Front Wheel and Hub Carrier

Find Your Part

Lamborghini Diablo SE30 (1993-1995) - Front Wheel and Hub Carrier

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Front Wheel and Hub Carrier of Lamborghini Lamborghini Diablo SE30 (1993-1995) Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 5333230
FRONT TIRE/TYRE
PNEUMATICO ANTERIORE 		- 2 Enquire
002 5134853
FRONT RIM
CERCHIO RUOTA ANTERIORE 		$1,874.47 2
003 5131893
STRAP
FASCETTA 		- 2 Enquire
004 5131894
GASKET
GUARNIZIONE 		$2.67 (1.1% off) 2
005 5131891
LOW TYRE P. SENSOR
TRASMETTITORE PRESSIONE 		- 2 Enquire
006 5132551
PLATE
TARGHETTA 		$16.25 2
007 5235331
TYRE REVOL. SENSOR
SENSORE GIRI RUOTA LAVOR. 		$1,842.41 2
008 8700614
SCREW
VITE 		$0.27 2
009 5134778
PHONIC WHEEL
RUOTA FONICA 		$377.79 2
010 8933601
PLUG
TAPPO 		$20.12 (3.7% off) 2
011 8700337
SCREW
VITE FISS.RUOTA FONICA 		$0.53 (92.7% off) 6
012 8410306
WASHER
RONDELLA 		- 6 Enquire
013 5134777
NUT
DADO FISS.MOZZI 		$89.96 2
014 5134975
PLUG
GHIERA 		$85.62 2
015 8515002
BEARING
CUSCINETTO 		$122.34 2
016 5134984
LEFT HUB HOUSING
PORTAMOZZO SX 		$1,755.58 1
016 5134983
RIGHT HUB HOUSING
PORTAMOZZO DX 		$1,755.58 1
017 5135004
HUB
MOZZO PORTA RUOTA ANTER. 		$251.88 2
018 5135969
STUD
COLONNETTA 		$50.57 10
019 5236122
PLUG
COPERCHIO 		- 2 Enquire
020 5131895
GASKET
GUARNIZIONE 		$3.43 (2% off) 2
021 5131892
BALANCE WEIGHT
CONTRAPPESO 		$33.01 2
022 5236123
ORNAMENT
FREGIO 		- 2 Enquire
023 5336014
VALVE
VALVOLA 		$39.00 2
