Oil System Radiator of Lamborghini Lamborghini Gallardo (2008)

View All

Lamborghini Gallardo (2008) - Oil System Radiator

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	400117098A	BRACKET	400117098A BRACKET	-	1	Enquire
002	N0902324	SCREW M6X10	N0902324 SCREW M6X10	-	1	Enquire
003	N90847903	Screw M6X15	N90847903 Screw M6X15	-	4	Enquire
004	7L117413C	HOSE	7L117413C HOSE	-	1	Enquire
005	7L115687C	HOSE	7L115687C HOSE	-	1	Enquire
006	N10451405	OVAL HEXAGON SOCKET HEAD BOLT	N10451405 OVAL HEXAGON SOCKET HEAD BOLT	-	4	Enquire
007	N90265703	NUT M6X7.6	N90265703 NUT M6X7.6	-	2	Enquire
008	400115339A	HEAT SHIELD	400115339A HEAT SHIELD	-	1	Enquire
009	400115707	CONNECTOR	400115707 CONNECTOR	-	1	Enquire
010	7L115664C	PIPE	7L115664C PIPE	-	1	Enquire
011	N10233401	CLAMP 16.2 X 7 X 0.60	N10233401 CLAMP 16.2 X 7 X 0.60	-	2	Enquire
013	7L115311E	PLUG	7L115311E PLUG	-	1	Enquire
014	7L115664C	PIPE	7L115664C PIPE	-	2	Enquire
016	N90107203	CLAMP 12 X 8.0 X 0.5	N90107203 CLAMP 12 X 8.0 X 0.5	-	2	Enquire
017	357711798	RUBBER SEAL	357711798 RUBBER SEAL	-	2	Enquire
018	N10005109	SCREW M8X35	N10005109 SCREW M8X35	-	2	Enquire
019	7L115373B	OIL TANK	7L115373B OIL TANK	-	1	Enquire
020	400115341B	HEAT SHIELD	400115341B HEAT SHIELD	-	1	Enquire
021	N10156305	SCREW M6X12	N10156305 SCREW M6X12	-	1	Enquire
022	7L115333B	RUBBER BUFFER	7L115333B RUBBER BUFFER	-	1	Enquire
023	N0138485	SEAL RING	N0138485 SEAL RING	-	1	Enquire
024	N91155901	SEALING SCREW PLUG M16 X 1.5	N91155901 SEALING SCREW PLUG M16 X 1.5	-	1	Enquire
025	7L919501A	Water Temperature Sensor	7L919501A Water Temperature Sensor	-	1	Enquire
026	7L115659G	OIL SUCTION ROSE	7L115659G OIL SUCTION ROSE	-	1	Enquire
027	7L115689B	PIPE	7L115689B PIPE	-	1	Enquire
028	N91107101	WASHER	N91107101 WASHER	-	1	Enquire
029	7L115688B	OILPIPE	7L115688B OILPIPE	-	1	Enquire
030	400117335	COOLER EXIT CONE	400117335 COOLER EXIT CONE	-	1	Enquire
031	400201365B	GASKET	400201365B GASKET	-	2	Enquire
032	400117097A	BRACKET	400117097A BRACKET	-	1	Enquire
033	400317025	LH CONVEYOR	400317025 LH CONVEYOR	-	1	Enquire
034	7L117015B	OIL COOLER	7L117015B OIL COOLER	-	1	Enquire
035	7L133741	SUPPORT	7L133741 SUPPORT	-	1	Enquire
036	7L115255	FLANGE	7L115255 FLANGE	-	1	Enquire
037	WHT000759	STUD BOLT (M6X14)	WHT000759 STUD BOLT (M6X14)	-	2	Enquire
038	N10129201	O-RING	N10129201 O-RING	-	1	Enquire
039	1J0711795	SPACER	1J0711795 SPACER	-	2	Enquire
040	400422095	FAIRLEAD	400422095 FAIRLEAD	-	1	Enquire
041	7L115333	RUBBER BUFFER	7L115333 RUBBER BUFFER	-	1	Enquire
042	N90937701	CABLE TIES	N90937701 CABLE TIES	-	1	Enquire
