Find Your Part

BATTERIES of Ferrari Ferrari 296 GTB Europe

View All

Ferrari 296 GTB Europe - BATTERIES

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	766996	HVB BATTERY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	962530	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	962531	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	966818	LITHIUM BATTERY	Enquire	To Order
	949042	BATTERY	Enquire	To Order
	966818	LITHIUM BATTERY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	840964	VENTING PIPE	Enquire	To Order
	884483	VENTING PIPE	Enquire	To Order
	950103	BATTERY VENT	Enquire	To Order

...and 3 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	935783	VENTING BLOCK	Enquire	To Order
	950118	BATTERY VENT BLOCK	Enquire	To Order
	935783	VENTING BLOCK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	817742	VENTING PIPE FLANGE GASKET	Enquire	To Order
	817742	VENTING PIPE FLANGE GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62797600	Allen Bolt Countersunk M6 x 20	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	322605	SPACER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	310112	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	199631	UNION FOR BATTERY BLEEDER PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	779107	LEAD ACID BATTERY INSTALLATION KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	834740	BATTERY BREATHER CAP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	859545	TEMPERATURE SENSOR	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	766996	HVB BATTERY	766996 HVB BATTERY See TI 2932	-	1	Enquire
2	962530	SCREW	962530 SCREW M10 X 1.25 X 40	-	4	Enquire
3	962531	SCREW	962531 SCREW M10 X 1.25 X 30	-	2	Enquire
4	966818	LITHIUM BATTERY	966818 LITHIUM BATTERY 40 Ah - With 30% charge - Version for lithium battery - After depletion of stock, order lead acid battery 949042, see TI 2950 for installation; Applies until depletion	-	1	Enquire
4	949042	BATTERY	949042 BATTERY 50 Ah - Version for lead battery - See TI 2950 for installation procedure for lead acid battery; Applicable after depletion of 966818	-	1	Enquire
4	966818	LITHIUM BATTERY	966818 LITHIUM BATTERY	-	1	Enquire
5	840964	VENTING PIPE	840964 VENTING PIPE Version for lithium battery	-	1	Enquire
5	884483	VENTING PIPE	884483 VENTING PIPE Version for lithium battery	-	1	Enquire
5	950103	BATTERY VENT	950103 BATTERY VENT Version for lead battery	-	1	Enquire
5	950678	BATTERY VENT	950678 BATTERY VENT Version for lead battery	-	1	Enquire
5	840964	VENTING PIPE	840964 VENTING PIPE	-	1	Enquire
5	884483	VENTING PIPE	884483 VENTING PIPE	-	1	Enquire
6	935783	VENTING BLOCK	935783 VENTING BLOCK Version for lithium battery	-	1	Enquire
6	950118	BATTERY VENT BLOCK	950118 BATTERY VENT BLOCK Version for lead battery - Also included with lead acid battery installation kit	-	1	Enquire
6	935783	VENTING BLOCK	935783 VENTING BLOCK	-	1	Enquire
7	817742	VENTING PIPE FLANGE GASKET	817742 VENTING PIPE FLANGE GASKET Version for lithium battery	-	1	Enquire
7	817742	VENTING PIPE FLANGE GASKET	817742 VENTING PIPE FLANGE GASKET	-	1	Enquire
8	62797600	Allen Bolt Countersunk M6 x 20	62797600 Allen Bolt Countersunk M6 x 20 M5 X 10	-	2	Enquire
9	322605	SPACER	322605 SPACER Version for lead battery - Also included with lead acid battery installation kit	-	1	Enquire
10	310112	CLIP	310112 CLIP Version for lead battery - Also included with lead acid battery installation kit; 1 compartment-	-	1	Enquire
11	199631	UNION FOR BATTERY BLEEDER PIPE	199631 UNION FOR BATTERY BLEEDER PIPE Version for lead battery - Also included with lead acid battery installation kit	-	1	Enquire
12	779107	LEAD ACID BATTERY INSTALLATION KIT	779107 LEAD ACID BATTERY INSTALLATION KIT	-	1	Enquire
13	834740	BATTERY BREATHER CAP	834740 BATTERY BREATHER CAP Version for lead battery - Also included with lead acid battery installation kit	-	1	Enquire
14	859545	TEMPERATURE SENSOR	859545 TEMPERATURE SENSOR	-	2	Enquire
