Ferrari 296 GTS USA - DOORS - OPENING MECHANISMS AND HINGES

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
804870 RH DOOR LOCK $630.70 To Order
804886 RH DOOR LOCK $630.70 To Order
804856 LH DOOR LOCK $630.70 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
808736 DOOR LOCK STRIKER PLATE $19.24 To Order
Photo Part No Description Price (each) Stock
802693 DOOR STRIKER PLATE SHIM $7.73 To Order
Photo Part No Description Price (each) Stock
924578 DOOR STRIKER PLATE FILM $7.33 To Order
Photo Part No Description Price (each) Stock
85133400 SCREW $0.66 To Order
Photo Part No Description Price (each) Stock
80874100 SCREW $1.10 ARRIVING SOON
Photo Part No Description Price (each) Stock
980005 COMPL. INNER DOOR HANDLE BOWDEN CABLE $131.85 To Order
Photo Part No Description Price (each) Stock
831375 COMPL. DOOR HANDLE $12.66 To Order
Photo Part No Description Price (each) Stock
880232 UPPER COVER $8.17 To Order
Photo Part No Description Price (each) Stock
276467 PLUG $3.13 To Order
Photo Part No Description Price (each) Stock
979918 DOOR SUBSTRUCTURE PLUG $9.16 To Order
Photo Part No Description Price (each) Stock
919641 RH OUTER DOOR HANDLE MODULE $336.95 To Order
870284 COMPL. RH OUTER DOOR HANDLE MODULE $473.02 To Order
Photo Part No Description Price (each) Stock
919640 COMPL. LH OUTER DOOR HANDLE MODULE $530.36 To Order
870302 LH OUTER DOOR HANDLE MODULE $315.34 To Order
Photo Part No Description Price (each) Stock
980172 RH HANDLE PULL $59.35 To Order
979381 LH HANDLE PULL $59.35 To Order
Photo Part No Description Price (each) Stock
980174 RH HANDLE BUTTON $12.66 To Order
979385 LH HANDLE BUTTON $12.66 To Order
Photo Part No Description Price (each) Stock
14059290 FLANGED NUT M6 $1.51 To Order
Photo Part No Description Price (each) Stock
825692 DOOR CHECK STRAP $118.95 To Order
Photo Part No Description Price (each) Stock
83897000 DOOR CHECK STRAP SEAL $15.87 To Order
Photo Part No Description Price (each) Stock
84872900 SCREW $0.41 To Order
Photo Part No Description Price (each) Stock
939222 WASHER $3.03 To Order
Photo Part No Description Price (each) Stock
805794 LATCH HOLDER $286.67 To Order
939894 LATCH HOLDER $301.00 To Order
Photo Part No Description Price (each) Stock
915520 LH DOOR BOWDEN CABLE $90.30 To Order
Photo Part No Description Price (each) Stock
238692 ADJUSTMENT SHIM $6.55 To Order
238693 ADJUSTMENT SHIM $5.77 To Order
238881 CAMBER SPACER 1.5MM $5.77 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
262544 ADJUSTER SHIM $9.50 To Order
262544 ADJUSTER SHIM $9.50 To Order
238693 ADJUSTMENT SHIM $5.77 To Order
...and 5 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
12578011 NUT $0.16 To Order
View All
DOORS - OPENING MECHANISMS AND HINGES of Ferrari Ferrari 296 GTS USA Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
0001 804870
RH DOOR LOCK 		$630.70 1
0001 804886
RH DOOR LOCK 		$630.70 1
0001 804856
LH DOOR LOCK 		$630.70 1
0001 804879
LH DOOR LOCK 		$630.70 1
0002 808736
DOOR LOCK STRIKER PLATE 		$19.24 2
0003 802693
DOOR STRIKER PLATE SHIM 		$7.73 2
0004 924578
DOOR STRIKER PLATE FILM 		$7.33 2
0005 85133400
SCREW
M8 X 20 		$0.66 (26.7% off) 4
0006 80874100
SCREW
M6 X 18
ARRIVING SOON 		$1.10 (12% off) 6
0007 980005
COMPL. INNER DOOR HANDLE BOWDEN CABLE 		$131.85 2
0008 831375
COMPL. DOOR HANDLE 		$12.66 2
0009 880232
UPPER COVER 		$8.17 2
0010 276467
PLUG 		$3.13 2
0011 979918
DOOR SUBSTRUCTURE PLUG 		$9.16 4
0012 919641
RH OUTER DOOR HANDLE MODULE
Does not include latch holder and Bowden cable 		$336.95 1
0012 870284
COMPL. RH OUTER DOOR HANDLE MODULE
Including latch holder and Bowden cable 		$473.02 1
0013 919640
COMPL. LH OUTER DOOR HANDLE MODULE
Including latch holder and Bowden cable 		$530.36 1
0013 870302
LH OUTER DOOR HANDLE MODULE
Does not include latch holder and Bowden cable 		$315.34 1
0014 980172
RH HANDLE PULL
Primered 		$59.35 1
0014 979381
LH HANDLE PULL
Primered 		$59.35 1
0015 980174
RH HANDLE BUTTON
Primered 		$12.66 1
0015 979385
LH HANDLE BUTTON
Primered 		$12.66 1
0016 14059290
FLANGED NUT M6
M6 X 6.2 		$1.51 18
0017 825692
DOOR CHECK STRAP 		$118.95 2
0018 83897000
DOOR CHECK STRAP SEAL 		$15.87 2
0019 84872900
SCREW
M8 X 25 		$0.41 2
0020 939222
WASHER
D, 8 15 X 16 X 1 		$3.03 2
0021 805794
LATCH HOLDER 		$286.67 1
0021 939894
LATCH HOLDER 		$301.00 1
0022 915520
LH DOOR BOWDEN CABLE 		$90.30 1
0023 238692
ADJUSTMENT SHIM
Th. 0.5 mm 		$6.55 2
0023 238693
ADJUSTMENT SHIM
Th. 1 mm 		$5.77 (7.7% off) 2
0023 238881
CAMBER SPACER 1.5MM
Th. 1.5 mm 		$5.77 (6.2% off) 2
0023 238694
ADJUSTMENT SHIM
Th. 2 mm 		$5.59 (9.1% off) 2
0024 262544
ADJUSTER SHIM
Th. 0.5 mm 		$9.50 4
0024 262544
ADJUSTER SHIM
Th. 0.5 mm 		$9.50 2
0024 238693
ADJUSTMENT SHIM
Th. 1 mm 		$5.77 (7.7% off) 4
0024 238693
ADJUSTMENT SHIM
Th. 1 mm 		$5.77 (7.7% off) 2
0024 238881
CAMBER SPACER 1.5MM
Th. 1.5 mm 		$5.77 (6.2% off) 4
0024 238881
CAMBER SPACER 1.5MM
Th. 1.5 mm 		$5.77 (6.2% off) 2
0024 238694
ADJUSTMENT SHIM
Th. 2 mm 		$5.59 (9.1% off) 4
0024 238694
ADJUSTMENT SHIM
Th. 2 mm 		$5.59 (9.1% off) 2
0025 12578011
NUT
M5 		$0.16 4
