Ferrari 512 M - Braking system

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	149054	Electronic control unit	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	149053	Protection relay	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	125241	10 A FUSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10519424	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	147966	Pipe from pump to front circuit control unit	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	147968	Pipe from pump to rear circuit control unit	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	155923	Brake pipe from control unit to RH front flexible cable	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	155924	Brake pipe from control unit to LH front flexible cable	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	155925	Brake pipe from control unit to brake pressure regulator	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14054511	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	159266	Front sensor	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	151330	Sensor support	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	60909500	ALLEN HEAD SCREW M6 X 15	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	137669	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	147951	Brake pupe from brake pressure regulator to 3 way union	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	147980	Brake pipe from 3 way union to RH rear flexible cable	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	147981	Brake pipe from 3 way union to LH rear flexible cable	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	101394	3 WAY UNION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	151179	R.H. support	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	143405	FASTON TONGUE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	319201	FUEL FILLER PIPE ASSEMBLY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62790300	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10519224	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	128292	CLIP -For GD q.ty 2-	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10519424	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	152422	Rear sensor protection	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	159267	Rear sensor	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10440890	BRACKET WITH SHEATH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	154747	Washer	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10440990	BRACKET WITH SHEATH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	137313	R.H. and L.H. front flexible pipe	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	271771	PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	146949	Brake pressure regulator	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
-	151180	L.H. support	151180 L.H. support	-	1	Enquire
-	152644	Brake pupe from brake pressure regulator to 3 way union	152644 Brake pupe from brake pressure regulator to 3 way union regulator to 3-way union / Valid for GD	-	1	Enquire
-	155928	Brake pipe from control unit to brake pressure regulator	155928 Brake pipe from control unit to brake pressure regulator brake pressure regulator / Valid for GD	-	1	Enquire
-	155927	Brake pipe from control unit to LH front flexible cable	155927 Brake pipe from control unit to LH front flexible cable L.H. front flexible cable / Valid for GD	-	1	Enquire
-	150363	Pipe from pump to rear circuit control unit	150363 Pipe from pump to rear circuit control unit rear circuit control unit / Valid for GD	-	1	Enquire
-	155926	Brake pipe from control unit to RH front flexible cable	155926 Brake pipe from control unit to RH front flexible cable R.H. front flexible cable / Valid for GD	-	1	Enquire
-	150359	Pipe from pump to front circuit control unit	150359 Pipe from pump to front circuit control unit front circuit control unit / Valid for GD	-	1	Enquire
1	149054	Electronic control unit	149054 Electronic control unit	-	1	Enquire
2	149053	Protection relay	149053 Protection relay	-	1	Enquire
3	125241	10 A FUSE	125241 10 A FUSE	-	1	Enquire
4	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	1	Enquire
5	10519424	WASHER	10519424 WASHER	-	1	Enquire
6	147966	Pipe from pump to front circuit control unit	147966 Pipe from pump to front circuit control unit front circuit control unit / Not for GD	-	1	Enquire
7	147968	Pipe from pump to rear circuit control unit	147968 Pipe from pump to rear circuit control unit rear circuit control unit / Not for GD	-	1	Enquire
8	155923	Brake pipe from control unit to RH front flexible cable	155923 Brake pipe from control unit to RH front flexible cable R.H. front flexible cable / Not for GD	-	1	Enquire
9	155924	Brake pipe from control unit to LH front flexible cable	155924 Brake pipe from control unit to LH front flexible cable L.H. front flexible cable / Not for GD	-	1	Enquire
10	155925	Brake pipe from control unit to brake pressure regulator	155925 Brake pipe from control unit to brake pressure regulator brake pressure regulator / Not for GD	-	1	Enquire
11	14054511	NUT	14054511 NUT	-	1	Enquire
12	159266	Front sensor	159266 Front sensor	-	2	Enquire
13	151330	Sensor support	151330 Sensor support	-	2	Enquire
14	60909500	ALLEN HEAD SCREW M6 X 15	60909500 ALLEN HEAD SCREW M6 X 15	-	6	Enquire
15	127494	WASHER	127494 WASHER	-	6	Enquire
16	137669	BRACKET	137669 BRACKET	-	1	Enquire
17	147951	Brake pupe from brake pressure regulator to 3 way union	147951 Brake pupe from brake pressure regulator to 3 way union regulator to 3-way union / Not for GD	-	1	Enquire
18	147980	Brake pipe from 3 way union to RH rear flexible cable	147980 Brake pipe from 3 way union to RH rear flexible cable R.H. rear flexible cable	-	1	Enquire
19	147981	Brake pipe from 3 way union to LH rear flexible cable	147981 Brake pipe from 3 way union to LH rear flexible cable L.H. rear flexible cable	-	1	Enquire
20	101394	3 WAY UNION	101394 3 WAY UNION	-	1	Enquire
21	151179	R.H. support	151179 R.H. support	-	1	Enquire
22	143405	FASTON TONGUE	143405 FASTON TONGUE	-	2	Enquire
23	319201	FUEL FILLER PIPE ASSEMBLY	319201 FUEL FILLER PIPE ASSEMBLY	-	6	Enquire
24	62790300	NUT	62790300 NUT	-	4	Enquire
25	10519224	WASHER	10519224 WASHER	-	4	Enquire
26	128292	CLIP -For GD q.ty 2-	128292 CLIP -For GD q.ty 2-	-	4	Enquire
27	10519424	WASHER	10519424 WASHER	-	4	Enquire
28	152422	Rear sensor protection	152422 Rear sensor protection	-	2	Enquire
29	159267	Rear sensor	159267 Rear sensor	-	2	Enquire
30	10440890	BRACKET WITH SHEATH	10440890 BRACKET WITH SHEATH	-	2	Enquire
31	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	2	Enquire
32	154747	Washer	154747 Washer Possible mounting	-	4	Enquire
33	10440990	BRACKET WITH SHEATH	10440990 BRACKET WITH SHEATH	-	2	Enquire
34	137313	R.H. and L.H. front flexible pipe	137313 R.H. and L.H. front flexible pipe	-	2	Enquire
35	271771	PIPE	271771 PIPE	-	2	Enquire
36	146949	Brake pressure regulator	146949 Brake pressure regulator	-	1	Enquire
