DASHBOARD AIR DUCTS of Ferrari Ferrari F12 Berlinetta

View All

Ferrari F12 Berlinetta - DASHBOARD AIR DUCTS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	84472200	DEFROSTER DUCT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	84489600	COMPL. RH AIR DUCT	Enquire	To Order
	84956500	COMPL. LH AIR DUCT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	84493700	COMPL. LH AIR DUCT	Enquire	To Order
	84956700	COMPL. RH AIR DUCT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85107900	DASH-RH DOOR AIR DUCT	Enquire	To Order
	84956800	DASH-LH DOOR AIR DUCT	Enquire	To Order
	84683200	DASH-RH DOOR AIR DUCT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85108100	DASH-LH DOOR AIR DUCT	Enquire	To Order
	84957000	DASH-RH DOOR AIR DUCT	Enquire	To Order
	84683300	DASH-LH DOOR AIR DUCT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	84966900	DRIVER SIDE AIR DUCT	Enquire	To Order
	83374900	DRIVER SIDE AIR DUCT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	84088300	PASSENGER SIDE UPPER FOOTWELL AIR DUCT	Enquire	To Order
	84966000	PASSENGER SIDE UPPER FOOTWELL AIR DUCT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	84191100	PASSENGER SIDE LOWER FOOTWELL AIR DUCT	Enquire	To Order
	84966200	PASSENGER SIDE LOWER FOOTWELL AIR DUCT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85833700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	84956600	DRIVER SIDE FOOTWELL AIR DUCT	Enquire	To Order
	84493500	DRIVER SIDE FOOTWELL AIR DUCT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85833700	SCREW	Enquire	To Order
	88822200	SCREW TORX HEAD M4 X 10MM	Enquire	To Order
	85833700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62769800	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85833700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85833700	SCREW	Enquire	To Order
	85833700	SCREW	Enquire	To Order
	85833700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62769800	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	84472200	DEFROSTER DUCT	84472200 DEFROSTER DUCT Not for GD; Applicable up to Ass. No. 114045	-	1	Enquire
2	84489600	COMPL. RH AIR DUCT	84489600 COMPL. RH AIR DUCT Not for GD	-	1	Enquire
2	84956500	COMPL. LH AIR DUCT	84956500 COMPL. LH AIR DUCT Applicable for GD	-	1	Enquire
3	84493700	COMPL. LH AIR DUCT	84493700 COMPL. LH AIR DUCT Not for GD	-	1	Enquire
3	84956700	COMPL. RH AIR DUCT	84956700 COMPL. RH AIR DUCT Applicable for GD	-	1	Enquire
4	85107900	DASH-RH DOOR AIR DUCT	85107900 DASH-RH DOOR AIR DUCT Not for GD; Applicable from Ass. No. 114046	-	1	Enquire
4	84956800	DASH-LH DOOR AIR DUCT	84956800 DASH-LH DOOR AIR DUCT Applicable for GD	-	1	Enquire
4	84683200	DASH-RH DOOR AIR DUCT	84683200 DASH-RH DOOR AIR DUCT Not for GD; Applicable up to Ass. No. 114045	-	1	Enquire
5	85108100	DASH-LH DOOR AIR DUCT	85108100 DASH-LH DOOR AIR DUCT Not for GD; Applicable from Ass. No. 114046	-	1	Enquire
5	84957000	DASH-RH DOOR AIR DUCT	84957000 DASH-RH DOOR AIR DUCT Applicable for GD	-	1	Enquire
5	84683300	DASH-LH DOOR AIR DUCT	84683300 DASH-LH DOOR AIR DUCT Not for GD; Applicable up to Ass. No. 114045	-	1	Enquire
6	84966900	DRIVER SIDE AIR DUCT	84966900 DRIVER SIDE AIR DUCT Applicable for GD	-	1	Enquire
6	83374900	DRIVER SIDE AIR DUCT	83374900 DRIVER SIDE AIR DUCT Not for GD	-	1	Enquire
7	84088300	PASSENGER SIDE UPPER FOOTWELL AIR DUCT	84088300 PASSENGER SIDE UPPER FOOTWELL AIR DUCT Not for GD	-	1	Enquire
7	84966000	PASSENGER SIDE UPPER FOOTWELL AIR DUCT	84966000 PASSENGER SIDE UPPER FOOTWELL AIR DUCT Applicable for GD	-	1	Enquire
8	84191100	PASSENGER SIDE LOWER FOOTWELL AIR DUCT	84191100 PASSENGER SIDE LOWER FOOTWELL AIR DUCT Not for GD	-	1	Enquire
8	84966200	PASSENGER SIDE LOWER FOOTWELL AIR DUCT	84966200 PASSENGER SIDE LOWER FOOTWELL AIR DUCT Applicable for GD	-	1	Enquire
9	85833700	SCREW	85833700 SCREW M5 X 12	-	2	Enquire
10	84956600	DRIVER SIDE FOOTWELL AIR DUCT	84956600 DRIVER SIDE FOOTWELL AIR DUCT Applicable for GD	-	1	Enquire
10	84493500	DRIVER SIDE FOOTWELL AIR DUCT	84493500 DRIVER SIDE FOOTWELL AIR DUCT Not for GD	-	1	Enquire
11	85833700	SCREW	85833700 SCREW M5 X 12; Applicable from Ass. No. 114046	-	5	Enquire
11	88822200	SCREW TORX HEAD M4 X 10MM	88822200 SCREW TORX HEAD M4 X 10MM M3.5 X 10; Applicable up to Ass. No. 114045	-	10	Enquire
11	85833700	SCREW	85833700 SCREW M5 X 10; Applicable up to Ass. No. 114045	-	1	Enquire
12	62769800	WASHER	62769800 WASHER Applicable from Ass. No. 114046	-	1	Enquire
13	85833700	SCREW	85833700 SCREW M5 X 14	-	8	Enquire
14	85833700	SCREW	85833700 SCREW M5 X 12; Applicable from Ass. No. 114046	-	4	Enquire
14	85833700	SCREW	85833700 SCREW M5 X 12; Applicable up to Ass. No. 114045	-	3	Enquire
14	85833700	SCREW	85833700 SCREW M5 X 8; Applicable up to Ass. No. 114045	-	1	Enquire
15	62769800	WASHER	62769800 WASHER Applicable up to Ass. No. 114045	-	3	Enquire
16	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	1	Enquire
