ENGINE COVERS of Ferrari Ferrari Purosangue Europe RH

View All

Ferrari Purosangue Europe RH - ENGINE COVERS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	882063	FRONT CRANKCASE COVER	$1,758.83	To Order

Photo	Part No	Description	Price (each)	Stock
	881983	GASKET	$57.75	To Order

Photo	Part No	Description	Price (each)	Stock
	175611	CENTERING DOWEL	$1.78	To Order

Photo	Part No	Description	Price (each)	Stock
	915452	BRACKET	$54.46	To Order

Photo	Part No	Description	Price (each)	Stock
	231625	SCREW	$0.65	To Order

Photo	Part No	Description	Price (each)	Stock
	274641	GASKET CRANKCASE D.49.5 X 62 X 7	$30.47	To Order

Photo	Part No	Description	Price (each)	Stock
	274642	SEAL D.49.5 X 65 X 8	$32.08	To Order

Photo	Part No	Description	Price (each)	Stock
	263649	GASKET D.71 44X 3.53	$11.56	To Order

Photo	Part No	Description	Price (each)	Stock
	258572	GASKET	$25.79	To Order

Photo	Part No	Description	Price (each)	Stock
	11061076	SEEGER RING	$1.78	To Order

Photo	Part No	Description	Price (each)	Stock
	258593	BEARING	$26.60	To Order

Photo	Part No	Description	Price (each)	Stock
	946852	FASTENER STUD	$74.52	To Order

Photo	Part No	Description	Price (each)	Stock
	925715	O-RING	$0.71	To Order

Photo	Part No	Description	Price (each)	Stock
	231622	SCREW	$0.36	To Order

Photo	Part No	Description	Price (each)	Stock
	14305524	SCREW	$0.15	To Order

Photo	Part No	Description	Price (each)	Stock
	216292	GASKET	$4.15	To Order

Photo	Part No	Description	Price (each)	Stock
	943939	WATER THERMOSTAT HOUSING	$372.69	To Order
	958545	WATER THERMOSTAT HOUSING	$358.34	To Order

Photo	Part No	Description	Price (each)	Stock
	262913	THERMOSTAT/PRESSURE SWITCH	$272.77	To Order

Photo	Part No	Description	Price (each)	Stock
	231619	SCREW	$0.31	To Order

Photo	Part No	Description	Price (each)	Stock
	228438	CONNECTOR	$9.50	To Order

Photo	Part No	Description	Price (each)	Stock
	180137	TEMPERATURE SENSOR	$30.23	To Order

Photo	Part No	Description	Price (each)	Stock
	920305	UNION FOR WATER VAPOUR VENT	$172.00	To Order

Photo	Part No	Description	Price (each)	Stock
	248334	SCREW	$0.68	To Order

Photo	Part No	Description	Price (each)	Stock
	231620	SCREW	$0.32	To Order

Photo	Part No	Description	Price (each)	Stock
	981171	WATER THERMOSTAT HOUSING GASKET	$21.17	To Order

Photo	Part No	Description	Price (each)	Stock
	14305924	SCREW	$0.18	To Order

Photo	Part No	Description	Price (each)	Stock
	183010	O-RING	$1.70	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
0001	882063	FRONT CRANKCASE COVER	882063 FRONT CRANKCASE COVER	$1,758.83	1
0002	881983	GASKET	881983 GASKET	$57.75	1
0003	175611	CENTERING DOWEL	175611 CENTERING DOWEL	$1.78	2
0004	915452	BRACKET	915452 BRACKET	$54.46	1
0005	231625	SCREW	231625 SCREW M6 X 50	$0.65	12
0006	274641	GASKET CRANKCASE D.49.5 X 62 X 7	274641 GASKET CRANKCASE D.49.5 X 62 X 7 Also included in engine gasket set; D. 49.5 X 62 X 7	$30.47 MSRP: ~~39.62~~ (23.1% off)	1
0007	274642	SEAL D.49.5 X 65 X 8	274642 SEAL D.49.5 X 65 X 8 Also included in engine gasket set; D. 49.5 X 65 X 8	$32.08 MSRP: ~~42.50~~ (24.5% off)	1
0008	263649	GASKET D.71 44X 3.53	263649 GASKET D.71 44X 3.53 Also included in engine gasket set; D. 71.44 X 3.53	$11.56	1
0009	258572	GASKET	258572 GASKET Also included in engine gasket set; D. 34.9 X 62 X 7	$25.79 MSRP: ~~32.56~~ (20.8% off)	1
0010	11061076	SEEGER RING	11061076 SEEGER RING	$1.78	1
0011	258593	BEARING	258593 BEARING	$26.60	1
0012	946852	FASTENER STUD	946852 FASTENER STUD	$74.52	1
0013	925715	O-RING	925715 O-RING Also included in engine gasket set	$0.71	1
0014	231622	SCREW	231622 SCREW M6 X 35	$0.36 MSRP: ~~0.50~~ (28% off)	4
0015	14305524	SCREW	14305524 SCREW M6 X 30	$0.15	1
0016	216292	GASKET	216292 GASKET Also included in engine gasket set	$4.15	5
0017	943939	WATER THERMOSTAT HOUSING	943939 WATER THERMOSTAT HOUSING Applies until depletion	$372.69	1
0017	958545	WATER THERMOSTAT HOUSING	958545 WATER THERMOSTAT HOUSING Applicable after depletion of 943939	$358.34	1
0018	262913	THERMOSTAT/PRESSURE SWITCH	262913 THERMOSTAT/PRESSURE SWITCH	$272.77 MSRP: ~~360.40~~ (24.3% off)	1
0019	231619	SCREW	231619 SCREW M6 X 20	$0.31	12
0020	228438	CONNECTOR	228438 CONNECTOR	$9.50	1
0021	180137	TEMPERATURE SENSOR	180137 TEMPERATURE SENSOR	$30.23 MSRP: ~~32.99~~ (8.4% off)	1
0022	920305	UNION FOR WATER VAPOUR VENT	920305 UNION FOR WATER VAPOUR VENT	$172.00	1
0023	248334	SCREW	248334 SCREW M6 X 14	$0.68	1
0024	231620	SCREW	231620 SCREW M6 X 25	$0.32 MSRP: ~~0.35~~ (8.6% off)	4
0025	981171	WATER THERMOSTAT HOUSING GASKET	981171 WATER THERMOSTAT HOUSING GASKET Also included in engine gasket set	$21.17	1
0026	14305924	SCREW	14305924 SCREW M6 X 45	$0.18	4
0027	183010	O-RING	183010 O-RING Also included in engine gasket set	$1.70 MSRP: ~~2.89~~ (41.2% off)	2
