CRANKCASE of Ferrari Ferrari Portofino M USA

View All

Ferrari Portofino M USA - CRANKCASE

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	764321	CRANKCASE-LOWER CRANKCASE SHELL ASSEMBLY	Enquire	To Order
	833196	CRANKCASE-LOWER CRANKCASE SHELL ASSEMBLY	Enquire	To Order
	804472	CRANKCASE-LOWER CRANKCASE SHELL ASSEMBLY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	271598	GASKET	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	271564	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	270464	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	185360	CENTERING DOWEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	282753	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	271810	CYLINDER SLEEVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	294153	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	307477	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10263460	COPPER GASKET D.28-22.3 X 1.5	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	311001	CENTERING DOWEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	278119	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	291078	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	282755	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	294614	CHECK VALVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231620	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	298858	PISTON COOLING NOZZLE ASSEMBLY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	298859	PISTON COOLING NOZZLE ASSEMBLY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	315493	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	339298	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	339289	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231620	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	278120	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	288133	DRIVE JOINT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11060276	SEEGER RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	247049	BEARING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11066876	SEEGER RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	102725	CENTERING DOWEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	255138	BLOW-BY VALVE ASSEMBLY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14303123	SCREW	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
0001	764321	CRANKCASE-LOWER CRANKCASE SHELL ASSEMBLY	764321 CRANKCASE-LOWER CRANKCASE SHELL ASSEMBLY For vehicles up to Ass.ly No. 506909 also order pipes in tab. 28, 787611 ref. 1, 787612 ref. 2, 787609 ref. 6, 787610 ref. 7, 787613 ref. 11 and 787614 ref. 12 - Also order washer 12642524 Ref.10 Tab.38; Applicable after depletion of 833196; Applicable from engine No. 506910	-	1	Enquire
0001	833196	CRANKCASE-LOWER CRANKCASE SHELL ASSEMBLY	833196 CRANKCASE-LOWER CRANKCASE SHELL ASSEMBLY For vehicles up to Ass.ly No. 506909 also order pipes in tab. 28, 787611 ref. 1, 787612 ref. 2, 787609 ref. 6, 787610 ref. 7, 787613 ref. 11 and 787614 ref. 12; Applies until depletion - Applicable after depletion of 804472; Applicable from engine No. 506910	-	1	Enquire
0001	804472	CRANKCASE-LOWER CRANKCASE SHELL ASSEMBLY	804472 CRANKCASE-LOWER CRANKCASE SHELL ASSEMBLY Applies until depletion; Applicable up to engine No. 506909	-	1	Enquire
0002	271598	GASKET ARRIVING SOON	271598 GASKET Also included in engine gasket set ARRIVING SOON	-	1	Enquire
0003	271564	STUD BOLT	271564 STUD BOLT	-	2	Enquire
0004	270464	STUD BOLT	270464 STUD BOLT	-	18	Enquire
0005	185360	CENTERING DOWEL	185360 CENTERING DOWEL	-	4	Enquire
0006	282753	THREADED PLUG	282753 THREADED PLUG	-	2	Enquire
0007	271810	CYLINDER SLEEVE	271810 CYLINDER SLEEVE	-	8	Enquire
0008	294153	GASKET	294153 GASKET Also included in engine gasket set	-	24	Enquire
0009	307477	THREADED PLUG	307477 THREADED PLUG	-	2	Enquire
0010	10263460	COPPER GASKET D.28-22.3 X 1.5	10263460 COPPER GASKET D.28-22.3 X 1.5 Also included in engine gasket set	-	2	Enquire
0011	311001	CENTERING DOWEL	311001 CENTERING DOWEL	-	2	Enquire
0012	278119	STUD BOLT	278119 STUD BOLT	-	6	Enquire
0013	291078	THREADED PLUG	291078 THREADED PLUG M12 X 11	-	2	Enquire
0014	282755	THREADED PLUG	282755 THREADED PLUG D. 10 X 1.25	-	2	Enquire
0015	294614	CHECK VALVE	294614 CHECK VALVE	-	1	Enquire
0016	231620	SCREW	231620 SCREW M6 X 30	-	1	Enquire
0017	298858	PISTON COOLING NOZZLE ASSEMBLY	298858 PISTON COOLING NOZZLE ASSEMBLY	-	4	Enquire
0018	298859	PISTON COOLING NOZZLE ASSEMBLY	298859 PISTON COOLING NOZZLE ASSEMBLY	-	8	Enquire
0019	315493	SCREW	315493 SCREW M4 X 10	-	12	Enquire
0020	339298	GASKET	339298 GASKET Also included in engine gasket set	-	1	Enquire
0021	339289	GASKET	339289 GASKET Also included in engine gasket set	-	1	Enquire
0022	231620	SCREW	231620 SCREW M6 X 25	-	13	Enquire
0023	278120	STUD BOLT	278120 STUD BOLT	-	2	Enquire
0024	288133	DRIVE JOINT	288133 DRIVE JOINT	-	1	Enquire
0025	11060276	SEEGER RING	11060276 SEEGER RING	-	1	Enquire
0026	247049	BEARING	247049 BEARING	-	1	Enquire
0027	11066876	SEEGER RING	11066876 SEEGER RING	-	1	Enquire
0028	102725	CENTERING DOWEL	102725 CENTERING DOWEL	-	2	Enquire
0029	255138	BLOW-BY VALVE ASSEMBLY	255138 BLOW-BY VALVE ASSEMBLY	-	4	Enquire
0030	14303123	SCREW	14303123 SCREW M4 X 14	-	8	Enquire
