Find Your Part

HI-FI SYSTEM of Ferrari Ferrari 430 Scuderia Spider 16M

View All

Ferrari 430 Scuderia Spider 16M - HI-FI SYSTEM

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	229439	FERRARI CASCADE 7909	Enquire	To Order
	249531	FERRARI CASCADE 6112 (SW 4.0)	Enquire	To Order
	249530	FERRARI CASCADE 6112 (SW 4.0)	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	201355	PRE-AMPLIFIER FOR ANTENNA	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	201353	AERIAL CABLE TO WINDSCREEN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	201354	AERIAL CABLE TO RADIO	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11568124	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62769800	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	194414	CD CHARGER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	208652	GPS ANTENNA	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62769800	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	255515	BUSH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	67960900	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11568124	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	80403500	COVER	Enquire	To Order
	81056700	COVER	Enquire	To Order
	80759700	COVER	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	254875	NAVISET CF KIT (SW 4.0)	Enquire	To Order
	254875	NAVISET CF KIT (SW 4.0)	Enquire	To Order
	70003195	System CD Radio Becker ''Cascade'' - Release 3.61 - Navigator Radio Version - Not for USA	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	234622	REMOVABLE FRONT PANEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	253622	ELECTRIC WIRING HARNESS	Enquire	To Order
	245142	ELECTRIC WIRING HARNESS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	185970	TWEETER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	254875	NAVISET CF KIT (SW 4.0)	Enquire	To Order
	70003195	System CD Radio Becker ''Cascade'' - Release 3.61 - Navigator Radio Version - Not for USA	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	219409	HANDS FREE SYSTEM WIRING HARNESS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	254695	iPod TOUCH BOX	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	254702	CD CONTENTS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	254697	iPod TOUCH CASE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	254699	iPod TOUCH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	254701	iPod TOUCH INSTRUCTION MANUAL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	82142800	iPod TOUCH SUPPORT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	257040	WIRING HARNESS FOR iPod TOUCH	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	229439	FERRARI CASCADE 7909	229439 FERRARI CASCADE 7909 Applicable for J	-	1	Enquire
1	249531	FERRARI CASCADE 6112 (SW 4.0)	249531 FERRARI CASCADE 6112 (SW 4.0) For vehicles without SW version 4.0, also replace Naviset CF kit (SW version 4.0) Part No. 254875; Applicable for USA, CDN	-	1	Enquire
1	249530	FERRARI CASCADE 6112 (SW 4.0)	249530 FERRARI CASCADE 6112 (SW 4.0) For vehicles without SW version 4.0, also replace Naviset CF kit (SW version 4.0) Part No. 254874; Not for USA, CDN, J	-	1	Enquire
2	201355	PRE-AMPLIFIER FOR ANTENNA	201355 PRE-AMPLIFIER FOR ANTENNA	-	1	Enquire
3	201353	AERIAL CABLE TO WINDSCREEN	201353 AERIAL CABLE TO WINDSCREEN	-	1	Enquire
4	201354	AERIAL CABLE TO RADIO	201354 AERIAL CABLE TO RADIO	-	1	Enquire
5	11568124	SCREW	11568124 SCREW	-	1	Enquire
6	62769800	WASHER	62769800 WASHER	-	1	Enquire
7	194414	CD CHARGER	194414 CD CHARGER Not for Spider 16M	-	1	Enquire
8	208652	GPS ANTENNA	208652 GPS ANTENNA Optional	-	1	Enquire
9	62769800	WASHER	62769800 WASHER Not for Spider 16M	-	2	Enquire
10	255515	BUSH	255515 BUSH Optional	-	1	Enquire
11	67960900	BRACKET	67960900 BRACKET Not for Spider 16M	-	2	Enquire
12	11568124	SCREW	11568124 SCREW Not for Spider 16M	-	4	Enquire
13	12574017	NUT	12574017 NUT Not for Spider 16M	-	4	Enquire
14	80403500	COVER	80403500 COVER	-	1	Enquire
14	81056700	COVER	81056700 COVER Carbon version	-	1	Enquire
14	80759700	COVER	80759700 COVER Leather Version	-	1	Enquire
14	82098100	COVER	82098100 COVER Applicable for quarterlight; Not for Spider 16M	-	1	Enquire
15	254875	NAVISET CF KIT (SW 4.0)	254875 NAVISET CF KIT (SW 4.0) Applicable for Spider 16M; Applicable for USA, CDN	-	1	Enquire
15	254875	NAVISET CF KIT (SW 4.0)	254875 NAVISET CF KIT (SW 4.0) Release 3.61; Not for Spider 16M; Applicable for USA, CDN	-	1	Enquire
15	70003195	System CD Radio Becker ''Cascade'' - Release 3.61 - Navigator Radio Version - Not for USA	70003195 System CD Radio Becker ''Cascade'' - Release 3.61 - Navigator Radio Version - Not for USA Release 3.61; Not for Spider 16M; Not for USA, CDN	-	1	Enquire
15	70003195	System CD Radio Becker ''Cascade'' - Release 3.61 - Navigator Radio Version - Not for USA	70003195 System CD Radio Becker ''Cascade'' - Release 3.61 - Navigator Radio Version - Not for USA Not for Spider 16M; Not for USA, CDN	-	1	Enquire
16	234622	REMOVABLE FRONT PANEL	234622 REMOVABLE FRONT PANEL	-	1	Enquire
17	253622	ELECTRIC WIRING HARNESS	253622 ELECTRIC WIRING HARNESS Applicable for Spider 16M	-	1	Enquire
17	245142	ELECTRIC WIRING HARNESS	245142 ELECTRIC WIRING HARNESS Not for Spider 16M; Applicable for GD	-	1	Enquire
18	185970	TWEETER	185970 TWEETER Not for Spider 16M	-	2	Enquire
19	254875	NAVISET CF KIT (SW 4.0)	254875 NAVISET CF KIT (SW 4.0) Release 3.61; Not for Spider 16M; Applicable for USA, CDN	-	1	Enquire
19	70003195	System CD Radio Becker ''Cascade'' - Release 3.61 - Navigator Radio Version - Not for USA	70003195 System CD Radio Becker ''Cascade'' - Release 3.61 - Navigator Radio Version - Not for USA Release 3.61; Not for Spider 16M; Not for USA, CDN	-	1	Enquire
20	219409	HANDS FREE SYSTEM WIRING HARNESS	219409 HANDS FREE SYSTEM WIRING HARNESS With Bluetooth hands-free microphone; No opt. CD charger; Not for Spider 16M	-	1	Enquire
21	254695	iPod TOUCH BOX	254695 iPod TOUCH BOX Applicable for Spider 16M	-	1	Enquire
22	254702	CD CONTENTS	254702 CD CONTENTS Applicable for Spider 16M	-	1	Enquire
23	254697	iPod TOUCH CASE	254697 iPod TOUCH CASE Alcantara; Applicable for Spider 16M	-	1	Enquire
24	254699	iPod TOUCH	254699 iPod TOUCH Applicable for Spider 16M	-	1	Enquire
25	254701	iPod TOUCH INSTRUCTION MANUAL	254701 iPod TOUCH INSTRUCTION MANUAL Applicable for Spider 16M	-	1	Enquire
26	82142800	iPod TOUCH SUPPORT	82142800 iPod TOUCH SUPPORT Applicable for Spider 16M	-	1	Enquire
27	257040	WIRING HARNESS FOR iPod TOUCH	257040 WIRING HARNESS FOR iPod TOUCH Applicable for Spider 16M	-	1	Enquire
