Clutch Release Control -Not For Gd-

Ferrari 348 (2.7 Motronic)

Find Your Part

Ferrari 348 (2.7 Motronic) - CLUTCH RELEASE CONTROL -Not for GD-

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
157268 CLUTCH PEDAL Enquire To Order
Photo Part No Description Price (each) Stock
157273 PEDAL SLAB Enquire To Order
Photo Part No Description Price (each) Stock
103163 SELF-LUBRICATING BUSHING Enquire To Order
Photo Part No Description Price (each) Stock
109407 BALL-JOINT Enquire To Order
Photo Part No Description Price (each) Stock
101305 SPRING Enquire To Order
Photo Part No Description Price (each) Stock
187014 PEDAL ADJUSTER SCREW Enquire To Order
Photo Part No Description Price (each) Stock
16102314 NUT Enquire To Order
Photo Part No Description Price (each) Stock
129615 GASKET Enquire To Order
Photo Part No Description Price (each) Stock
13525770 THREADED INSERT Enquire To Order
Photo Part No Description Price (each) Stock
143041 SPACER Enquire To Order
Photo Part No Description Price (each) Stock
14499370 Washer Enquire To Order
Photo Part No Description Price (each) Stock
14059290 FLANGED NUT M6 Enquire To Order
Photo Part No Description Price (each) Stock
129612 SPRING ANCHOR PIN Enquire To Order
Photo Part No Description Price (each) Stock
11500124 STUD BOLT Enquire To Order
Photo Part No Description Price (each) Stock
129613 PEDALS SUPPORT PIN Enquire To Order
Photo Part No Description Price (each) Stock
101314 BUSHING Enquire To Order
Photo Part No Description Price (each) Stock
112153 BUSHING Enquire To Order
Photo Part No Description Price (each) Stock
112125 SPACER WASHER Enquire To Order
Photo Part No Description Price (each) Stock
112127 DITTO THICKNESS mm. 0.9 Enquire To Order
Photo Part No Description Price (each) Stock
11066676 FLEXIBLE RING Enquire To Order
Photo Part No Description Price (each) Stock
13516824 STUD BOLT Enquire To Order
Photo Part No Description Price (each) Stock
104030 NYLOC NUT M8 X 1.25 X 9.5 Enquire To Order
Photo Part No Description Price (each) Stock
14499421 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
62877200 PEDAL SUPPORT PROTECTION Enquire To Order
Photo Part No Description Price (each) Stock
62694400 GASKET Enquire To Order
Photo Part No Description Price (each) Stock
14059290 FLANGED NUT M6 Enquire To Order
Photo Part No Description Price (each) Stock
12646604 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
15925601 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
104030 NYLOC NUT M8 X 1.25 X 9.5 Enquire To Order
Photo Part No Description Price (each) Stock
14499421 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
175211 Clutch master cylinder Enquire To Order
Photo Part No Description Price (each) Stock
16102314 NUT Enquire To Order
Photo Part No Description Price (each) Stock
13516824 STUD BOLT Enquire To Order
Photo Part No Description Price (each) Stock
14040711 NUT M8 FLANGED Enquire To Order
Photo Part No Description Price (each) Stock
12638524 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
10248271 FORK FOR CLUTCH LEVER Enquire To Order
Photo Part No Description Price (each) Stock
130926 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
16104411 Selflocking nut Enquire To Order
Photo Part No Description Price (each) Stock
151845 PIPE FROM CLUTCH PUMP TO Enquire To Order
Photo Part No Description Price (each) Stock
157934 SCREW COLLAR Enquire To Order
Photo Part No Description Price (each) Stock
140669 HOSE Enquire To Order
Photo Part No Description Price (each) Stock
105369 CABLE GROMMET Enquire To Order
Photo Part No Description Price (each) Stock
232649 CLIP Enquire To Order
Photo Part No Description Price (each) Stock
139375 2-WAY UNION Enquire To Order
Photo Part No Description Price (each) Stock
14059290 FLANGED NUT M6 Enquire To Order
Photo Part No Description Price (each) Stock
14499370 Washer Enquire To Order
Photo Part No Description Price (each) Stock
140666 INTERMEDIATE TUBE Enquire To Order
Photo Part No Description Price (each) Stock
141522 CLIP Enquire To Order
Photo Part No Description Price (each) Stock
141521 CLIP Enquire To Order
Photo Part No Description Price (each) Stock
240774 CONNECTOR Enquire To Order
Photo Part No Description Price (each) Stock
14059290 FLANGED NUT M6 Enquire To Order
Photo Part No Description Price (each) Stock
62797600 Allen Bolt Countersunk M6 x 20 Enquire To Order
Photo Part No Description Price (each) Stock
149295 PEDAL SLAB Enquire To Order
Photo Part No Description Price (each) Stock
184497 CONNECTOR Enquire To Order
Photo Part No Description Price (each) Stock
175189 SEAT RING Enquire To Order
View All
CLUTCH RELEASE CONTROL -Not for GD- of Ferrari Ferrari 348 (2.7 Motronic) Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
- 112131
DITTO THICKNESS mm. 1.3
Possible fitting 		- 1 Enquire
- 112128
DITTO THICKNESS mm. 1.0
Possible fitting 		- 1 Enquire
- 112129
DITTO THICKNESS mm. 1.1
Possible fitting 		- 1 Enquire
- 112130
DITTO THICKNESS mm. 1.2
Possible fitting 		- 1 Enquire
- 147690
COMPLETE PEDAL SUPPORT 		- 1 Enquire
- 149293
CLUTCH PEDAL
Valid for Spider 		- 1 Enquire
1 157268
CLUTCH PEDAL
Not for Spider 		- 1 Enquire
2 157273
PEDAL SLAB
Not for Spider 		- 1 Enquire
3 103163
SELF-LUBRICATING BUSHING 		- 2 Enquire
4 109407
BALL-JOINT 		- 1 Enquire
5 101305
SPRING 		- 1 Enquire
6 187014
PEDAL ADJUSTER SCREW 		- 2 Enquire
7 16102314
NUT 		- 2 Enquire
9 129615
GASKET 		- 1 Enquire
10 13525770
THREADED INSERT 		- 2 Enquire
11 143041
SPACER 		- 1 Enquire
12 14499370
Washer 		- 1 Enquire
13 14059290
FLANGED NUT M6 		- 2 Enquire
14 129612
SPRING ANCHOR PIN 		- 1 Enquire
15 11500124
STUD BOLT 		- 4 Enquire
16 129613
PEDALS SUPPORT PIN 		- 1 Enquire
17 101314
BUSHING 		- 1 Enquire
18 112153
BUSHING 		- 1 Enquire
19 112125
SPACER WASHER 		- 1 Enquire
20 112127
DITTO THICKNESS mm. 0.9
Possible fitting 		- 1 Enquire
21 11066676
FLEXIBLE RING 		- 1 Enquire
22 13516824
STUD BOLT 		- 4 Enquire
23 104030
NYLOC NUT M8 X 1.25 X 9.5 		- 4 Enquire
24 14499421
WASHER 		- 4 Enquire
25 62877200
PEDAL SUPPORT PROTECTION 		- 1 Enquire
26 62694400
GASKET 		- 1 Enquire
27 14059290
FLANGED NUT M6 		- 2 Enquire
28 12646604
WASHER 		- 3 Enquire
29 15925601
SCREW 		- 1 Enquire
30 104030
NYLOC NUT M8 X 1.25 X 9.5 		- 1 Enquire
31 14499421
WASHER 		- 1 Enquire
32 175211
Clutch master cylinder 		- 1 Enquire
33 16102314
NUT 		- 1 Enquire
34 13516824
STUD BOLT 		- 2 Enquire
35 14040711
NUT M8 FLANGED 		- 2 Enquire
36 12638524
WASHER 		- 2 Enquire
37 10248271
FORK FOR CLUTCH LEVER 		- 1 Enquire
38 130926
SCREW 		- 1 Enquire
39 16104411
Selflocking nut 		- 1 Enquire
40 151845
PIPE FROM CLUTCH PUMP TO 		- 1 Enquire
41 157934
SCREW COLLAR 		- 2 Enquire
42 140669
HOSE 		- 1 Enquire
43 105369
CABLE GROMMET 		- 1 Enquire
44 232649
CLIP 		- 1 Enquire
45 139375
2-WAY UNION 		- 1 Enquire
46 14059290
FLANGED NUT M6 		- 1 Enquire
47 14499370
Washer 		- 1 Enquire
48 140666
INTERMEDIATE TUBE 		- 1 Enquire
49 141522
CLIP 		- 9 Enquire
50 141521
CLIP 		- 2 Enquire
51 240774
CONNECTOR 		- 1 Enquire
52 14059290
FLANGED NUT M6 		- 1 Enquire
53 62797600
Allen Bolt Countersunk M6 x 20 		- 2 Enquire
54 149295
PEDAL SLAB
Valid for Spider 		- 1 Enquire
55 184497
CONNECTOR 		- 1 Enquire
56 175189
SEAT RING 		- 1 Enquire
