Photo	Part No	Description	Price (each)	Stock
	324813	HEXAGONAL OIL PUMP DRIVE ROD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	309348	OIL RECOVERY PUMP GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	303379	OIL RECOVERY PUMP FILTER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	320781	CHECK VALVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	310610	CHECK VALVE MOUNTING BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	282391	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	310612	OIL PUMP BUSHING MOUNTING BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	239462	CALIBRATED SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	342254	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	285494	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	804104	OIL PUMP GASKET KIT	Enquire	To Order

View All

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
0001	887314	COMPL. OIL PUMPS	887314 COMPL. OIL PUMPS Applicable after depletion of 342155	-	1	Enquire
0001	887314	COMPL. OIL PUMPS	887314 COMPL. OIL PUMPS	-	1	Enquire
0002	324813	HEXAGONAL OIL PUMP DRIVE ROD	324813 HEXAGONAL OIL PUMP DRIVE ROD	-	1	Enquire
0003	309348	OIL RECOVERY PUMP GASKET	309348 OIL RECOVERY PUMP GASKET Also included in engine gasket set	-	1	Enquire
0004	303379	OIL RECOVERY PUMP FILTER	303379 OIL RECOVERY PUMP FILTER	-	1	Enquire
0005	320781	CHECK VALVE	320781 CHECK VALVE	-	1	Enquire
0006	310610	CHECK VALVE MOUNTING BRACKET	310610 CHECK VALVE MOUNTING BRACKET	-	1	Enquire
0007	282391	SCREW	282391 SCREW M6 X 12	-	2	Enquire
0008	310612	OIL PUMP BUSHING MOUNTING BRACKET	310612 OIL PUMP BUSHING MOUNTING BRACKET	-	1	Enquire
0009	239462	CALIBRATED SCREW	239462 CALIBRATED SCREW	-	1	Enquire
0010	986899	WASHER	986899 WASHER	-	2	Enquire
0010	986899	WASHER	986899 WASHER	-	2	Enquire
0011	342254	SCREW	342254 SCREW	-	1	Enquire
0012	285494	SCREW	285494 SCREW M8 X 50	-	5	Enquire
0013	804104	OIL PUMP GASKET KIT	804104 OIL PUMP GASKET KIT Also included in engine gasket set	-	1	Enquire
