CYLINDER HEADS - RH HEAD of Ferrari Ferrari Purosangue Europe

View All

Ferrari Purosangue Europe - CYLINDER HEADS - RH HEAD

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	949234	RH HEAD ASSEMBLY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	815999	RH CYLINDER HEAD COVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	324013	RH HEAD-CRANKCASE GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	243800	RH HEAD COVER GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	317962	THREADED CONNECTOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	772927	SINGLE IGNITION COIL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	223982	SPARK PLUG TUBE SEAL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	801187	OIL PRESSURE REGULATOR VALVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	229353	SOLENOID VALVE GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14304221	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11181574	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	157218	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	157218	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	248334	SCREW M6 X 14MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	339948	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	269228	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	333779	CALIBRATED STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14499421	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	293278	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	986899	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	239614	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127635	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	200458	NON RETURN VALVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	252099	SHIELD MOUNTING BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	211641	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231620	SCREW	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
0001	949234	RH HEAD ASSEMBLY	949234 RH HEAD ASSEMBLY	-	1	Enquire
0002	815999	RH CYLINDER HEAD COVER	815999 RH CYLINDER HEAD COVER	-	1	Enquire
0003	324013	RH HEAD-CRANKCASE GASKET	324013 RH HEAD-CRANKCASE GASKET Also included in engine gasket set	-	1	Enquire
0004	243800	RH HEAD COVER GASKET	243800 RH HEAD COVER GASKET Also included in engine gasket set	-	1	Enquire
0005	317962	THREADED CONNECTOR	317962 THREADED CONNECTOR	-	1	Enquire
0006	772927	SINGLE IGNITION COIL	772927 SINGLE IGNITION COIL	-	6	Enquire
0007	223982	SPARK PLUG TUBE SEAL	223982 SPARK PLUG TUBE SEAL Also included in engine gasket set	-	6	Enquire
0008	801187	OIL PRESSURE REGULATOR VALVE	801187 OIL PRESSURE REGULATOR VALVE	-	2	Enquire
0009	229353	SOLENOID VALVE GASKET	229353 SOLENOID VALVE GASKET Also included in engine gasket set	-	1	Enquire
0010	14304221	SCREW	14304221 SCREW M5 X 16	-	2	Enquire
0011	11181574	WASHER	11181574 WASHER	-	2	Enquire
0012	157218	SCREW	157218 SCREW M6 X 25	-	13	Enquire
0013	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2	-	18	Enquire
0014	157218	SCREW	157218 SCREW	-	2	Enquire
0015	248334	SCREW M6 X 14MM	248334 SCREW M6 X 14MM M6 X 14	-	1	Enquire
0016	339948	STUD BOLT	339948 STUD BOLT H. 14 mm	-	1	Enquire
0017	269228	STUD BOLT	269228 STUD BOLT M6 X 25	-	2	Enquire
0018	333779	CALIBRATED STUD BOLT	333779 CALIBRATED STUD BOLT	-	1	Enquire
0019	14499421	WASHER	14499421 WASHER	-	1	Enquire
0020	293278	SCREW	293278 SCREW M6 X 1	-	1	Enquire
0021	986899	WASHER	986899 WASHER	-	1	Enquire
0022	239614	GASKET	239614 GASKET Also included in engine gasket set	-	1	Enquire
0023	127635	THREADED PLUG	127635 THREADED PLUG M18 X 11 X 1.5	-	6	Enquire
0024	200458	NON RETURN VALVE	200458 NON RETURN VALVE	-	2	Enquire
0025	252099	SHIELD MOUNTING BRACKET	252099 SHIELD MOUNTING BRACKET	-	1	Enquire
0026	211641	STUD BOLT	211641 STUD BOLT M8 X 16- -Shank length 24	-	12	Enquire
0027	231620	SCREW	231620 SCREW M6 X 25	-	1	Enquire
