Ferrari 360 Modena - INJECTION DEVICE - IGNITION

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
199876 L.H. SIDE ENGINE INJECTION CABLES Enquire To Order
199874 L.H. SIDE ENGINE INJECTION CABLES Enquire To Order
199875 R.H. SIDE ENGINE INJECTION CABLES Enquire To Order
...and 2 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
177074 Single Ignition Coil Enquire To Order
Photo Part No Description Price (each) Stock
10902424 SCREW Enquire To Order
10902534 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
11197774 WAVY WASHER D.6.4 X 12 X 1.2 Enquire To Order
Photo Part No Description Price (each) Stock
192637 Spark Plug NGK Enquire ARRIVING SOON
192637 Spark Plug NGK Enquire ARRIVING SOON
Photo Part No Description Price (each) Stock
197808 Electro-Injector Enquire To Order
197808 Electro-Injector Enquire To Order
Photo Part No Description Price (each) Stock
133902 O-Ring Enquire To Order
Photo Part No Description Price (each) Stock
144730 INJECTORS RETENTION CLIP Enquire To Order
Photo Part No Description Price (each) Stock
14306424 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
12601374 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
206421 CONTROL UNIT IGNITION Enquire To Order
206423 CONTROL UNIT IGNITION Enquire To Order
201752 CONTROL UNIT IGNITION Enquire To Order
...and 19 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
174956 L.H. PLATE Enquire To Order
189978 R.H. PLATE Enquire To Order
177984 R.H. PLATE Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
15896470 NUT Enquire To Order
Photo Part No Description Price (each) Stock
12604178 Washer Enquire To Order
Photo Part No Description Price (each) Stock
86574700 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
198348 LH COMPLETE FUEL TUBE WITH ELECTRO-INJECTORS Enquire To Order
198348 LH COMPLETE FUEL TUBE WITH ELECTRO-INJECTORS Enquire To Order
198347 RH COMPLETE FUEL TUBE WITH ELECTRO-INJECTORS Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
185316 EMERGENCY SWITCH BRACKET Enquire To Order
Photo Part No Description Price (each) Stock
179243 PLATE Enquire To Order
Photo Part No Description Price (each) Stock
178430 FASTENER CLIP Enquire To Order
View All
INJECTION DEVICE - IGNITION of Ferrari Ferrari 360 Modena Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 199876
L.H. SIDE ENGINE INJECTION CABLES
Valid for USA MY 2000,2001,2002,2003,2004 and / CDN MY 2000,2001,2002,2003,2004-- Valid till Ass. Nr. 44103 / Valid till stock exhaustion / 		- 1 Enquire
1 199874
L.H. SIDE ENGINE INJECTION CABLES
Not for USA MY 2000,2001,2002,2003,2004 and / CDN MY 2000,2001,2002,2003,2004 / Valid till Ass. Nr. 44103 / Valid till stock exhaustion 		- 1 Enquire
1 199875
R.H. SIDE ENGINE INJECTION CABLES
Valid for USA MY 2000,2001,2002,2003,2004 and / CDN MY 2000,2001,2002,2003,2004 / Valid from Ass. Nr. 44104 / Valid till stock exhaustion / 		- 1 Enquire
1 199875
R.H. SIDE ENGINE INJECTION CABLES
Valid for USA MY 2000,2001,2002,2003,2004 and / CDN MY 2000,2001,2002,2003,2004 / Valid till Ass. Nr. 44103 / Valid till stock exhaustion 		- 1 Enquire
1 199873
R.H. SIDE ENGINE INJECTION CABLES
Not for USA MY 2000,2001,2002,2003,2004 and / CDN MY 2000,2001,2002,2003,2004 / Valid till Ass. Nr. 44103 / Valid till stock exhaustion 		- 1 Enquire
2 177074
Single Ignition Coil 		- 8 Enquire
3 10902424
SCREW
Not as spare part / Replaced by 10902534 		- 16 Enquire
3 10902534
SCREW 		- 16 Enquire
4 11197774
WAVY WASHER D.6.4 X 12 X 1.2 		- 16 Enquire
5 192637
Spark Plug NGK
ARRIVING SOON 		- 8 Enquire
5 192637
Spark Plug NGK
ARRIVING SOON 		- 8 Enquire
6 197808
Electro-Injector 		- 8 Enquire
6 197808
Electro-Injector 		- 8 Enquire
7 133902
O-Ring 		- 16 Enquire
8 144730
INJECTORS RETENTION CLIP 		- 8 Enquire
9 14306424
SCREW 		- 4 Enquire
10 12601374
WASHER 		- 4 Enquire
11 206421
CONTROL UNIT IGNITION
/ Not for USA and CDN / Valid for racing exhaust version / Optional / 		- 2 Enquire
11 206423
CONTROL UNIT IGNITION
Valid for F1 / Not for USA and CDN / Valid for racing exhaust version / Optional 		- 2 Enquire
11 201752
CONTROL UNIT IGNITION
Valid for F1 / Valid for USA MY 2004 and CDN MY 2004 		- 2 Enquire
11 206424
CONTROL UNIT IGNITION
/ Valid for USA and CDN / Valid for racing exhaust version / Optional / 		- 2 Enquire
11 206425
CONTROL UNIT IGNITION
Valid for F1 / Valid for USA and CDN / Valid for racing exhaust version / Optional 		- 2 Enquire
11 197913
CONTROL UNIT IGNITION
Valid for F1 / Valid for USA MY 2002 and CDN MY 2002 / Not for USA MY 2003,2004 and CDN MY 2003,2004 		- 2 Enquire
11 197913
CONTROL UNIT IGNITION
Valid for F1 / Vale for USA MY 2003 and CDN MY 2003 		- 2 Enquire
11 181642
CONTROL UNIT IGNITION
Valid for F1- -Not for USA, CDN and AUS / Valid for USA MY 2000, USA MY 2001, / CDN MY 2000 and CDN MY 2001 / Not for USA MY 2002,2003,2004 and CDN MY / 2002,2003,2004 		- 2 Enquire
11 209974
CONTROL UNIT IGNITION
Valid for F1 / Valid from Nr.53911 for AUS / For cars not USA, CDN and AUS valid from / Ass. Nr. 57451 		- 2 Enquire
11 182630
CONTROL UNIT IGNITION
Valid for F1 / Valid for not catalyzed cars / Not for USA, CDN and AUS / 		- 2 Enquire
11 178784
CONTROL UNIT IGNITION
Valid for F1 / Not for USA MY 2000,2001,2002,2003,2004 / and CDN MY 2000,2001,2002,2003,2004 / Valid till Ass. Nr.53910 for AUS 		- 2 Enquire
11 209974
CONTROL UNIT IGNITION
Valid for F1 / Valid for catalyzed cars- -Not for USA, CDN and AUS / Valid for EU GS F1 and J F1 from car / Ass.Nr. 39160 / Valid for GB F1 from car Ass.Nr. 39149 / Valid till Ass. Nr. 57450 		- 2 Enquire
11 197914
CONTROL UNIT IGNITION
/ Valid for USA MY 2003 and CDN MY / 2003 / 		- 2 Enquire
11 201747
CONTROL UNIT IGNITION
/ Valid for USA MY 2004 and CDN MY / 2004 / 		- 2 Enquire
11 178765
CONTROL UNIT IGNITION
Valid for F1 / Valid for catalyzed cars- -Not for USA, CDN and AUS / Valid for EU GS F1 and J F1 till car / Ass.Nr. 39159 / Valid for GB F1 till car Ass.Nr. 39148 		- 2 Enquire
11 197914
CONTROL UNIT IGNITION
/ Valid for USA MY 2002 and CDN MY 2002 / Not for USA MY 2003,2004 and CDN MY 2003,2004 / 		- 2 Enquire
11 209973
CONTROL UNIT IGNITION
/ Valid from Nr.53911 for AUS / For cars not USA, CDN and AUS valid from / Ass. Nr. 57451 		- 2 Enquire
11 180700
CONTROL UNIT IGNITION -Not for F1-
Valid for USA MY 2000, USA MY 2001, / CDN MY 2000 and CDN MY 2001 / Not for USA MY 2002,2003 and CDN MY 2002, / 2003,2004 / 		- 2 Enquire
11 178768
CONTROL UNIT IGNITION
Not for F1- -Valid for USA, CDN and AUS / Not for USA MY 2000,2001,2002,2003,2004 / and CDN MY 2000,2001,2002,2003,2004 / Valid till Ass. Nr.53910 for AUS / / 		- 2 Enquire
11 209973
CONTROL UNIT IGNITION
Not for F1- -Valid for catalyzed cars / Not for USA, CDN and AUS / Valid for EU GS not F1 and J not F1 from car / Ass.Nr. 39159 / Valid for GB not F1 from car Ass.Nr. 39145 / Valid till Ass. Nr. 57450 		- 2 Enquire
11 180101
CONTROL UNIT IGNITION
/ Valid for not catalyzed cars / Not for USA, CDN and AUS / 		- 2 Enquire
11 178285
CONTROL UNIT IGNITION
/ Valid for catalyzed cars- -Not for USA, CDN and AUS / Valid for EU GS not F1 and J not F1 till car / Ass.Nr. 39158 / Valid for GB not F1 till car Ass.Nr. 39144 		- 2 Enquire
12 174956
L.H. PLATE 		- 1 Enquire
12 189978
R.H. PLATE
For cars not USA and CDN valid from Ass. Nr. 44737 / For cars USA MY 2002,2003 and CDN MY 2002,2003, / 2004valid from Ass. Nr. 44739 		- 1 Enquire
12 177984
R.H. PLATE
Not for USA MY 2000,2001,2002,2003,2004 and / CDN MY 2000,2001,2002,2003,2004 / Valid till car Ass. Nr. 44736 		- 1 Enquire
12 179553
R.H. PLATE
Valid for USA MY 2000,2001,2002,2003,2004 and / CDN MY 2000,2001,2002,2003,2004 / Valid till car Ass. Nr. 44738 		- 1 Enquire
13 15896470
NUT 		- 8 Enquire
14 12604178
Washer 		- 8 Enquire
15 86574700
SCREW 		- 4 Enquire
16 198348
LH COMPLETE FUEL TUBE WITH ELECTRO-INJECTORS
WITH ELECTRO-INJECTORS / Valid till stock exhaustion 		- 1 Enquire
16 198348
LH COMPLETE FUEL TUBE WITH ELECTRO-INJECTORS
WITH ELECTRO-INJECTORS 		- 1 Enquire
16 198347
RH COMPLETE FUEL TUBE WITH ELECTRO-INJECTORS
WITH ELECTRO-INJECTORS / Valid till stock exhaustion 		- 1 Enquire
16 198347
RH COMPLETE FUEL TUBE WITH ELECTRO-INJECTORS
WITH ELECTRO-INJECTORS 		- 1 Enquire
17 185316
EMERGENCY SWITCH BRACKET
BRACKET 		- 1 Enquire
18 179243
PLATE 		- 2 Enquire
19 178430
FASTENER CLIP 		- 2 Enquire
