AIR CONDITIONING SYSTEM of Ferrari Ferrari 550 Maranello (2011-2012)

View All

Ferrari 550 Maranello (2011-2012) - AIR CONDITIONING SYSTEM

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	165395	A.C. CONDENSER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	168481	RH BRACKET A.C. CONDENSER SUPPORT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	165136	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	165561	L.H. UPPER BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	168068	L.H. LOWER BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64918600	PIPE FROM CONDENSER TO DEHYDRATOR FILTER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64918700	PIPE FROM COMPRESSOR TO CONDENSER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64894200	DEHYDRATOR FILTER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66374400	PRESSURE SWITCH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63994900	BRACKET FOR PUMP -Not as spare part- -Replaced by 69966100-	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	70000900	COMPLETE WATER PUMP KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	165137	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	65190300	PIPE FROM HOSE TO COMPRESSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	285553	VIBRATION DAMPER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64827600	PIPE FROM DEHYDRATOR FILTER TO HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10902424	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12643724	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64791200	HOSE FROM EVAPORATOR TO PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64791300	HOSE FROM PIPE TO EVAPORATOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63961900	FRAME FOR PIPE BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63961800	RUBBER PIPE-HOLDER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64999000	TGK VALVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	65201000	RETURN TUBE FROM HEATER TO VALVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	65201100	RETURN PIPE FROM VALVE TO NOURICE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	65128200	DELIVERY PIPE FROM PUMP TO EVAPORATOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	65122300	DELIVERY PIPE FROM ENGINE TO PUMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13000490	Screw Collar	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	319201	FUEL FILLER PIPE ASSEMBLY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12638124	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10459087	CABLE GROMMET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13000490	Screw Collar	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	169463	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	165136	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	156989	SMALL PLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14498801	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12648224	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14778814	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	81591700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10519424	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	175836	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66309300	O-RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	177655	O.R. GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	65357600	ANTI-VIBRATION GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	177507	BRACKET	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
-	65238100	DELIVERY PIPE FROM ENGINE TO PUMP	65238100 DELIVERY PIPE FROM ENGINE TO PUMP TO PUMP / Valid for GD	-	1	Enquire
-	65237500	DELIVERY PIPE FROM PUMP TO EVAPORATOR	65237500 DELIVERY PIPE FROM PUMP TO EVAPORATOR EVAPORATOR / Valid for GD	-	1	Enquire
-	65237600	RETURN PIPE FROM VALVE TO NOURICE	65237600 RETURN PIPE FROM VALVE TO NOURICE NOURICE / Valid for GD	-	1	Enquire
-	65237700	HOSE FROM EVAPORATOR TO PIPE	65237700 HOSE FROM EVAPORATOR TO PIPE PIPE / Valid for GD	-	1	Enquire
-	65237800	HOSE FROM PIPE TO EVAPORATOR	65237800 HOSE FROM PIPE TO EVAPORATOR EVAPORATOR / Valid for GD	-	1	Enquire
-	65237900	PIPE FROM DEHYDRATOR FILTER TO HOSE	65237900 PIPE FROM DEHYDRATOR FILTER TO HOSE TO HOSE / Valid for GD	-	1	Enquire
-	65856900	PIPE FROM DEHYDRATOR FILTER TO HOSE	65856900 PIPE FROM DEHYDRATOR FILTER TO HOSE TO HOSE / Valid for USA M.Y. 99, CDN M.Y. 99, / USA M.Y. 2000, CDN M.Y. 2000, / USA M.Y. 2001 and CDN M.Y. 2001	-	1	Enquire
-	65238000	PIPE FROM HOSE TO COMPRESSOR	65238000 PIPE FROM HOSE TO COMPRESSOR COMPRESSOR / Valid for GD	-	1	Enquire
-	65857600	PIPE FROM HOSE TO COMPRESSOR	65857600 PIPE FROM HOSE TO COMPRESSOR COMPRESSOR / Valid for USA M.Y. 99, CDN M.Y. 99, / USA M.Y. 2000, CDN M.Y. 2000, / USA M.Y. 2001 and CDN M.Y. 2001	-	1	Enquire
-	65460300	COMPLETE WATER PUMP	65460300 COMPLETE WATER PUMP Valid from car Ass. Nr. 32957 / Valid from car Ass. Nr. 33073 USA M.Y. 99	-	1	Enquire
-	65488600	WATER PUMP	65488600 WATER PUMP Valid from car Ass. Nr. 27498 / and valid till car Ass. Nr. 32956 / Valid till car Ass. Nr. 33072 USA M.Y. 99	-	1	Enquire
-	66374400	PRESSURE SWITCH	66374400 PRESSURE SWITCH	-	1	Enquire
1	165395	A.C. CONDENSER	165395 A.C. CONDENSER	-	1	Enquire
2	168481	RH BRACKET A.C. CONDENSER SUPPORT	168481 RH BRACKET A.C. CONDENSER SUPPORT SUPPORT	-	2	Enquire
3	165136	SCREW	165136 SCREW	-	4	Enquire
4	165561	L.H. UPPER BRACKET	165561 L.H. UPPER BRACKET	-	1	Enquire
5	168068	L.H. LOWER BRACKET	168068 L.H. LOWER BRACKET	-	1	Enquire
6	64918600	PIPE FROM CONDENSER TO DEHYDRATOR FILTER	64918600 PIPE FROM CONDENSER TO DEHYDRATOR FILTER TO DEHYDRATOR FILTER	-	1	Enquire
7	64918700	PIPE FROM COMPRESSOR TO CONDENSER	64918700 PIPE FROM COMPRESSOR TO CONDENSER CONDENSER	-	1	Enquire
8	64894200	DEHYDRATOR FILTER	64894200 DEHYDRATOR FILTER	-	1	Enquire
9	66374400	PRESSURE SWITCH	66374400 PRESSURE SWITCH Not as spare part now / Replaced by 66374400	-	1	Enquire
10	63994900	BRACKET FOR PUMP -Not as spare part- -Replaced by 69966100-	63994900 BRACKET FOR PUMP -Not as spare part- -Replaced by 69966100-	-	1	Enquire
11	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	2	Enquire
12	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2	-	2	Enquire
13	70000900	COMPLETE WATER PUMP KIT	70000900 COMPLETE WATER PUMP KIT Valid till car Ass. Nr. 27497	-	1	Enquire
14	165137	SCREW	165137 SCREW	-	4	Enquire
15	65190300	PIPE FROM HOSE TO COMPRESSOR	65190300 PIPE FROM HOSE TO COMPRESSOR COMPRESSOR -Not for GD / Not for USA M.Y. 99, CDN M.Y. 99, / USA M.Y. 2000, CDN M.Y. 2000, / USA M.Y. 2001 and CDN M.Y. 2001	-	1	Enquire
16	285553	VIBRATION DAMPER	285553 VIBRATION DAMPER	-	2	Enquire
17	64827600	PIPE FROM DEHYDRATOR FILTER TO HOSE	64827600 PIPE FROM DEHYDRATOR FILTER TO HOSE TO HOSE -Not for GD / Not for USA M.Y. 99, CDN M.Y. 99, / USA M.Y. 2000, CDN M.Y. 2000, / USA M.Y. 2001 and CDN M.Y. 2001	-	1	Enquire
18	10902424	SCREW	10902424 SCREW	-	1	Enquire
19	127494	WASHER	127494 WASHER	-	1	Enquire
20	12643724	WASHER	12643724 WASHER	-	1	Enquire
21	64791200	HOSE FROM EVAPORATOR TO PIPE	64791200 HOSE FROM EVAPORATOR TO PIPE PIPE / Not for GD	-	1	Enquire
22	64791300	HOSE FROM PIPE TO EVAPORATOR	64791300 HOSE FROM PIPE TO EVAPORATOR EVAPORATOR / Not for GD	-	1	Enquire
23	63961900	FRAME FOR PIPE BUSHING	63961900 FRAME FOR PIPE BUSHING	-	1	Enquire
24	63961800	RUBBER PIPE-HOLDER	63961800 RUBBER PIPE-HOLDER	-	1	Enquire
25	64999000	TGK VALVE	64999000 TGK VALVE	-	1	Enquire
26	65201000	RETURN TUBE FROM HEATER TO VALVE	65201000 RETURN TUBE FROM HEATER TO VALVE TO VALVE	-	1	Enquire
27	65201100	RETURN PIPE FROM VALVE TO NOURICE	65201100 RETURN PIPE FROM VALVE TO NOURICE NOURICE / Not for GD	-	1	Enquire
28	65128200	DELIVERY PIPE FROM PUMP TO EVAPORATOR	65128200 DELIVERY PIPE FROM PUMP TO EVAPORATOR EVAPORATOR / Not for GD	-	1	Enquire
29	65122300	DELIVERY PIPE FROM ENGINE TO PUMP	65122300 DELIVERY PIPE FROM ENGINE TO PUMP TO PUMP / Not for GD	-	1	Enquire
30	13000490	Screw Collar	13000490 Screw Collar	-	2	Enquire
31	319201	FUEL FILLER PIPE ASSEMBLY	319201 FUEL FILLER PIPE ASSEMBLY	-	2	Enquire
32	12638124	WASHER	12638124 WASHER	-	2	Enquire
33	10459087	CABLE GROMMET	10459087 CABLE GROMMET	-	2	Enquire
34	13000490	Screw Collar	13000490 Screw Collar	-	2	Enquire
35	169463	BRACKET	169463 BRACKET	-	1	Enquire
36	165136	SCREW	165136 SCREW	-	6	Enquire
37	156989	SMALL PLATE	156989 SMALL PLATE	-	1	Enquire
38	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	1	Enquire
39	127494	WASHER	127494 WASHER	-	1	Enquire
40	14498801	WASHER	14498801 WASHER	-	1	Enquire
41	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	2	Enquire
42	127494	WASHER	127494 WASHER	-	2	Enquire
43	12648224	WASHER	12648224 WASHER	-	2	Enquire
44	14778814	SCREW	14778814 SCREW	-	1	Enquire
45	81591700	SCREW	81591700 SCREW	-	2	Enquire
46	127494	WASHER	127494 WASHER	-	2	Enquire
47	10519424	WASHER	10519424 WASHER	-	2	Enquire
48	175836	BRACKET	175836 BRACKET	-	1	Enquire
49	66309300	O-RING	66309300 O-RING	-	1	Enquire
50	177655	O.R. GASKET	177655 O.R. GASKET	-	1	Enquire
51	65357600	ANTI-VIBRATION GASKET	65357600 ANTI-VIBRATION GASKET Valid for GD / Valid from car Ass. Nr. 33515	-	1	Enquire
52	177507	BRACKET	177507 BRACKET Valid from car Ass. Nr. 29471	-	1	Enquire
