Lamborghini Gallardo Superleggera - Hi Fi System

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Hi Fi System of Lamborghini Lamborghini Gallardo Superleggera Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
002 400035311D
SUPPORT 		$168.69 1
004 8E0035399
TWEETER 		$56.59 2
005 8E0035411
LOUDSPEAKER 		$82.12 2
006 8E0858075
RADIO SUPPORT (RNSE) 		$39.52 1
007 N0902941
SCREW ST4.2X19 		$0.80 (89% off) 6
008 N90729003
SCREW M5X16 		$0.62 (91.5% off) 6
009 N90777702
SPEED NUT 		$1.16 (84% off) 4
010 N90821401
EXPANDING NUT 		$1.32 (81.7% off) 6
011 400035192H
RADIO AND NAVIGATOR SYSTEM 		$5,430.08 1
012 1J5035111A
CD CHANGER 		$611.56 1
013 4D0919146D
TV-TUNER 		$3,508.07 1
015 402035550
FM3 ANTENNA CABLE (FOR GDX CARS) 		$43.15 1
016 8Z0919889
AERIAL GPS 		$338.70 1
017 400919909A
GPS ANTENNA BRACKET 		$24.34 1
022 408035535
BRACKET (TV ANTENNA AMPLIFIER) 		$11.17 1
023 400035536
BRACKET (ANTENNA AMPLIFIER AM/FM) 		$13.85 1
024 N90693702
SCREW M5X20 		$0.58 (92.1% off) 2
025 N90693702
SCREW M5X20 		$0.58 (92.1% off) 2
028 N01100412
HEXAGON NUT 		- 2 Enquire
030 WHT001190
ROUND HD. SCREW 		$0.53 2
