Find Your Part

REAR SHIELDS of Ferrari Ferrari 488 Pista Spider USA

View All

Ferrari 488 Pista Spider USA - REAR SHIELDS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	762216	COMPL. RH ENGINE AIR VENT DUCT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	762226	COMPL. LH ENGINE AIR VENT DUCT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	768520	RH REAR LATERAL DAM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	768518	LH REAR LATERAL DAM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10523401	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231620	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	87546300	COMPL. ENGINE BUFFER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12646678	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12640624	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12643724	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13027024	SCREW M6 X 16MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13290024	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	317169	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	768645	TYPE A PLATE FOR PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12647724	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	915271	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	880041	Allen Head Bolt M6 X 26	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	880041	Allen Head Bolt M6 X 26	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	815004	COMPL. ROOF TUB	Enquire	To Order
	985815004	COMPL. ROOF TUB	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85797600	SPECIAL SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85833700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	88076200	COMPL. RH ENGINE COMPARTMENT COSMETIC SHIELD	Enquire	To Order
	88076600	COMPL. RH ENGINE COMPARTMENT COSMETIC SHIELD	Enquire	To Order
	70006542	COMPL. RH ENGINE COMPARTMENT COSMETIC SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	88076100	COMPL. LH ENGINE COMPARTMENT COSMETIC SHIELD	Enquire	To Order
	70006543	COMPL. LH ENGINE COMPARTMENT COSMETIC SHIELD	Enquire	To Order
	88076500	COMPL. LH ENGINE COMPARTMENT COSMETIC SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	743830	COMPL. REAR UNDERBODY SHIELD	Enquire	To Order
	743830	COMPL. REAR UNDERBODY SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	86921700	COMPL. CENTRAL COSMETIC SHIELD	Enquire	To Order
	86935100	COMPL. CENTRAL COSMETIC SHIELD	Enquire	To Order
	70006353	COMPL. CENTRAL COSMETIC SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	87383800	RH SHIELD OUTER BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	87384000	LH SHIELD OUTER BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	867357	SERIAL NUMBER PLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	87260400	COSMETIC SHIELD INTERNAL BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	86880800	REAR COSMETIC SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	83911400	WATER DRAIN PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	82201000	ROOF TUB SEAL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	867730	COMPL. ROOF TUB SOUNDPROOFING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85164700	BUSH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	817640	COMPL. MEMBRANE MOUNTING BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	877468	ROOF TUB SEAL KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	815007	ROOF TUB HEAT SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	872545	RH ROOF TUB RESONATOR CAP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	874789	LH ROOF TUB RESONATOR CAP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	316527	COMPL. REAR CHASSIS REINFORCEMENT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	67315400	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	87258000	ENGINE COMPARTMENT COSMETIC SHIELD SEAL	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
0001	762216	COMPL. RH ENGINE AIR VENT DUCT	762216 COMPL. RH ENGINE AIR VENT DUCT	-	1	Enquire
0002	762226	COMPL. LH ENGINE AIR VENT DUCT	762226 COMPL. LH ENGINE AIR VENT DUCT	-	1	Enquire
0003	768520	RH REAR LATERAL DAM	768520 RH REAR LATERAL DAM	-	1	Enquire
0004	768518	LH REAR LATERAL DAM	768518 LH REAR LATERAL DAM	-	1	Enquire
0005	10523401	WASHER	10523401 WASHER	-	4	Enquire
0006	231620	SCREW	231620 SCREW M6 X 20 X 22	-	4	Enquire
0007	87546300	COMPL. ENGINE BUFFER	87546300 COMPL. ENGINE BUFFER	-	1	Enquire
0008	12646678	WASHER	12646678 WASHER	-	4	Enquire
0009	12640624	WASHER	12640624 WASHER	-	4	Enquire
0010	12643724	WASHER	12643724 WASHER	-	10	Enquire
0011	13027024	SCREW M6 X 16MM	13027024 SCREW M6 X 16MM M6 X 14	-	4	Enquire
0012	13290024	SCREW	13290024 SCREW M6 X 14	-	6	Enquire
0013	317169	SCREW	317169 SCREW M6 X 18	-	14	Enquire
0014	768645	TYPE A PLATE FOR PIN	768645 TYPE A PLATE FOR PIN	-	2	Enquire
0015	12647724	WASHER	12647724 WASHER 15 X 25 X 2	-	16	Enquire
0016	915271	SCREW	915271 SCREW M6 X 15	-	2	Enquire
0017	880041	Allen Head Bolt M6 X 26	880041 Allen Head Bolt M6 X 26 M6 X 20	-	11	Enquire
0018	880041	Allen Head Bolt M6 X 26	880041 Allen Head Bolt M6 X 26 M6 X 22	-	6	Enquire
0019	815004	COMPL. ROOF TUB	815004 COMPL. ROOF TUB Applies until depletion	-	1	Enquire
0019	985815004	COMPL. ROOF TUB	985815004 COMPL. ROOF TUB Applicable after depletion of 815004	-	1	Enquire
0020	85797600	SPECIAL SCREW	85797600 SPECIAL SCREW M5	-	2	Enquire
0021	85833700	SCREW	85833700 SCREW M5 X 16	-	10	Enquire
0022	88076200	COMPL. RH ENGINE COMPARTMENT COSMETIC SHIELD	88076200 COMPL. RH ENGINE COMPARTMENT COSMETIC SHIELD	-	1	Enquire
0022	88076600	COMPL. RH ENGINE COMPARTMENT COSMETIC SHIELD	88076600 COMPL. RH ENGINE COMPARTMENT COSMETIC SHIELD Naked weave carbon engine comp. shields; Carbon	-	1	Enquire
0022	70006542	COMPL. RH ENGINE COMPARTMENT COSMETIC SHIELD	70006542 COMPL. RH ENGINE COMPARTMENT COSMETIC SHIELD Engine comp. shields in coloured naked weave carbon - CECM - CECM for colour and finish selection - For better colour match, also order adjacent off-catalogue components; Off-catalogue version	-	1	Enquire
0023	88076100	COMPL. LH ENGINE COMPARTMENT COSMETIC SHIELD	88076100 COMPL. LH ENGINE COMPARTMENT COSMETIC SHIELD	-	1	Enquire
0023	70006543	COMPL. LH ENGINE COMPARTMENT COSMETIC SHIELD	70006543 COMPL. LH ENGINE COMPARTMENT COSMETIC SHIELD Engine comp. shields in coloured naked weave carbon - CECM - CECM for colour and finish selection - For better colour match, also order adjacent off-catalogue components; Off-catalogue version	-	1	Enquire
0023	88076500	COMPL. LH ENGINE COMPARTMENT COSMETIC SHIELD	88076500 COMPL. LH ENGINE COMPARTMENT COSMETIC SHIELD Naked weave carbon engine comp. shields; Carbon	-	1	Enquire
0024	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2	-	4	Enquire
0025	743830	COMPL. REAR UNDERBODY SHIELD	743830 COMPL. REAR UNDERBODY SHIELD	-	1	Enquire
0025	743830	COMPL. REAR UNDERBODY SHIELD	743830 COMPL. REAR UNDERBODY SHIELD	-	1	Enquire
0026	86921700	COMPL. CENTRAL COSMETIC SHIELD	86921700 COMPL. CENTRAL COSMETIC SHIELD	-	1	Enquire
0026	86935100	COMPL. CENTRAL COSMETIC SHIELD	86935100 COMPL. CENTRAL COSMETIC SHIELD Naked weave carbon engine comp. shields; Carbon	-	1	Enquire
0026	70006353	COMPL. CENTRAL COSMETIC SHIELD	70006353 COMPL. CENTRAL COSMETIC SHIELD Engine comp. shields in coloured naked weave carbon - CECM - CECM for colour and finish selection - For better colour match, also order adjacent off-catalogue components; Off-catalogue version	-	1	Enquire
0027	87383800	RH SHIELD OUTER BRACKET	87383800 RH SHIELD OUTER BRACKET	-	1	Enquire
0028	87384000	LH SHIELD OUTER BRACKET	87384000 LH SHIELD OUTER BRACKET Not for version with lift system	-	1	Enquire
0029	867357	SERIAL NUMBER PLATE	867357 SERIAL NUMBER PLATE	-	1	Enquire
0030	87260400	COSMETIC SHIELD INTERNAL BRACKET	87260400 COSMETIC SHIELD INTERNAL BRACKET	-	1	Enquire
0031	86880800	REAR COSMETIC SHIELD	86880800 REAR COSMETIC SHIELD	-	1	Enquire
0032	83911400	WATER DRAIN PIPE	83911400 WATER DRAIN PIPE	-	2	Enquire
0033	82201000	ROOF TUB SEAL	82201000 ROOF TUB SEAL	-	1	Enquire
0034	867730	COMPL. ROOF TUB SOUNDPROOFING	867730 COMPL. ROOF TUB SOUNDPROOFING	-	1	Enquire
0035	85164700	BUSH	85164700 BUSH	-	4	Enquire
0036	817640	COMPL. MEMBRANE MOUNTING BRACKET	817640 COMPL. MEMBRANE MOUNTING BRACKET	-	1	Enquire
0037	877468	ROOF TUB SEAL KIT	877468 ROOF TUB SEAL KIT	-	1	Enquire
0038	815007	ROOF TUB HEAT SHIELD	815007 ROOF TUB HEAT SHIELD	-	1	Enquire
0039	872545	RH ROOF TUB RESONATOR CAP	872545 RH ROOF TUB RESONATOR CAP	-	1	Enquire
0040	874789	LH ROOF TUB RESONATOR CAP	874789 LH ROOF TUB RESONATOR CAP	-	1	Enquire
0041	316527	COMPL. REAR CHASSIS REINFORCEMENT	316527 COMPL. REAR CHASSIS REINFORCEMENT	-	1	Enquire
0042	67315400	WASHER	67315400 WASHER	-	16	Enquire
0043	87258000	ENGINE COMPARTMENT COSMETIC SHIELD SEAL	87258000 ENGINE COMPARTMENT COSMETIC SHIELD SEAL	-	2	Enquire
