HEAT SHIELDS IN VEHICLE of Ferrari Ferrari California (2012-2014)

View All

Ferrari California (2012-2014) - HEAT SHIELDS IN VEHICLE

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	83951500	RH CATALYTIC CONVERTER HEAT SHIELD	Enquire	To Order
	69760500	R.H. HEAT SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	83951600	LH CATALYTIC CONVERTER HEAT SHIELD	Enquire	To Order
	69760600	L.H. HEAT SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	80874100	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	67315400	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	81175800	TUNNEL HEAT SHIELD	Enquire	To Order
	83951700	TUNNEL HEAT SHIELD	Enquire	To Order
	69761000	TUNNEL HEAT SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	80874100	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	67315400	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	263737	TANK HEAT SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16296934	SCREW 6 X 14MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	67315400	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	83951800	RH HEAT SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	80874100	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	67315400	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	69761200	R.H. HEAT SHIELD TRUNK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	69761300	L.H. HEAT SHIELD TRUNK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	82118300	SCREW -No longer supplied- -Replaced by 11625714-	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	67315400	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231619	SOCKET HEAD SCREW M6 X 22 WITH WASHER	Enquire	To Order
	86574700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	254704	RH GEARBOX HEAT SHIELD	Enquire	To Order
	282637	RH GEARBOX HEAT SHIELD	Enquire	To Order
	261947	RH GEARBOX HEAT SHIELD	Enquire	To Order

...and 5 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	254703	LH GEARBOX HEAT SHIELD	Enquire	To Order
	282922	LH GEARBOX HEAT SHIELD	Enquire	To Order
	261946	LH GEARBOX HEAT SHIELD	Enquire	To Order

...and 5 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	16296934	SCREW 6 X 14MM	Enquire	To Order
	86574700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	246880	R.H. OIL PIPES HEAT SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	246879	L.H. OIL PIPES HEAT SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	86574700	SCREW	Enquire	To Order
	16286124	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12643724	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	83951900	LH HEAT SHIELD	Enquire	To Order
	83628300	LH HEAT SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13046112	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	82159500	CAP FOR SLOT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	82299600	PLUG FOR FRONT MASTER POINT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	82299500	PLUG FOR REAR MASTER POINT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	263963	CABLE SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85833700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	84290300	LOWER FASTENER BRACKET FOR LH HEAT SHIELD	Enquire	To Order
	84209700	LOWER FASTENER BRACKET FOR RH HEAT SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	84451000	UPPER FASTENER BRACKET FOR LH HEAT SHIELD	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	83951500	RH CATALYTIC CONVERTER HEAT SHIELD	83951500 RH CATALYTIC CONVERTER HEAT SHIELD not affected by modification; Applicable from Ass. No. 103179	-	1	Enquire
1	69760500	R.H. HEAT SHIELD	69760500 R.H. HEAT SHIELD Applicable up to Ass. No. 103178	-	1	Enquire
2	83951600	LH CATALYTIC CONVERTER HEAT SHIELD	83951600 LH CATALYTIC CONVERTER HEAT SHIELD not affected by modification; Applicable from Ass. No. 103179	-	1	Enquire
2	69760600	L.H. HEAT SHIELD	69760600 L.H. HEAT SHIELD Applicable up to Ass. No. 103178	-	1	Enquire
3	80874100	SCREW	80874100 SCREW	-	12	Enquire
4	67315400	WASHER	67315400 WASHER	-	12	Enquire
5	81175800	TUNNEL HEAT SHIELD	81175800 TUNNEL HEAT SHIELD Not for DCT-F1 gearbox (Applicable for mechanical gearbox)	-	1	Enquire
5	83951700	TUNNEL HEAT SHIELD	83951700 TUNNEL HEAT SHIELD not affected by modification; Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable from Ass. No. 103179	-	1	Enquire
5	69761000	TUNNEL HEAT SHIELD	69761000 TUNNEL HEAT SHIELD Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable up to Ass. No. 103178	-	1	Enquire
6	80874100	SCREW	80874100 SCREW	-	6	Enquire
7	67315400	WASHER	67315400 WASHER	-	6	Enquire
8	263737	TANK HEAT SHIELD	263737 TANK HEAT SHIELD Not for DCT-F1 gearbox (Applicable for mechanical gearbox)	-	1	Enquire
9	16296934	SCREW 6 X 14MM	16296934 SCREW 6 X 14MM	-	2	Enquire
10	67315400	WASHER	67315400 WASHER	-	2	Enquire
11	83951800	RH HEAT SHIELD	83951800 RH HEAT SHIELD not affected by modification; Applicable from Ass. No. 103179	-	1	Enquire
12	80874100	SCREW	80874100 SCREW	-	6	Enquire
13	67315400	WASHER	67315400 WASHER	-	6	Enquire
14	69761200	R.H. HEAT SHIELD TRUNK	69761200 R.H. HEAT SHIELD TRUNK Applicable up to Ass. No. 103178	-	1	Enquire
15	69761300	L.H. HEAT SHIELD TRUNK	69761300 L.H. HEAT SHIELD TRUNK Applicable up to Ass. No. 103178	-	1	Enquire
16	82118300	SCREW -No longer supplied- -Replaced by 11625714-	82118300 SCREW -No longer supplied- -Replaced by 11625714-	-	6	Enquire
17	67315400	WASHER	67315400 WASHER	-	6	Enquire
20	231619	SOCKET HEAD SCREW M6 X 22 WITH WASHER	231619 SOCKET HEAD SCREW M6 X 22 WITH WASHER M6 X 22; Applicable from Ass. No. 103179	-	8	Enquire
20	86574700	SCREW	86574700 SCREW M6 X 16; Applicable up to Ass. No. 103178	-	8	Enquire
21	254704	RH GEARBOX HEAT SHIELD	254704 RH GEARBOX HEAT SHIELD Not for DCT-F1 gearbox (Applicable for mechanical gearbox)	-	1	Enquire
21	282637	RH GEARBOX HEAT SHIELD	282637 RH GEARBOX HEAT SHIELD not affected by modification; Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable from Ass. No. 103179	-	1	Enquire
21	261947	RH GEARBOX HEAT SHIELD	261947 RH GEARBOX HEAT SHIELD Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable for GD; Applicable from Ass. No. 91553 up to Ass. No. 103178	-	1	Enquire
21	261947	RH GEARBOX HEAT SHIELD	261947 RH GEARBOX HEAT SHIELD Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable for CINA, USA, CDN, J, USA LIGHT; Applicable from Ass. No. 90609 up to Ass. No. 103178	-	1	Enquire
21	261947	RH GEARBOX HEAT SHIELD	261947 RH GEARBOX HEAT SHIELD Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Not for CINA, USA, CDN, J, GD, USA LIGHT; Applicable from Ass. No. 89389 up to Ass. No. 103178	-	1	Enquire
21	242697	RH GEARBOX HEAT SHIELD	242697 RH GEARBOX HEAT SHIELD Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable for GD; Applicable up to Ass. No. 91552	-	1	Enquire
21	242697	RH GEARBOX HEAT SHIELD	242697 RH GEARBOX HEAT SHIELD Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable for CINA, USA, CDN, J, USA LIGHT; Applicable up to Ass. No. 90608	-	1	Enquire
21	242697	RH GEARBOX HEAT SHIELD	242697 RH GEARBOX HEAT SHIELD Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Not for CINA, USA, CDN, J, GD, USA LIGHT; Applicable up to Ass. No. 89388	-	1	Enquire
22	254703	LH GEARBOX HEAT SHIELD	254703 LH GEARBOX HEAT SHIELD Not for DCT-F1 gearbox (Applicable for mechanical gearbox)	-	1	Enquire
22	282922	LH GEARBOX HEAT SHIELD	282922 LH GEARBOX HEAT SHIELD not affected by modification; Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable from Ass. No. 103179	-	1	Enquire
22	261946	LH GEARBOX HEAT SHIELD	261946 LH GEARBOX HEAT SHIELD Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable for GD; Applicable from Ass. No. 91553 up to Ass. No. 103178	-	1	Enquire
22	261946	LH GEARBOX HEAT SHIELD	261946 LH GEARBOX HEAT SHIELD Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable for CINA, USA, CDN, J, USA LIGHT; Applicable from Ass. No. 90609 up to Ass. No. 103178	-	1	Enquire
22	261946	LH GEARBOX HEAT SHIELD	261946 LH GEARBOX HEAT SHIELD Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Not for CINA, USA, CDN, J, GD, USA LIGHT; Applicable from Ass. No. 89389 up to Ass. No. 103178	-	1	Enquire
22	248741	LH GEARBOX HEAT SHIELD	248741 LH GEARBOX HEAT SHIELD Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable for GD; Applicable up to Ass. No. 91552	-	1	Enquire
22	248741	LH GEARBOX HEAT SHIELD	248741 LH GEARBOX HEAT SHIELD Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Applicable for CINA, USA, CDN, J, USA LIGHT; Applicable up to Ass. No. 90608	-	1	Enquire
22	248741	LH GEARBOX HEAT SHIELD	248741 LH GEARBOX HEAT SHIELD Applicable for DCT-F1 gearbox (Not for mechanical gearbox); Not for CINA, USA, CDN, J, GD, USA LIGHT; Applicable up to Ass. No. 89388	-	1	Enquire
23	16296934	SCREW 6 X 14MM	16296934 SCREW 6 X 14MM	-	6	Enquire
23	86574700	SCREW	86574700 SCREW M6 X 16; No longer supplied; Replaced by 16296924	-	6	Enquire
24	246880	R.H. OIL PIPES HEAT SHIELD	246880 R.H. OIL PIPES HEAT SHIELD	-	1	Enquire
25	246879	L.H. OIL PIPES HEAT SHIELD	246879 L.H. OIL PIPES HEAT SHIELD	-	1	Enquire
26	86574700	SCREW	86574700 SCREW M6 X 16	-	2	Enquire
26	16286124	SCREW	16286124 SCREW	-	2	Enquire
27	12643724	WASHER	12643724 WASHER	-	4	Enquire
28	83951900	LH HEAT SHIELD	83951900 LH HEAT SHIELD not affected by modification; Applicable from Ass. No. 103179	-	1	Enquire
28	83628300	LH HEAT SHIELD	83628300 LH HEAT SHIELD Applicable up to Ass. No. 103178	-	1	Enquire
29	13046112	NUT	13046112 NUT	-	6	Enquire
30	82159500	CAP FOR SLOT	82159500 CAP FOR SLOT	-	4	Enquire
31	82299600	PLUG FOR FRONT MASTER POINT	82299600 PLUG FOR FRONT MASTER POINT	-	2	Enquire
32	82299500	PLUG FOR REAR MASTER POINT	82299500 PLUG FOR REAR MASTER POINT	-	2	Enquire
33	263963	CABLE SHIELD	263963 CABLE SHIELD Not for DCT-F1 gearbox (Applicable for mechanical gearbox)	-	1	Enquire
34	85833700	SCREW	85833700 SCREW Not for DCT-F1 gearbox (Applicable for mechanical gearbox)	-	2	Enquire
35	84290300	LOWER FASTENER BRACKET FOR LH HEAT SHIELD	84290300 LOWER FASTENER BRACKET FOR LH HEAT SHIELD not affected by modification; Applicable from Ass. No. 103179	-	1	Enquire
35	84209700	LOWER FASTENER BRACKET FOR RH HEAT SHIELD	84209700 LOWER FASTENER BRACKET FOR RH HEAT SHIELD not affected by modification; Applicable from Ass. No. 103179	-	1	Enquire
36	84451000	UPPER FASTENER BRACKET FOR LH HEAT SHIELD	84451000 UPPER FASTENER BRACKET FOR LH HEAT SHIELD not affected by modification; Applicable from Ass. No. 103179	-	1	Enquire
