REAR HOOD 2 of Lamborghini Lamborghini Aventador LP750 SV Roadster

View All

Lamborghini Aventador LP750 SV Roadster - REAR HOOD 2

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	475827302A	LID HINGE	475827302A LID HINGE	-	1	Enquire
001	475827301A	LID HINGE	475827301A LID HINGE	-	1	Enquire
002	475827394C	BRACKET	475827394C BRACKET	-	1	Enquire
002	475827393C	BRACKET	475827393C BRACKET	-	1	Enquire
003	417827379	GAS FILLED STRUT	417827379 GAS FILLED STRUT	-	2	Enquire
003	418827401A	GAS FILLED STRUT	418827401A GAS FILLED STRUT	-	2	Enquire
004	400827518B	STRIKER	400827518B STRIKER	-	1	Enquire
005	400807333	SUPPORT	400807333 SUPPORT	-	2	Enquire
006	470827523	BRACKET FOR TENSION SPRING	470827523 BRACKET FOR TENSION SPRING	-	2	Enquire
007	N90643905	HEXAGON HEAD BOLT (COMBI)	N90643905 HEXAGON HEAD BOLT (COMBI)	-	8	Enquire
008	N10558102	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	N10558102 SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	-	3	Enquire
009	N01111611	HEXAGON NUT	N01111611 HEXAGON NUT	-	2	Enquire
010	N10558102	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	N10558102 SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	-	4	Enquire
011	6X0827439	JOURNAL	6X0827439 JOURNAL	-	4	Enquire
012	475827066	BRACKET FOR TENSION SPRING	475827066 BRACKET FOR TENSION SPRING	-	1	Enquire
012	475827065	BRACKET FOR TENSION SPRING	475827065 BRACKET FOR TENSION SPRING	-	1	Enquire
014	400103145	SPACER	400103145 SPACER	-	2	Enquire
015	475823509B	Bonnet Lock-lower Part (with Wiring Harness, Carbon Engine Bonnet)	475823509B Bonnet Lock-lower Part (with Wiring Harness, Carbon Engine Bonnet)	-	1	Enquire
015	476823509	BONNET LOCK-LOWER PART	476823509 BONNET LOCK-LOWER PART	-	1	Enquire
