View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	472857051C	RHD Dashboard Black with Yellow Stitch	472857051C RHD Dashboard Black with Yellow Stitch	-	1	Enquire
001	471857922D	LOWER DASHBOARD ASSEMBLY (LEATHER UPHOLSTERY - SUPPLY VIN)	471857922D LOWER DASHBOARD ASSEMBLY (LEATHER UPHOLSTERY - SUPPLY VIN)	-	1	Enquire
002	471857226	Molding Dashboard	471857226 Molding Dashboard	-	1	Enquire
003	5K0919234A	CONTROL LAMP FOR DEACT- IVATION OF FRONT PASSENGER AIRBAG	5K0919234A CONTROL LAMP FOR DEACT- IVATION OF FRONT PASSENGER AIRBAG	-	1	Enquire
004	400853886	LAMBORGHINI EMBLEM	400853886 LAMBORGHINI EMBLEM	-	1	Enquire
005	471857222A	TRIM STRIP FOR DASH PANEL, FOIL SEALED	471857222A TRIM STRIP FOR DASH PANEL, FOIL SEALED	-	1	Enquire
006	470819903	DEFROSTER NOZZLE FOR WIND- SCREEN	470819903 DEFROSTER NOZZLE FOR WIND- SCREEN	-	1	Enquire
007	8K0909131D	IGNITION/STARTER SWITCH	8K0909131D IGNITION/STARTER SWITCH	-	1	Enquire
008	8R1905219	TRIM	8R1905219 TRIM	-	1	Enquire
009	470857087	Bracket	470857087 Bracket	-	1	Enquire
010	N90777702	SPEED NUT	N90777702 SPEED NUT	-	2	Enquire
011	N10406602	OVAL HEXAGON SOCKET HEAD BOLT	N10406602 OVAL HEXAGON SOCKET HEAD BOLT	-	2	Enquire
012	N10588402	SPEED NUT	N10588402 SPEED NUT	-	12	Enquire
013	N10586401	OVAL HEXAGON SOCKET HEAD BOLT	N10586401 OVAL HEXAGON SOCKET HEAD BOLT	-	2	Enquire
014	N90981701	SPEED NUT	N90981701 SPEED NUT	-	3	Enquire
015	N10738101	HEX SOCKET HEAD BOLT (COMBI)	N10738101 HEX SOCKET HEAD BOLT (COMBI)	-	3	Enquire
