Find Your Part

VEHICLE ECUs of Ferrari Ferrari F12 Berlinetta

View All

Ferrari F12 Berlinetta - VEHICLE ECUs

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	245788	DASHBOARD ECU	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	273412	DRIVER SIDE DOOR NODE ECU	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	273413	PASSENGER SIDE DOOR NODE ECU	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11568124	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	302489	PARKING SENSOR NODE ECU	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231619	SOCKET HEAD SCREW M6 X 22 WITH WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	267786	MAGNERIDE SUSPENSION ECU	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14054048	NUT	Enquire	To Order
	62790300	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11181474	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	267787	POWER STEERING CONTROL ECU	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	65708600	SPACER BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	267996	PARKING CAMERA ECU	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11625824	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059211	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059211	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	65708600	SPACER BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	341962	VEHICLE LIFT ECU	Enquire	To Order
	341961	VEHICLE LIFT ECU	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	290965	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	264097	VOLTAGE STABILIZER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	277281	ADAPTIVE HEADLIGHT NODE ECU	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231619	SOCKET HEAD SCREW M6 X 22 WITH WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	291167	VENT CONTROL ECU	Enquire	To Order
	296258	VENT CONTROL ECU	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	287268	NODE MOUNTING BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	264935	PWM COMMAND SIGNAL FOR FUEL PUMPS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	255515	BUSH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	238263	IGNITION ECU	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	289449	LH MOTRONIC FASTENER BRACKET	Enquire	To Order
	289448	RH MOTRONIC FASTENER BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	257695	CENTRE BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16296934	SCREW 6 X 14MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14498801	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	289064	IONISING KNOCK SENSOR CONTROL UNIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	291303	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	292632	COMPL. PWM ECU FASTENER BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	295913	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	267992	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	223469	BUZZER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85833700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62769800	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16286124	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	81591700	SCREW	Enquire	To Order
	81591700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	298044	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	284284	FRONT FASTENER BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	284285	REAR FASTENER BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	284286	FRONT FASTENER BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	284287	REAR FASTENER BRACKET	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
2	245788	DASHBOARD ECU	245788 DASHBOARD ECU	-	1	Enquire
3	273412	DRIVER SIDE DOOR NODE ECU	273412 DRIVER SIDE DOOR NODE ECU	-	1	Enquire
4	273413	PASSENGER SIDE DOOR NODE ECU	273413 PASSENGER SIDE DOOR NODE ECU	-	1	Enquire
5	11568124	SCREW	11568124 SCREW M5 X 16	-	4	Enquire
6	302489	PARKING SENSOR NODE ECU	302489 PARKING SENSOR NODE ECU Applicable up to Ass. No. 117693	-	1	Enquire
7	231619	SOCKET HEAD SCREW M6 X 22 WITH WASHER	231619 SOCKET HEAD SCREW M6 X 22 WITH WASHER M6 X 18	-	4	Enquire
8	267786	MAGNERIDE SUSPENSION ECU	267786 MAGNERIDE SUSPENSION ECU	-	1	Enquire
9	14054048	NUT	14054048 NUT	-	4	Enquire
9	62790300	NUT	62790300 NUT No longer supplied; Replaced by 168698	-	4	Enquire
10	11181474	WASHER	11181474 WASHER No longer supplied	-	4	Enquire
11	267787	POWER STEERING CONTROL ECU	267787 POWER STEERING CONTROL ECU	-	1	Enquire
12	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6 M5	-	2	Enquire
13	65708600	SPACER BUSHING	65708600 SPACER BUSHING	-	2	Enquire
14	267996	PARKING CAMERA ECU	267996 PARKING CAMERA ECU	-	1	Enquire
15	11625824	SCREW	11625824 SCREW	-	2	Enquire
16	14059211	NUT	14059211 NUT	-	3	Enquire
18	14059211	NUT	14059211 NUT	-	2	Enquire
19	65708600	SPACER BUSHING	65708600 SPACER BUSHING	-	2	Enquire
20	341962	VEHICLE LIFT ECU	341962 VEHICLE LIFT ECU Applicable until depletion	-	1	Enquire
20	341961	VEHICLE LIFT ECU	341961 VEHICLE LIFT ECU Applicable after depletion of 284013	-	1	Enquire
21	290965	BRACKET	290965 BRACKET	-	1	Enquire
22	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6 M5	-	2	Enquire
23	264097	VOLTAGE STABILIZER	264097 VOLTAGE STABILIZER Applicable for Stop&Start	-	1	Enquire
24	277281	ADAPTIVE HEADLIGHT NODE ECU	277281 ADAPTIVE HEADLIGHT NODE ECU	-	1	Enquire
25	231619	SOCKET HEAD SCREW M6 X 22 WITH WASHER	231619 SOCKET HEAD SCREW M6 X 22 WITH WASHER M6 X 18	-	4	Enquire
26	291167	VENT CONTROL ECU	291167 VENT CONTROL ECU Not for GD	-	1	Enquire
26	296258	VENT CONTROL ECU	296258 VENT CONTROL ECU Applicable for GD	-	1	Enquire
27	287268	NODE MOUNTING BRACKET	287268 NODE MOUNTING BRACKET	-	1	Enquire
28	264935	PWM COMMAND SIGNAL FOR FUEL PUMPS	264935 PWM COMMAND SIGNAL FOR FUEL PUMPS	-	1	Enquire
29	255515	BUSH	255515 BUSH	-	1	Enquire
31	238263	IGNITION ECU	238263 IGNITION ECU Unprogrammed	-	2	Enquire
32	289449	LH MOTRONIC FASTENER BRACKET	289449 LH MOTRONIC FASTENER BRACKET	-	1	Enquire
32	289448	RH MOTRONIC FASTENER BRACKET	289448 RH MOTRONIC FASTENER BRACKET	-	1	Enquire
33	257695	CENTRE BRACKET	257695 CENTRE BRACKET	-	1	Enquire
34	16296934	SCREW 6 X 14MM	16296934 SCREW 6 X 14MM M6 X 14	-	4	Enquire
35	14498801	WASHER	14498801 WASHER	-	4	Enquire
36	289064	IONISING KNOCK SENSOR CONTROL UNIT	289064 IONISING KNOCK SENSOR CONTROL UNIT Unprogrammed	-	2	Enquire
39	291303	BRACKET	291303 BRACKET	-	1	Enquire
40	292632	COMPL. PWM ECU FASTENER BRACKET	292632 COMPL. PWM ECU FASTENER BRACKET	-	1	Enquire
41	295913	BRACKET	295913 BRACKET	-	1	Enquire
42	267992	BRACKET	267992 BRACKET	-	1	Enquire
43	223469	BUZZER	223469 BUZZER	-	2	Enquire
44	85833700	SCREW	85833700 SCREW M5 X 10	-	4	Enquire
45	62769800	WASHER	62769800 WASHER	-	4	Enquire
46	16286124	SCREW	16286124 SCREW M6 X 20	-	4	Enquire
47	81591700	SCREW	81591700 SCREW	-	3	Enquire
47	81591700	SCREW	81591700 SCREW No longer supplied; Replaced by 85692300	-	3	Enquire
48	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	2	Enquire
49	298044	BRACKET	298044 BRACKET Applicable up to Ass. No. 108014	-	1	Enquire
50	284284	FRONT FASTENER BRACKET	284284 FRONT FASTENER BRACKET	-	1	Enquire
51	284285	REAR FASTENER BRACKET	284285 REAR FASTENER BRACKET	-	1	Enquire
52	284286	FRONT FASTENER BRACKET	284286 FRONT FASTENER BRACKET	-	1	Enquire
53	284287	REAR FASTENER BRACKET	284287 REAR FASTENER BRACKET	-	1	Enquire
