View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
001	470201137C	FUEL FILLER NECK	470201137C FUEL FILLER NECK	$273.49	1
002	470201138A	FUEL FILLER NECK	470201138A FUEL FILLER NECK	$77.97	1
003	470201163A	BREATHER LINE	470201163A BREATHER LINE	$37.37	1
004	N91115401	SPRING BAND CLAMP	N91115401 SPRING BAND CLAMP	$5.51	2
005	8K0862153F	Throttle Control Element	8K0862153F Throttle Control Element	$98.53	1
007	470201553C	FUEL TANK CAP	470201553C FUEL TANK CAP	$1,074.55	1
009	N10549603	OVAL HEXAGON SOCKET HEAD BOLT	N10549603 OVAL HEXAGON SOCKET HEAD BOLT	$1.32	5
010	WHT001190	ROUND HD. SCREW	WHT001190 ROUND HD. SCREW	$0.53	5
011	470201290	MOUNTING BAR	470201290 MOUNTING BAR	$164.66	1
012	470201309	SEAL	470201309 SEAL	$151.22	1
013	N91188304	HEXAGON SOCKET HEAD BOLT	N91188304 HEXAGON SOCKET HEAD BOLT	$2.96	4
