RADIATORS AND ELECTRIC FANS of Lamborghini Lamborghini Murcielago

View All

Lamborghini Murcielago - RADIATORS AND ELECTRIC FANS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
001	400611799	BRACKET 0 5 MM	400611799 BRACKET 0 5 MM	$0.79 MSRP: ~~7.28~~ (89.1% off)	6
002	7M121434	PIPE	7M121434 PIPE	$504.04	1
003	7M121107	PIPE	7M121107 PIPE	$215.74	1
004	7M121074	PIPE	7M121074 PIPE	$39.92	5
005	N0245165	CLAMP	N0245165 CLAMP	$4.78	8
006	7M121102	PIPE	7M121102 PIPE	$3,259.41	1
007	7L121199	PROTECTION	7L121199 PROTECTION	$19.97	4
008	N0111849	NUT	N0111849 NUT	$2.15 MSRP: ~~7.25~~ (70.3% off)	2
009	N90179103	WASHER 18X8,4X2,5	N90179103 WASHER 18X8,4X2,5	$1.55	2
010	WHT001942	WASHER	WHT001942 WASHER	$3.30	4
011	WHT000524	BANJO BOLT	WHT000524 BANJO BOLT	$24.66	2
012	N0138302	Washer Copper 8 x 1MM	N0138302 Washer Copper 8 x 1MM	$3.27 MSRP: ~~7.33~~ (55.4% off)	6
013	410121235	BRACKET	410121235 BRACKET	$6.61	1
014	410121252B	RH Complete Water Radiator	410121252B RH Complete Water Radiator	$5,672.05	1
015	410121539	GASKET	410121539 GASKET	$57.85	2
016	410121334A	RH CONVEYOR	410121334A RH CONVEYOR	$1,599.47	1
017	N01034518	SCREW M8X45	N01034518 SCREW M8X45	$6.00	4
018	7L959465C	ELECTRIC FAN	7L959465C ELECTRIC FAN	$1,659.02	2
019	N0152785	WASHER	N0152785 WASHER	$0.40	4
020	WHT001189	PLASTIC WASHER	WHT001189 PLASTIC WASHER	$6.27	2
021	WHT003058	SEAL RING	WHT003058 SEAL RING	$1.74 MSRP: ~~7.11~~ (75.5% off)	1
022	410121299	PLUG	410121299 PLUG	$231.85	2
023	400121277	DISTANCE PIECE	400121277 DISTANCE PIECE	$10.37	2
024	400121268	RUBBER BUSH	400121268 RUBBER BUSH	$11.56	2
025	WHT002961	WASHER	WHT002961 WASHER	$0.42	8
026	WHT002963	WASHER	WHT002963 WASHER	$0.13 MSRP: ~~7.38~~ (98.2% off)	8
027	8700614	SCREW	8700614 SCREW	$0.27	4
028	8700644	SCREW	8700644 SCREW	$0.37 MSRP: ~~7.34~~ (95% off)	8
029	8831515	CLAMP	8831515 CLAMP	$10.01	1
030	WHT003040	WASHER 5.3X1.5X15 (For Becker Radio System)	WHT003040 WASHER 5.3X1.5X15 (For Becker Radio System)	$7.53	4
031	WHT000769A	WASHER	WHT000769A WASHER	$0.89 MSRP: ~~7.26~~ (87.7% off)	4
032	N10430103	HEXAGON SOCKET FLAT HEAD BOLT	N10430103 HEXAGON SOCKET FLAT HEAD BOLT	$0.80 MSRP: ~~7.30~~ (89% off)	4
033	8100623	SCREW	8100623 SCREW	$0.36	2
034	7L121585	RUBBER BUSHING	7L121585 RUBBER BUSHING	$18.96	2
035	N10536103	SCREW M8X16	N10536103 SCREW M8X16	$0.98 MSRP: ~~7.27~~ (86.5% off)	2
036	410813686	RH BRACKET	410813686 RH BRACKET	$133.08	1
036	410813685	LH BRACKET	410813685 LH BRACKET	$225.13	1
037	8800606	BUSHING	8800606 BUSHING	$15.81	2
038	8400635	WASHER	8400635 WASHER	$26.68	8
039	410121253B	LH COMPLETE WATER RADIATOR	410121253B LH COMPLETE WATER RADIATOR	$5,672.05	1
040	410121214	BRACKET	410121214 BRACKET	$12.51	1
041	7M121103	PIPE	7M121103 PIPE	$159.95	1
042	8830303	CLAMP	8830303 CLAMP	$0.70 MSRP: ~~7.25~~ (90.3% off)	3
043	410121333A	LH CONVEYOR	410121333A LH CONVEYOR	$1,525.54	1
