Find Your Part

Disc Brake 1 of Lamborghini Lamborghini Gallardo LP550 Coupe

View All

Lamborghini Gallardo LP550 Coupe - Disc Brake 1

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	420615301K	Ceramic Brake Disc (vented) (left Front)	420615301K Ceramic Brake Disc (vented) (left Front)	-	1	Enquire
001	420615302G	Ceramic Brake Disc (vented) (right Front)	420615302G Ceramic Brake Disc (vented) (right Front) use : 4S0615302A	-	1	Enquire
002	400615105AK	LH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - YELLOW FRONT CALIPERS)	400615105AK LH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - YELLOW FRONT CALIPERS)	-	1	Enquire
002	400615106AL	RH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - SILVER)	400615106AL RH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - SILVER)	-	1	Enquire
002	400615105AL	LH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - SILVER)	400615105AL LH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - SILVER)	-	1	Enquire
002	400615105AR	LH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - ORANGE FRONT CALIPERS)	400615105AR LH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - ORANGE FRONT CALIPERS)	-	1	Enquire
002	400615105AJ	LH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - BLACK FRONT CALIPERS)	400615105AJ LH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - BLACK FRONT CALIPERS)	-	1	Enquire
002	400615106AJ	RH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - BLACK FRONT CALIPERS)	400615106AJ RH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - BLACK FRONT CALIPERS)	-	1	Enquire
002	400615106AR	RH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - ORANGE FRONT CALIPERS)	400615106AR RH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - ORANGE FRONT CALIPERS)	-	1	Enquire
002	400615106AK	RH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - YELLOW FRONT CALIPERS)	400615106AK RH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - YELLOW FRONT CALIPERS)	-	1	Enquire
003	420611707B	HOSE	420611707B HOSE	-	-	Enquire
005	420611846A	RH BRACKET	420611846A RH BRACKET	-	1	Enquire
006	420611845B	LH BRACKET	420611845B LH BRACKET	-	1	Enquire
007	N01029316	SCREW M8X16	N01029316 SCREW M8X16	-	2	Enquire
008	WHT001330A	SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD	WHT001330A SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD	-	2	Enquire
009	4S0698151AA	1 SET OF BRAKE PADS FOR DISK BRAKE	4S0698151AA 1 SET OF BRAKE PADS FOR DISK BRAKE	-	1	Enquire
010	8A0615273	1 SET BLEEDER VALVES WITH DUST CAP	8A0615273 1 SET BLEEDER VALVES WITH DUST CAP	-	2	Enquire
011	7D0611483	DUST CAP	7D0611483 DUST CAP	-	2	Enquire
012	400698135B	1 SET FIXING PARTS FOR DISC BRAKE PADS	400698135B 1 SET FIXING PARTS FOR DISC BRAKE PADS	-	2	Enquire
013	4E0698507	SET OF GASKETS FOR BRAKE CALIPER HOUSING	4E0698507 SET OF GASKETS FOR BRAKE CALIPER HOUSING	-	2	Enquire
015	400698137	BRAKE PAD WEAR SENSOR	400698137 BRAKE PAD WEAR SENSOR	-	1	Enquire
016	N10648301	HEX SOCKET COUNTERSUNK BOLT	N10648301 HEX SOCKET COUNTERSUNK BOLT	-	2	Enquire
017	R1400210	1 SET SPRINGS	R1400210 1 SET SPRINGS	-	1	Enquire
