Handbrake of Lamborghini Lamborghini Diablo SE30 (1993-1995)

View All

Lamborghini Diablo SE30 (1993-1995) - Handbrake

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	410711301D	HAND BRAKE LEVER	410711301D HAND BRAKE LEVER	-	1	Enquire
002	N01118312	HEXAGON NUT, SELF-LOCKING	N01118312 HEXAGON NUT, SELF-LOCKING DADO	-	4	Enquire
003	3330827	BUSHING	3330827 BUSHING BOCCOLA	-	3	Enquire
004	9458374	CASE	9458374 CASE COPRI LEVA	-	1	Enquire
005	8700851	SCREW	8700851 SCREW VITE	-	3	Enquire
006	WHT001187	WASHER	WHT001187 WASHER RONDELLA	-	1	Enquire
007	N0211963	NUT	N0211963 NUT DADO	-	1	Enquire
008	3319356	SWITCH	3319356 SWITCH INTERRUTTORE PER SPIA	-	1	Enquire
009	3332512	PULLEY	3332512 PULLEY CARRUCOLA	-	3	Enquire
010	3332762	RIGHT TIE ROD	3332762 RIGHT TIE ROD TIRANTE DX	-	1	Enquire
011	8101407	SCREW M14X55	8101407 SCREW M14X55 VITE	-	1	Enquire
012	8411502	WASHER	8411502 WASHER RONDELLA	-	1	Enquire
013	3330828	SPACER	3330828 SPACER DISTANZIALE	-	1	Enquire
014	3330829	SPRING	3330829 SPRING MOLLA	-	1	Enquire
015	8200607	NUT M6	8200607 NUT M6 DADO	-	1	Enquire
016	413609206	ADJUSTING SLEEVE	413609206 ADJUSTING SLEEVE REGISTRO	-	1	Enquire
017	N01100632	NUT M6	N01100632 NUT M6 DADO	-	1	Enquire
018	410609789	JOURNAL	410609789 JOURNAL PERNO	-	2	Enquire
019	N0122094	WASHER	N0122094 WASHER RONDELLA	-	2	Enquire
020	4207085	CLIP	4207085 CLIP FERMO	-	1	Enquire
021	3332751	LEFT TIE ROD	3332751 LEFT TIE ROD TIRANTE SX	-	1	Enquire
022	3333935	ROCKER	3333935 ROCKER BILANCIERE	-	1	Enquire
023	3330880	RUBBER BUSHING	3330880 RUBBER BUSHING BOCCOLA GOMMA	-	1	Enquire
024	3330816	TIE ROD	3330816 TIE ROD TIRANTE CENTRALE	-	1	Enquire
025	8820201	SPLIT PIN	8820201 SPLIT PIN COPIGLIA	-	1	Enquire
026	8400606	WASHER	8400606 WASHER RONDELLA	-	1	Enquire
