	888761	ADJUSTER SHIM	888761 ADJUSTER SHIM Th. 4 mm	-	4	Enquire
0034	969297	ADJUSTMENT SHIM	969297 ADJUSTMENT SHIM Th. 0.5 mm	-	2	Enquire
0034	969298	ADJUSTMENT SHIM	969298 ADJUSTMENT SHIM Th. 1 mm	-	2	Enquire
0034	969299	ADJUSTMENT SHIM	969299 ADJUSTMENT SHIM Th. 1.5 mm	-	2	Enquire
0034	969296	ADJUSTMENT SHIM	969296 ADJUSTMENT SHIM Th. 2 mm	-	2	Enquire
0034	969300	ADJUSTMENT SHIM	969300 ADJUSTMENT SHIM Th. 2.5 mm	-	2	Enquire
0034	969301	ADJUSTMENT SHIM	969301 ADJUSTMENT SHIM Th. 3 mm	-	2	Enquire
0034	969302	ADJUSTMENT SHIM	969302 ADJUSTMENT SHIM Th. 3.5 mm	-	2	Enquire
0034	969303	ADJUSTMENT SHIM	969303 ADJUSTMENT SHIM Th. 4 mm	-	2	Enquire
0035	13507434	WASHER	13507434 WASHER	-	8	Enquire
0036	148020	NUT	148020 NUT	-	8	Enquire
0037	984045	COMPL. TRAVEL SENSOR	984045 COMPL. TRAVEL SENSOR	-	2	Enquire
0038	216973	BALL JOINT	216973 BALL JOINT	-	2	Enquire
0039	16284934	FLANGED SCREW	16284934 FLANGED SCREW M5 X 10	-	4	Enquire
